XENIT PLUS
USER'S MANUAL
VERSION - 04/16
FLY
Products
©
s.r.l.
Copyright by
Via Perù n. 30
63013 GROTTAMMARE (AP) - ITALY
tel./fax +39.735.632486
www.flyproducts.com
-
fly@flyproducts.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XENIT PLUS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Fly Products XENIT PLUS

  • Page 1 XENIT PLUS USER’S MANUAL VERSION - 04/16 Products © s.r.l. Copyright by Via Perù n. 30 63013 GROTTAMMARE (AP) - ITALY tel./fax +39.735.632486  www.flyproducts.com fly@flyproducts.com...
  • Page 2 Index Chapter Description INTRODUCTION GENERAL INFORMATION UNPACKING AND ASSEMBLING YOUR “XENIT PLUS” PREPARING YOUR FLIGHT FLYING YOUR NEW “XENIT PLUS” MAINTENANCE TROUBLESHOOTING SPECIFICATION AND PERFORMANCE MISCELLANEOUS...
  • Page 3: Introduction And General Information

    Please read and be sure you thoroughly understand this Operator’s Manual before starting or flying your XENIT PLUS. It contains information critical to the safe operation of the Trike.
  • Page 4 XENIT PLUS features  Easy assembly and disassembly  Electric Starter  Power Ignition  Reduction drive DIMENSIONS...
  • Page 5: Frame Assembly

    UNPACKING AND ASSEMBLING “XENIT PLUS” Frame assembly Frame assembly and disassembly is very fast and easy. The outer frame consists of four parts, and they are held together by the velcro straps. For an easy and correct assembly proceed in the following order:...
  • Page 6 Secure belt passenger harness Adjustable belt Pilot harness belt...
  • Page 7 Attach the left cable and using the tensioning Attach the right cable (the one without the device pull the cable tight. tensioning device). Insert the 2 lower parts of frame. Insert the push pin from the back into position...
  • Page 8 Insert the 2 push pins into position and secure the cage. Secure the tank in its placement using the tank belt.
  • Page 9: Emergency Parachute

    Emergency parachute A reserve parachute can be attached to the XENIT PLUS and is highly recommended for obvious security reasons. The reserve parachute is inserted under the harness of the pilot. A reserve parachute can be attached to the XENIT THOR 250 and is highly recommended for obvious security reasons.
  • Page 10 Attach the 2 parachute straps to the 2 Side view of the mounted rescue carabiners, protect them with the 2 covers pack and harness. Attention! A parachute is a life-saving tool that should be used only in situations of real danger. A reserve parachute should never be used "for fun", or just to see how it works.
  • Page 11: Fuel And Oil

    Mounting the prop, the red arrow indicate the direction of propeller rotation. PREPARING FOR YOUR FLIGHT Fuel and Oil FLY PRODUCTS recommends the use of a unleaded automotive gasoline of 92 octane or higher, and the use semi-synthetic 2-cycle oil.
  • Page 12: Before Starting The Engine

    Before Starting the Engine Before starting the engine on the ground, ensure that the unit is in an area free from dirt, rocks, dust, etc. that could be sucked up and thrown around by the propeller. Check assembly of the unit, and especially check any and all nuts, bolts, and screws, that could be loose. Also check all parts of the prop cage for looseness.
  • Page 13: Starting The Engine

     Close the inlet on the filter intake Starting the engine Now that we’ve covered stopping the motor, let’s start the engine! If everything is ready as described in the procedure preloads, place the switch in ON position Pump the mixture through the appropriate manual blower.
  • Page 14 - In flight One very valuable feature of the XENIT PLUS is its ability to be started while in flight. This feature allows the pilot the freedom to turn-off the engine and glide silently, to enjoy the exhilaration of thermal soaring, and then when he gets low, to start the engine and climb back up to do it again.
  • Page 15 Carburetor Adjusting with WALBRO WB 39 Standard carburetor setting When purchased, the motor has a standard carburetor setting and testing. To modify this, you must adjust the two screws of the carburetor. The screw on the right marked with a L (low) regulates the entrance of fuel at the low rpm (the range of the accelerator from zero to half).
  • Page 16: Engine Break-In

    During the break-in, gently change RPM from idle to 3/4-throttle and back. At this point, you can fly the XENIT PLUS however avoid long durations of full Power, and vary the throttle setting often. Break-in is complete after 10 liters of fuel have been run through the engine.
  • Page 17 It is highly recommended that you use one of the examples, or create your own, print it out, laminate it, and use it whenever you fly. Also note that these Checklists are examples only, FLY PRODUCTS is not responsible for their use or for their completeness. The following checklists are provided only as EXAMPLES.
  • Page 18 Adjustments version tandem or mono Tandem setup The glider attachment must be positioned further The glider attachment must be positioned forward for flights with a pilot of less than 85 kg and further back for flights with a pilot of over 90 passenger of over 90 kg.
  • Page 19: Maintenance Overview

