Register for your
extended warranty
before spraying.
petratools.com/HD101
realpetratools
Need Help?
petratools.com/support/HD101
for FAQ's and videos on using
this product. Or, contact us at:
support@petratools.com
(800) 613-6889
PetraTools
PetraTools
HD101 SPRAYER
Pr od u ct M an u al
PT-SS-1112-1G-V1
Scan or visit
Advertisement
Table of Contents
Related Manuals for PetraTools HD101
Summary of Contents for PetraTools HD101
- Page 1 HD101 SPRAYER Pr od u ct M an u al PT-SS-1112-1G-V1 Need Help? Scan or visit Register for your petratools.com/support/HD101 extended warranty for FAQ’s and videos on using before spraying. this product. Or, contact us at: support@petratools.com petratools.com/HD101 (800) 613-6889...
- Page 2 Minors should not be allowed to use this sprayer. Do not use if bystanders or animals are nearby. Do not modify in any way that is not explicitly recommended in PetraTools videos or instructions. Wear sturdy shoes or boots with non-slip soles. Always wear proper protective clothing and gloves when handling or spraying chemicals.
-
Page 3: What's In The Box
WHAT’S IN THE BOX? FAN FLAT ADJUSTABLE NOZZLE NOZZLE SPRAYER WAND VALVE HANDLE MANUAL Questions/ Issues with 1-800-613-6889 Please visit the page your product? support@petratools.com petratools.com/support/HD101 We’ll make it right www.petratools.com... -
Page 4: Pump Assembly
PRODUCT SPECIFICATIONS PUMP ASSEMBLY PUMP HANDLE PUMP HOUSING VALVE HANDLE FILTER FILTR-10153 NOZZLE (ADJUSTABLE) TIP-10139 NOZZLE (FAN FLAT) TIP-10140 HOSE-10137 HOSE HNDL-10138 PUMP ASSEMBLY PUMP-10149 VALVE HANDLE COMPRESSION NUT NUT-10152 FUNNEL BOWL MISC-10150 FILTR-10154 TANK FILTER PRESSURE-RELEASE VALVE VALVE-10151 WAND WAND-10141 TANK TANK-10098... - Page 5 HOW TO USE THE HD101 SPRAYER? STEP 1 - UNBOXING Open the box to find your HD101 unit, wand, and accessory bag. STEP 2 - ATTACHING THE WAND Fully insert the wand into the valve handle. A twisting motion often helps ensure a complete fit.
-
Page 6: Step 5 - Operation
STEP 4 - ADDING SOLUTION Carefully pour the solution through the wide-mouth lid of the tank. After filling the tank, re-thread the pump assembly back into the tank and tighten clockwise. STEP 5 - OPERATION Check Connections: Make sure the pressure relief valve and hose connections are tight. - Page 7 HOW TO CHANGE NOZZLES Changing the Nozzles If you need to change the nozzles on your HD101 One Gallon Pump Sprayer, follow these simple steps. The nozzles are attached to the end of the sprayer rod with a compression nut.
- Page 8 2. Remove the Hose: Carefully pull the hose away from the valve handle to disconnect it. 3. Unthread the Filter Housing: Use an adjustable wrench to unthread the filter housing from the bottom of the valve handle. 4. Remove and Inspect the Filter: Remove the filter from the housing and inspect it for debris or damage. ...
- Page 9 STEPS TO CHECK, CLEAN, OR REPLACE THE TANK FILTER: 1. Unthread the Hose Connection: Unthread the hose connection from the tank by hand. 2. Remove the Pickup Hose: Remove the pickup hose from inside the tank. 3. Remove and Inspect the Filter: Locate the filter at the bottom of the pickup hose, inspect it for any debris or...
-
Page 10: Troubleshooting Steps
100% SATISFACTION GUARANTEE: Your satisfaction with this sprayer is our primary concern. If you're not completely happy with your purchase, please contact our friendly support team at 1-800-613-6889 for immediate assistance. We offer a 30-day return policy from the date of purchase AND a total satisfaction guarantee. If the product doesn't meet your expectations, just let us know, and our dedicated customer service team will make sure you have an excellent experience with our product. -
Page 11: Pump Inspection
• Liquid Level: Verify that there is sufficient liquid in the tank. • Clogged Filters: Check and clean the filters inside the valve handle and at the bottom of the hose inside the tank. Questions/ Issues with 1-800-613-6889 Please visit the page your product? support@petratools.com petratools.com/support/HD101 We’ll make it right www.petratools.com... -
Page 12: 100% Satisfaction Guarantee
If you have any questions, concerns, or missing parts DO NOT RETURN UNIT TO STORE / ONLINE RETAILER PLEASE CALL OUR SUPPORT HOTLINE AT 1-800-613-6889 Visit www.petratools.com Email our support: support@petratools.com Common maintenance questions: www.petratools.com/start...
