Summary of Contents for Pentashot GLS 17
- Page 2 Operating Instructions GLS 17...
-
Page 3: Table Of Contents
Safety notes and important information ............Description ......................... Preparing laser simulator for use ................Technical data ......................... Warranty ..........................Storage ..........................Spare parts ........................ -
Page 4: Safety Notes And Important Information
Safety notes and important information Keep the emitters clean by wiping the dust out of them with a dry cloth. Never use any cleaning agents, solvents or chemical preparations. Do not push the emissive hole optic with any object. Regularly check the condition of the battery inside the simulator body to make sure it does not corrode or leak. -
Page 5: Description
LASER RADIATION DO NOT LOOK DIRECTLY INTO THE LASER BEAM! CLASS I. LASER DEVICE Description 1 — Front sights 2 — Battery cover / battery 3 — Battery status LED indicator 4 — Loading lever 5 — Rear sights 6 — Ambidextrous grip 7 —... -
Page 6: Preparing Laser Simulator For Use
It is intended for laser beam shooting initiated by a trigger. The GLS 17 laser simulator employs the FLPM20 laser module with a 15.6 ms code as an emitter. The code is fully compatible with the International Modern Pentathlon Union... -
Page 7: Switching Off
After the battery test, the LED light remains constantly blue to indicate the laser is on and ready for use. The LED fl ashing continuously blue means the battery is discharged and it should be immediately replaced. SWITCHING OFF The laser container will switch off approximately 20 minutes after the last shot. In case you need to switch it off immediately, remove the battery from the simulator body. - Page 8 Turning the screw (9a) counterclockwise Turning the screw (9b) clockwise Turning the screw (9b) counterclockwise laser dot moves to the left laser dot moves to the right laser dot goes upward laser dot goes downward IMPORTANT: The movement of the adjusting screws must be very small. One turn of the adjusting screw moves the laser dot by approximately 20 cm at a 10m distance.
- Page 9 SETTING THE GRIP ANGLE (ONLY ANATOMICAL GRIP) Use the supplied hexagonal key to loosen the small screw on the simulator grip bottom. Set a new position of the grip and fi x it by tightening the small screw.
- Page 10 BATERRY REPLACEMENT When the LED indicator fl ashes once or is constantly fl ashing, replace the battery. Press your thumbes on the places marked “Push” and lower the battery cover until it is completely removed. Remove the discharged battery using the ribbon and insert a new one (AAA 1,5V). Pay attention to the correct polarity of battery! Reinstall the cover (A).
-
Page 11: Update Function
Only the manufacturer has access to the laser simulator software. Technical data Dimensions 355mm x 150mm x 50mm Simulator type single-acting, laser 650 g lighter version GLS 17 “K” Weight 780 g with universal handle 830 g with anatomical handle... - Page 12 Shooting distance From 3 m to 10 m Laser class I. (per EN 60825-1:2014) No. 1140735 (Electrotechnical Testing Institute, Laser class certifi cation Czech Republic) Laser module FLPM20 Laser signal 15.6 ms UIPM laser signal Wavelength 650 nm Diameter of laser beam 4 mm ±...
-
Page 13: Warranty
It is forbidden to open or modify the laser simulator, with the exception of changing the battery or grip. The Laser beam parameters can only be changed by the manufacturer or an authorized person. The simulator owner must confi rm his consent to the change in writing. The manufacturer does not assume responsibility for any damage that would arise from the change. -
Page 14: Storage
Order replacement parts by e-mail from business@pentashot.eu or from PENTASHOT partners and dealers. A list of them can be found at www.pentashot.eu. Only the manufacturer or an authorized individual has the right to replace the simulator’s main parts (optics and... - Page 15 Disposal Once the laser simulator ends its lifetime, do not dispose of it along with other household waste. Take it to a waste disposal site of raw materials or let it be disposed at a specialized company capable of recycling such a material.