    Remember… …that YOU are ultimately responsible for your motor and it’s proper care, FLY PRODUCTS and it’s dealers assume NO responsibility for any engine problem resulting from improper use! Before leaving the factory each motor has been tested for up to 30 minutes to insure that it is in proper running order and all FLY PRODUCTS units are guaranteed of one year after purchase.
  • Page 20 XENIT PLUS _ OWNER’S MANUAL ____ VER. 1.1 • Rubber components such as belt transmission, silent block, intake manifold and depression tube may be damaged by atmospheric agents. Their durability can therefore be different from what is reported, you should therefore check their condition and provide a possible replacement even outside the agreed time.
  • Page 21 XENIT PLUS _ OWNER’S MANUAL ____ VER. 1.1 SELECTION B: 72.700mm SELECTION C: 72.710mm SELECTION D: 72.720mm • The pin must not be blue because that indicates a high working temperature and the external diameter must not be less than 17.990mm.
  • Page 22 XENIT PLUS _ OWNER’S MANUAL ____ VER. 1.1 Operation Date check Inspector Remarks time (h) ___________________________________________________________________________ Products © Copyright s.r.l. Page...
  • Page 23: Spark Plug

    VER. 1.1 Cleaning Clean your XENIT PLUS with clean water and a mild soap. Dust and dirt can be brushed off, or removed with water and mild soap. Grease and oil can be removed with a good water-based degreaser such as “Simple Green”.
  • Page 24 XENIT PLUS _ OWNER’S MANUAL ____ VER. 1.1 Caution! Repairs to the harness or any stress-carrying areas of the XENIT PLUS should only be performed by a certified parachute rigger. Reduction belt ADJUSTING REDUCTION BELT Attention: Only qualified people can do this procedure, otherwise consult your dealer.
  • Page 25: Troubleshooting Chart

    XENIT PLUS _ OWNER’S MANUAL ____ VER. 1.1 Before you begin, make a small mark from pin to the pulley so as to have a reference point for measuring the displacement of the eccentric "C", these settings are "fine" and must not exceed 1 mm.
  • Page 26: Specifications And Performance

    XENIT PLUS _ OWNER’S MANUAL ____ VER. 1.1 to run Incorrect Idle Mixture adjustment See section 3.1 Prop out of balance See section 2.3 Excessive Check and tighten engine mounting Vibration Loose fasteners bolts, muffler bolts, prop bolts, etc. SPECIFICATIONS AND PERFORMANCE...
  • Page 27: Torque Specification Chart

    XENIT PLUS _ OWNER’S MANUAL ____ VER. 1.1 Frame Aluminium, aircraft tubing Harness Rip-stop nylon Dry Weight 62 kg MAX Pilot weight Kg. 95 + 95 Torque Specification Chart ELEMENTS TORQUE (Kgm) Cylinder head bolts ( M8 BTR ) Magnet fixing nut ( M10 x 1 ) Reduction cam locking screw ( M8 ) Primary pulley locking screw ( M12 x 1.25 )
  • Page 28: Electric System

    XENIT PLUS _ OWNER’S MANUAL ____ VER. 1.1 Electric system Following table shows the MINI3 electric connections ___________________________________________________________________________ Products © Copyright s.r.l. Page...
  • Page 29 XENIT PLUS _ OWNER’S MANUAL ____ VER. 1.1 MISCELLANEOUS Obtaining Repair Parts To obtain repairs parts for your machine, call your FLY PRODUCTS local dealer or FLY PRODUCTS directly. MINI3 ENGINE SPARE PARTS ___________________________________________________________________________ Products © Copyright s.r.l. Page...
  • Page 30 XENIT PLUS _ OWNER’S MANUAL ____ VER. 1.1 MINI3 engine spare parts list MINI 3/01 KIT ENGINE SCREWS MINI 3/46 ECCENTRIC PINION MINI 3/02 EXHAUST SYSTEM MINI 3/47 SEEGER REDUCTION MINI 3/03 COMPLETE SET OF GASKETS MINI 3/48 COMPLETE SET OF REDUCTION BEARINGS...
  • Page 31: Warranty

    VER. 1.1 Warranty FLY PRODUCTS will warrant their product to be free from defects in materials and workmanship for a period of one year from the date of purchase. This warranty applies to the product in normal usage situations only. The dealer, from whom you purchased the product, or FLY PRODUCTS, will repair the product free-of-charge.
