STEREO DVD CASSETTE DECK RECEIVER
XR-A9700DV
XR-VS100D
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model
Type
XR-A9700DV XR-VS100D
KUCXJ
DBXJ
-
DLXJ/NC
-
DDXJ/RA
-
DDXJ/RB
-
CONTENTS
1. SAFETY INFORMATION ...................................... 2
4. PCB CONNECTION DIAGRAM .......................... 42
5. PCB PARTS LIST ............................................... 60
6. ADJUSTMENT .................................................... 69
PIONEER CORPORATION
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER ELECTRONIC (EUROPE) N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
c
PIONEER CORPORATION 1999
• XR-A9700DV
Power Requirement
-
AC120V
AC110-127V/220-230V/240V
AC110-127V/220-230V/240V
AC110-127V/220-230V/240V
AC110-127V/220-230V/240V
4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
Region
The voltage can be converted by
No.
the following method.
1
3
With the voltage selector
3
With the voltage selector
1
With the voltage selector
2
With the voltage selector
7. GENERAL INFORMATION ................................ 76
7.1 DIAGNOSIS .................................................. 76
7.1.2 TROUBLE SHOOTING .......................... 78
7.1.3 ERROR CODE ....................................... 79
7.1.4 DISASSEMBLY ...................................... 83
7.1.5 POWER ON SEQUENCE ...................... 89
7.2 PARTS .......................................................... 91
7.2.1 IC ............................................................ 91
7.2.2 DISPLAY ............................................... 109
T - IZK OCT. 1999 Printed in Japan
ORDER NO.
RRV2221
