- Page 1 USER MANUAL INDOOR STATION WWW.GLOBAL-LEELEN.COM XIAMEN LEELEN TECHNOLOGY CO.,LTD...
-
Page 2: Foreword
This file will be updated as the device is optimized or upgraded.The latest user manual for the device can be downloaded from LEELEN website. (https://www.global-leelen.com). Please use the manual with the guidance and assistance of professionals trained in supporting the production. - Page 3 INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved ・Do not disassemble or modify the product. Refer servicing to an authorised service centre when service is required. Disassembling the product or manipulating the product in a way not described in the documentation may expose you to dangerous voltages and other risks.
- Page 4 INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved ・The product should not be exposed to direct sunlight. ・The product should be kept away from heat sources such as radiators, cookers, etc. It should not be placed in rooms where the temperature is less than 0 °C or greater than 40 °C. Damp basements should also be avoided.
-
Page 5: Table Of Contents
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved Content Foreword ............................. 2 Content ..............................5 1. Product Overview ........................... 7 2. Introduction to Menu ........................8 3. Access the Device ..........................9 3.1 WIFI Setting ...........................9 3.2 Call Settings .........................11 3.2.1 Add Contact ...................... - Page 6 INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved 4.1.2 APP register ......................34 4.2 APP bind and Unbind ......................36 4.2.1 APP bind ........................36 4.2.2 APP and device unbind ....................37 4.3 APP account management ....................38 4.3.1 Home switch ......................39 4.3.2 Family management ....................
-
Page 7: Product Overview
Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved 1.Product Overview V39 indoor station is a 10.1 inch Android digital HD indoor intercom. It can realize audio and video communication with outdoor station, unlock, monitor outdoor station & IPC and other functions. -
Page 8: Introduction To Menu
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved 2.Introduction to Menu Status: The upper left corner of the interface displays some working status of device, including Security warning status, WIFI status, LAN status, APP binding status, etc. If the operating status is not normal, the icon is displayed with a Red Cross or an exclamation mark. -
Page 9: Access The Device
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved 3.Access the Device 3.1 WIFI Setting If the network is not connected, you can set the LAN or WIFI as required. Usually, the LAN is configured by engineers. For details about how to configure the LAN, Please look at the configuration manual. - Page 10 INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved Before connecting, you can tap on the right icon of any Wifi, and turn on “advanced settings’ to set the parameters of the corresponding WIFI . The system has two ways as follows.
-
Page 11: Call Settings
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved 3.2 Call Settings 3.2.1 Add Contact Tap” Video Intercom” -> upper right corner -> . Enter the user name and device number in the edit box, and tap Complete. If the editing content is wrong, you can tap Edit to modify it. - Page 12 INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved A.digit dialing You can enter the number in the digital key area and click to call. If you want to call the management center, click . The center number is set by the engineering personnel. For details, refer to the project configuration manual.
-
Page 13: Receive Call
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved Note: 1. Ensure that the number of buildings in the cell is less than or equal to 6, and that the first four digits of the outdoor station number are 0001 to 0006. -
Page 14: Call Records
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved 3.2.4 Call Records You can query intercom records in either of the following ways. One way, you can tap Intercom Logs in the main interface to enter the Intercom record query. The second way is to tap Video Intercom, and then tap to enter the Intercom record query. -
Page 15: Blocklist
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved Note: 1. A total of 100 intercom records can be stored. Capture pictures up to 50. One intercom can capture up to 5 and messages up to 10. 2. A red dot before an intercom record indicates that the intercom record is a missed call. The red arrow indicates that the call is hung up, and the blue arrow indicates that the call enters the intercom phase. -
Page 16: Monitoring Settings
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved Note:You can add a maximum of 50 blocklist entries. 3.3 Monitoring Settings The user can use the indoor station to monitor the IPC or outdoor station. 3.3.1 Add IPC Tap Video Survey on the home page and then tap and New monitoring to add.Th... -
Page 17: Monitor Ipc And Outdoor Station
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved 3.3.2 Monitor IPC and outdoor station Tap Video Survey on the home page and tap to monitor,At this time,you can unlock, record video and capture the picture. E-mail:export@leelen.com Add:LEELEN Building.780 Tieshan Rd.,Jimei District,Xiamen Tel:(0086)592-6157677 Web:www.global-leelen.com... -
Page 18: Monitor Records
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved 3.3.3 Monitor Records The user tap to query the monitor record, includes the video name of outdoor station/IPC, device type, monitoring duration, unlock or not, video recording and captures. You can click Delete to delete records. -
