- Page 1 User's Manual Nano Soft Bathroom Softeners...
-
Page 2: Table Of Contents
CONTENTS Page No. Introduction ------------------------------------------------------------------------ 03 Important Instructions ------------------------------------------------------------- 04 Component identication ---------------------------------------------------------- 05 Process and features -------------------------------------------------------------- Know your Nano Soft -------------------------------------------------------------- 07 To 08 Caution & Inlet water condition--------------------------------------------------- 09 Technical specications ------------------------------------------------------------- 10 Installation Location, electrical & plumbing requirement ------------------ How to install Nano soft? ----------------------------------------------------------- 12 To 14 Dos and don'ts ------------------------------------------------------------------------ 15 Unpacking checklist ----------------------------------------------------------------- 16... -
Page 3: Introduction
INTRODUCTION The new generation Softenizers -Zero B Nano Soft are automatic water conditioners from Ion Exchange India Limited meant to serve our customers with an experience of enhanced performance, user friendliness and assurance on the quality of treated water. The primary function of the Zero B Nano Soft is to condition the incoming hard water... -
Page 4: Important Instructions
IMPORTANT INSTRUCTIONS ·Without reading and truly understanding the contents of this user manual, please do not perform any operation on the control valve. ·After inactivation for a long period of time, initiate a recharge cycle, Then turn on the tap for several minutes before resuming normal use. ·If water usage or hardness of the raw water increases (comparing to the normal usage), the frequency of regeneration should correspondingly increase. -
Page 5: Component IdentiCation
COMPONENT IDENTIFICATION 1.Glass panel 2. Front shell 3. Display board 4. Middle shell 5. Water leakage monitoring sensor 6. Salt level monitoring sensor 7. Brine tank 8. Bottom mounting clamps 9. Rear shell 10. Mounting clamps 11. Brine well and brine oat valve 12. -
Page 6: Process And Features
PROCESS AND FEATURES PRINCIPLE OF WORKING 1.The softener converts the hard water into soft water using an Ion exchange process 2.In the softening cycle, the softener resin media exchanges the hard ions of calcium and magnesium for sodium ions 3.When the softener resin is exhausted, the auto valve gives command for recharging... -
Page 7: Special Features
SPECIAL FEATURES ·Corrosion proof salt tanks for longer life ·Elegant and compact designed ·Fully automatic microprocessor controlling operation ·Can be easily installed on wall and ready to use ·Automatic OBR calculation and settings ·Indication- time to add salt ·Leakage protection indicator ·Display –... -
Page 8: Know Your Nano Soft
KNOW YOUR NANO SOFT 1.The display screen This display screen communicates the status of the softenizer. Description a.Current time, remaining soft water output (L), ow rate of outlet (LPM), etc. will be displayed in display area. b.Regeneration indicator: When the softener turns to regeneration status, this indicator gets activated. - Page 9 2. How to recharge the softener manually? The option of manual regeneration is also available. This forced regeneration is recommended under following conditions 1.Power failure during auto recharging (If you have doubts of an incomplete recharging) 2.Unit is stagnant for more than 8 days or water quality is not desirable. 3.Be Aware ·Based on the set program by the technician during installation , the auto softener gets regenerated midnight using the raw water...
- Page 10 5.Where the softener can be used? ·It can be an attachment to geysers, enhancing life of Geysers and also power saving, ·It can be used to prevent the chocking of shower panel, taps and ttings due to hardness. & scale depositions ·It can be a used as an attachment for the washing machines.
- Page 11 CAUTION For drinking - The Zero B Nano soft only conditions the water for bathing, washing and laundering. This water may not be microbially safe for direct drinking. Always use a point of use water purier for drinking. Please take advise from our visiting personnel. For replacement of media after expiry –...
-
Page 12: Technical SpeciCations
TECHNICAL SPECIFICATIONS Parameter Max. treated water ow rate 600LPH (10LPM) Resin volume 4.8Liter Treated water output per recharge @500 Hardness 300Liter @800 Hardness 180Liter Salt required per recharge 0.62Kg Salt loading capacity 2.5Kg (for four regenerations) Regeneration time 2Hours 34Minutes (including 2hours soaking time) Inlet pressure 1.5 –... -
Page 13: Installation Location
INSTALLATION LOCATION ·To condition the hard water supply at home, install the water softener close to main water supply of Inlet. ·A nearby drain is required to carry away regeneration discharge (drain) water. Use a oor drain, laundry tub, sump, Bucket or any other options. ·The location chosen for the installation must have enough space for the system itself, its accessories and connections and also for proper maintenance. -
Page 14: How To Install Nano Soft
HOW TO INSTALL THE NANO SOFT? Zero B Nano soft must be installed by the authorized service technician as per recommended procedures for Softener assembly and Auto valve programming. The softener has to be installed such that the salt lling door of the softener is not more than 5.5 –... - Page 15 ·Use the template for mark the screw xing position on the wall and drill the holes with 8mm drill at the positions marked on the wall. The two stainless steel brackets should be on the same horizontal line (As shown in Fig.2). ·Fix a pair of SS Clamps using screws to hold the Nano soft.
- Page 16 ·Hang the softener on the pair of xed SS clamps, and move the softener down against the wall to ensure that it is hung up properly. (As shown in Fig.4) Fig.4 ·After the xing of machine mark the bottom SS support clamp hole and drill the hole using drill machine.
- Page 17 START UP OF THE SOFTENER 1. Ensure that the softener is installed by the authorized service technician as per recommended procedures for Softener assembly and Auto valve programming 2. Ensure that sufcient inlet water supply and pressure is available as specied. 3.
-
Page 18: Dos And Don'ts
10. If manual regeneration button switch is locked, press and hold both Up and Down buttons for 5 seconds to unlock the buttons. 11. Before starting the service operation, manually trigger the softener in Backwash mode for 5Min. and then put the valve by pressing manual button in lling mode for 7Min to ll the brine tank for regeneration. -
Page 19: Unpacking Checklist
UNPACKING CHECK LIST ·Nano soft assembled unit – 1Nos. ·SMPS for AV -1Nos. ·Template – 1Nos. ·SS clamps for wall mounting – 3Nos ·CSK screws – 6Nos ·Pan Head tapping screws – 3Nos. ·½” Nylon white tubing for Inlet outlet – 4Mtr. ·¼”... -
Page 20: Troubleshooting
TROUBLE-SHOOTING:- Problem Cause Correction 1.Softener fails to activate the trigger for a. Electrical service to unit has been interrupted a. Assure permanent electrical service regeneration b. Service time set is incorrect or zero. (check fuse, plug, switch, etc.) c. Controller is defective. b. - Page 21 Unit Serial No. : ........NANO SOFT Product Serial No. : ......................................Email ID : .............. Company's Stamp & Signature...
- Page 22 to the buyer at actual.
- Page 23 the company's vision: "To be a leader in our business which is so vital to people's lives and +91 77560 43064 Mumbai 400011. | Tel. : 022-278812345 | 022-2068486848...
