Automatic Wrist
Blood Pressure
Monitor
RS7 Intelli IT (HEM-6232T-E)
Instruction Manual
Table of Contents
Introduction
Important Safety Information
Introduction
Thank you for purchasing the RS7 Intelli IT Automatic Wrist Blood
Pressure Monitor. This blood pressure monitor is to be worn on your
wrist.
This blood pressure monitor uses the oscillometric method of blood
pressure measurement. When the cuff inflates, this monitor senses
the pressure pulsations of the artery underneath the cuff. The pulses
are called oscillometric pulses. The electronic pressure sensor
displays a digital reading of blood pressure.
Safety Instructions
This instruction manual provides you with important information
about the RS7 Intelli IT Automatic Wrist Blood Pressure Monitor. To
ensure the safe and proper use of this monitor, READ and
UNDERSTAND all of the safety and operating instructions. If you do
not understand these instructions or have any questions, contact
your OMRON retail outlet or distributor before attempting to use this
monitor. For specific information about your own blood pressure,
consult with your physician.
Intended Use
This device is a digital monitor intended for use in measuring blood
pressure and pulse rate in adult patient population with wrist
circumference ranging from 13.5 cm to 21.5 cm. This monitor
detects the appearance of irregular heartbeats during measurement
and gives a warning signal with readings. It is mainly designed for
general household use.
Receiving and Inspection
Remove this monitor from the packaging and inspect for damage. If
this monitor is damaged, DO NOT USE and consult with your
OMRON retail outlet or distributor.
Important Safety Information
Please read the Important Safety Information in this instruction
manual before using this monitor.
Please follow this instruction manual thoroughly for your safety.
Please keep for future reference. For specific information about your
own blood pressure, CONSULT WITH YOUR PHYSICIAN.
Warning
• DO NOT use this monitor on infants, toddlers, children or
persons who cannot express themselves.
• DO NOT adjust medication based on readings from this blood
pressure monitor. Take medication as prescribed by your
physician. ONLY a physician is qualified to diagnose and treat
high blood pressure.
• DO NOT use this monitor on an injured wrist or a wrist under
medical treatment.
• DO NOT apply the wrist cuff on your wrist while on an
intravenous drip or blood transfusion.
• DO NOT use this monitor in areas containing high frequency
(HF) surgical equipment, magnetic resonance imaging (MRI)
equipment, computerized tomography (CT) scanners. This
may result in incorrect operation of the monitor and/or cause
an inaccurate reading.
• DO NOT use this monitor in oxygen rich environments or near
flammable gas.
• Consult with your physician before using this monitor if you
have common arrhythmias such as atrial or ventricular
premature beats or atrial fibrillation; arterial sclerosis; poor
perfusion; diabetes; pregnancy; pre-eclampsia or renal
disease. NOTE that any of these conditions in addition to
patient motion, trembling, or shivering may affect the
measurement reading.
• NEVER diagnose or treat yourself based on your readings.
ALWAYS consult with your physician.
• This product contains small parts that may cause a choking
hazard if swallowed by infants, toddlers or children.
Data Transmission
• This product emits radio frequencies (RF) in the 2.4 GHz
band. DO NOT use this product in locations where RF is
restricted, such as on an aircraft or in hospitals. Turn off the
Bluetooth feature in this monitor and remove batteries when
in RF restricted areas.
Battery Handling and Usage
• Keep batteries out of the reach of infants, toddlers or
children.
Caution
• Stop using this monitor and consult with your physician if
you experience skin irritation or discomfort.
Indicates a potentially hazardous situation
which, if not avoided, could result in death or
serious injury.
Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderate injury to the user or patient, or cause
damage to the equipment or other property.
IM-HEM-6232T-E-EN-01-09/2017
2829393-8A
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Omron RS7 Intelli IT
Summary of Contents for Omron RS7 Intelli IT
-
Page 1: Table Of Contents
10. Limited Warranty 11. Guidance and Manufacturer’s Declaration Introduction Thank you for purchasing the RS7 Intelli IT Automatic Wrist Blood Pressure Monitor. This blood pressure monitor is to be worn on your wrist. This blood pressure monitor uses the oscillometric method of blood pressure measurement. -
Page 2: Data Transmission
Taking a measurement after an extreme temperature change could lead to an inaccurate reading. OMRON recommends waiting for approximately 2 hours for the monitor to warm up or cool down when the monitor is used in an environment within the temperature specified as operating conditions after it is stored either at the maximum or at the minimum storage temperature. -
Page 3: Know Your Monitor
1. Know Your Monitor Contents Monitor, 2 “AAA” alkaline batteries, storage case, instruction manual, setup instructions Monitor a. Wrist cuff (Wrist circumference 13.5 cm to 21.5 cm) b. Display c. [User ID selection] switch d. [Memory] button e. [Morning average] button f. -
Page 4: Preparation
Positioning indicator Your monitor has a built-in advanced positioning sensor that is used as an aid in determining if the monitor is at the correct height. The “ ” symbol lights in blue when your monitor is at the correct position relative to your heart during a measurement. -
Page 5: Setting The Date And Time
• As soon as batteries are correctly installed, the year flashes on the display of your monitor. • The date and time will automatically be set when the monitor is paired with “OMRON connect” app. Refer to section 4.1. Press the button once to adjust the year. -
Page 6: Sitting Correctly
Wrap the wrist cuff firmly around your wrist. Do not apply over clothing. Check to make sure that there is no gap between your wrist and the cuff. Note • Make sure the wrist cuff does not cover the protruding part of the wrist bone on the outside of your wrist. -
Page 7: Using Your Monitor Without A Smart Device
3. Using Your Monitor without a Smart Device Taking a Measurement You can use your monitor without pairing to a smart device. To pair your monitor with a smart device, refer to section 4.1. Note • To stop the measurement, press the [START/STOP] button once to deflate the wrist cuff. -
Page 8: Using Your Monitor With A Smart Device
• Please be aware that OMRON will not be responsible for the loss of data and/or information in the app. • “OMRON connect” is the only app that we recommend to use with your monitor to transfer data correctly. -
Page 9: Using Memory Function
5. Using Memory Function Your monitor automatically stores up to 100 readings per user. Viewing the Readings Stored in Memory Select your user ID. Press the button. Alternating date/time display The Memory number appears for one second before the pulse rate is displayed. -
Page 10: Other Settings
“Er” still appears, malfunctioned. contact your OMRON appears retail outlet or distributor. Follow the instructions shown in the “OMRON The monitor cannot connect” app. If the connect to a smart “Err” symbol still device or transmit data appears after checking correctly. -
Page 11: Maintenance
• It is generally recommended to have the unit inspected every two years to ensure correct functioning and accuracy. Please consult your authorised OMRON dealer or the OMRON Customer Service at the address given on the packaging or attached literature. -
Page 12: Specifications
This product is warranted by OMRON for a period of 3 years after the date of purchase. The proper construction, workmanship and materials of this product is warranted by OMRON. During this period of warranty OMRON will, without charge for labour or parts, repair or replace the defect product or any defective parts. -
Page 13: Guidance And Manufacturer's Declaration
• The full text of the EU declaration of conformity is available at the following internet address: www.omron-healthcare.com • This OMRON product is produced under the strict quality system of OMRON HEALTHCARE Co., Ltd., Japan. The Core component for OMRON blood pressure monitors, which is the Pressure Sensor, is produced in Japan. - Page 14 ® The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by OMRON HEALTHCARE Co., Ltd. is under license. Other trademarks and trade names are those of their respective owners.