Page 19: Message
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved 3.4 Message Users can edit, send, and receive messages on the indoor station. 3.4.1 Message Edit You can edit and send information on Message on the home screen, click New Message ->... -
Page 20: Arm/Disarm
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved Note:The message records can store 100 records. If the number of records exceeds this number, the previous record information will be erased. 3.5 Arm/Disarm 3.5.1 Set Arm Mode Tap “Security Management”, the Users can turn on the alarm according to the layout of the defense area sensor at home.There are three states that can be set, including away mode... -
Page 21: Alarm Process
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved 3.5.2 Alarm process When someone triggers the sensor of the defense area at home, the alarm bell will be issued and the alarm pop-up window will be displayed on the interface. At this time, the user can immediately take corresponding safety precautions and eliminate the alarm on the indoor station. -
Page 22: Arm Status Check
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved 3.5.3 Arm status check Users tap to view the status of home defense area settings. There are detailed information, including defense zone number, zone name, detector type, zone status and alarm type. The setting of parameters related to these alarm areas or sensors is the content set by engineers. -
Page 23: Arming Records
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved 3.5.4 Arming Records User tap Security Management in the home page to query information about alarm records, tap All to check all alarm records and tap Not Viewed means that have been missed. - Page 24 INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved E-mail:export@leelen.com Add:LEELEN Building.780 Tieshan Rd.,Jimei District,Xiamen Tel:(0086)592-6157677 Web:www.global-leelen.com IoT Industry Base:1019 Wanjiachun Rd.,Xiang’an District,Xiamen Fax:(0086)592-615767...
-
Page 25: Sos
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved 3.6 SOS 3.6.1 SOS emergency call In case of an emergency, users can tap SOS for 2S to send emergency call to the management machine in the property center. Property manager received the information, immediately make the corresponding event processing verification. -
Page 26: Privacy
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved 3.6.2 Privacy When user wants to be free from indoor station ringtones during a period of time. You can set the Privacy mode on the home page . When the user wants the indoor station... -
Page 27: Language Settings
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved network. For example, the NTP address of Australia is ntp.cs.mu.oz.au. After setting the NTP address, users can check ”Automatically determined date and time,time to use the ntp net time”... -
Page 28: Display Settings
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved Tips: Switching the language will restart the application 3.7.3 Display settings The user tap Settings->User Settings -> Display and adjust the brightness of the home page on the device. You can tap Brightness and adjust the brightness through the length bar. Next, the screen saver time can be set to 15 seconds, 30 seconds, 1 minutes, 2 minutes, 5 minutes, 10 minutes, 30 minutes and never. -
Page 29: Sound Settings
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved 3.7.4 Sound settings The user tap Settings->User Settings->Sound to set the volume, you can tap Volume Setting to set the volume in 3 scenarios: ringing volume, call volume and prompt volume. The ringtone volume has 10 levels to choose, from 0% to 100%. -
Page 30: Call Transfer
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved 3.7.5 Call Transfer If the customer wants to be called by his own indoor station, but misses it accidentally, he can set up automatic transfer to other indoor station or guard station. The user tap Settings->User Settings call->... -
Page 31: Device Information
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved 3.7.6 Device information You tap Settings-> About The Equipment,to query the software and hardware version information,device No., Device IP, Android Version, Kernel Version and MAC address. E-mail:export@leelen.com Add:LEELEN Building.780 Tieshan Rd.,Jimei District,Xiamen Tel:(0086)592-6157677 Web:www.global-leelen.com... -
Page 32: Password Settings
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved 3.7.7 Password settings The password has two kinds of password, one is about Unlock Password Settings, another is the User Password Settings (Default 123456). A. Unlock password The user tap Setting ->User Settings->Unlock Code. On the screen, you can set a lock password with a number of 6. -
Page 33: Restart
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved 3.7.8 Restart User can restart the device on this page.User can tap Settings->User Settings->Restart-> ,the device will into restart. E-mail:export@leelen.com Add:LEELEN Building.780 Tieshan Rd.,Jimei District,Xiamen Tel:(0086)592-6157677 Web:www.global-leelen.com IoT Industry Base:1019 Wanjiachun Rd.,Xiang’an District,Xiamen... -
Page 34: Remote Control App
4.1 APP download and register 4.1.1 APP download Users can download Leelen APP (Intercom-Technology for life) from the APP Store or Google Play. 4.1.2 APP register User download the APP, and you should register the account, follow the step: 1. - Page 35 INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved Tap region as the country->enter E-mail as the account->tap Get code to gain the Verification code->enter code->enter password->enter password again->Check Privacy Statement->tap Sign 2. Come back the login page，enter the country, account, password, tap Log in, to go to home page;...
-
Page 36: App Bind And Unbind
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved 4.2 APP bind and Unbind 4.2.1 APP bind 1) User open the indoor station and tap on the top right corner of home page .Note: When you open the QR code, it display: Tuya Cloud platform is not connected, please connect. Or the network is not connected, please connect. -
Page 37: App And Device Unbind
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved 4.2.2 APP and device unbind There are two way of unbind from APP and device.you can unbind APP on the indoor station or 4.2.2.1 APP unbind User tap More->Family management->Account of APP->tap ，... -
Page 38: App Account Management
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved Note： Do not remove the account easily. If the main account should no longer follow the home, and other accounts are still under the current home, you can remove the permission of the main account to other members. -
Page 39: Home Switch
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved 4.3.1 Home switch The same account can be bound to 20 homes at the same time. The user can tap More to select the home. After switch the home, all the following operations are carried out for the current home, except for the call ring. -
Page 40: Family Management
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved Family management 4.3.2 4.3.2.1 Invite new member User tap More->Family management->Invite new members,In the Invite new members, enter the new account ,tap Invite.At this point, the sub-account can refresh the following table by pulling up and down on the main interface, and the device under the home page can appear. -
Page 41: Remove Account
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved 4.3.2.2 Remove account When the account is the main account, if the account is removed, all accounts will be r emoved from this home. Therefore, if you want to make sure that everyone exits the h ome, you can directly remove the main account and all sub-accounts. -
Page 42: Cancel Account
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved 4.3.4 Cancel account User tap More->Cancel account->Agree to the statement->OK，to cancel account. When a user logs out of an account, the protection period of the account is 7 days. If the user does not use the account within 7 days, the account is permanently logged out. -
Page 43: App Function
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved 4.4 APP function 4.4.1 Monitoring User tap My device-> ,The monitoring page is displayed,you can unlock, hang up the monitor, capture a picture, transfer the monitor to an intercom, or switch devices. -
Page 44: Intercom
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved Note:The indoor station in a home can monitor up to four devices(Monitor all outdoor station first). 4.4.2 Intercom When a visitor calls the indoor station, the APP bound to the corresponding home will also receive the ringing push. -
Page 45: Records Query
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved 4.4.3 Records query 4.4.3.1 Intercom records User can tap Intercom Record, to query the intercom records in this home, included incoming number, outgoing number, intercom time. 4.4.3.2 Alarm records User can tap Alarm Record to query the alarm records,included alarm time、... -
Page 46: Other Function
INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved 4.4.4 Other function 4.4.4.1 Change ringtone User can tap More->Ringtone Settings,to choose your ringtone,included Ring1-Ring7. 4.4.4.2 Change Password User tap More->Change Password,In this page,enter country 、 account 、 gain verification 、... - Page 47 INDOOR STATION Copyright © 2023 Xiamen Leelen Technology Co.,Ltd.All Rights Reserved password.After the password is successfully changed, you need to return to the login page and log in to the account and password again. E-mail:export@leelen.com Add:LEELEN Building.780 Tieshan Rd.,Jimei District,Xiamen Tel:(0086)592-6157677 Web:www.global-leelen.com...
-
Page 48: Faq
A1: You can use the display screen to get the IP information, just check the IP address at Settings > About the Equipment. Q2: Can I communicate other indoor monitor with indoor monitor? A2: Leelen device can communicate with each other, no matter it is indoor monitor, outdoor station. Q3: What is user password? A3:The default of password is 123456.
