Nikon Z 9
Repair Manual
Ver.1.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the Z 9 and is the answer not in the manual?

Questions and answers

Related Manuals for Nikon Z 9

Summary of Contents for Nikon Z 9

  • Page 1 Nikon Z 9 Repair Manual Ver.1.0...

  • Page 2: Table Of Contents

    Notations used in this Repair Manual ................2 Safety precautions ......................4 Disclaimer of warranties and limitation of damages .............6 Notification ........................6 Service tools Nikon service tools .......................7 Standard service tools ....................7 Illustrated Service Parts List Parts Removal and Replacement Procedures Before disassembling the Product ................30 During the repairing ....................30...
  • Page 3 TOP COVER FPC UNIT ........................61 TOP LCD UNIT..........................63 SHOE MOLD UNIT .......................... 69 MAIN SW DIAL ..........................71 GPS PCB ............................72 SYNC TERMINAL ..........................73 TOP COVER UNIT ........................... 74 EYELET ............................76 EYEPIECE BLOCK UNIT ......................... 77 EVF PANEL UNIT ..........................
  • Page 4 TRIPOD BASE ..........................193 V-POSITION SUB COMMAND DIAL UNIT ................... 196 GRIP RUBBER UNIT ........................202 MAIN PCB UNIT ..........................207 TOP COVER UNIT ......................... 213 EVF UNIT ............................215 REAR COVER UNIT ........................217 NAME PLATE ..........................219 RUBBER CAP ..........................219 NECK-STRAP RING ........................

  • Page 5: Introduction

    ● For purposes of this Repair Manual, "Nikon" means Nikon Corporation, and all direct and indirect affiliated companies, including without limitation, Nikon Inc. ● This Repair Manual is solely intended for Nikon products imported into and sold in the Unit- ed States by Nikon Inc.

  • Page 6: Notations Used In This Repair Manual

    For the camera serial numbers, refer to the documentation provided with the camera (the Reference Guide). ● The serial number may be required when you contact Nikon with CAUTION regards to the Product. Make sure not to lose the serial numbered...
  • Page 7 Read this first ● No part of this Repair Manual may be reproduced, transmitted, transcribed, stored in a re- trieval system, or translated into any language in any form, by any means, without Nikon's prior written permission. ● Illustrations shown in this Repair Manual may differ from the actual Product.

  • Page 8: Safety Precautions

    Product from being able to be attached and will cause problems when shooting. In such cases, accurate adjustments and repair will be required and it is recom- mended that you contact Nikon for service repairs. ● If the Product contains a lithium-ion battery, then inappropriate use, transportation, recycling, reuse, or disposal of the lithium-ion battery may cause a fire, explosion or other damage or injury.
  • Page 9 Safety policy and procedure ● All Product safety issues must be managed according to the following points. ● If any of the following conditions are visible, stop repairing the Product and contact Nikon's customer service at www.nikonproductsupport.com. – There are burnt or melted components or traces on the outside of the Product, or other heat-related damage (including scorching on charging terminals or other connection terminals).

  • Page 10: Disclaimer Of Warranties And Limitation Of Damages

    ● All the information, descriptions, materials, and products provided on or in connection with this Repair Manual are provided by Nikon on an "as-is basis" and in "the form that can only be provided if possible'' unless otherwise expressly specified in writing by Nikon. With re-...

  • Page 11: Service Tools

    This section shows the tools used to repair products. The standard service tools are commercially available and can be purchased from third party retailers. Nikon hereby disclaims all responsibility and liability for any tools or other items purchased from third party retailers.

  • Page 12: Illustrated Service Parts List

    Illustrated Service Parts List ● The parts marked in gray in the illustration cannot be replaced in- dividually as replacing them will affect the optical performance. If IMPORTANT you need to replace these parts, use the CAMERA BODY UNIT (143VR). ●...
  • Page 13 132CE 1A-17050FD2 x5 132CY 132CF 132CB 132C9 x2 137G8 132C8 1334P 132CA x5 1A-17035FD2 x5 132CC 132CZ 132CD 132DC...
  • Page 14 1A-17040FD2 1A-17040FD2 139JL 139HY 139JM 139JE 139JJ 1264Y x2 139JK x2 1A-17030FD2 133VJ...
  • Page 15 133VJ x2 12H46 12H4B x2 12H46 12S07 x2 12S07 133TY x4 12H48 x2 135AH 127MU 134XU H1-17060FD2 12H45 x5...
  • Page 16 1350K 133MP-A100HZ 138YS-A110A2 US 30- 12G7R 135HC 1334K 1K685-799 x2 1K100-035 x2 133TP x2 135AD 133UA 122TJ x4 12H45 x4 139PE 135AC 133TG x6 1K241-775 6A-17035FD2 x2 1K010-593 x4 137EM 135AF 133PX...
  • Page 17 138T6 138T5 1333N 1333L 134YZ 138F5 133TY x4 1E-17020FD2 x3 1333P 133UF 133R0 1333K A2-20035FA x4 138T8 x2 138F6 x2...
  • Page 18 6A-17040FD2 135A1 6A-17040FD2 x2 138T7 6A-17040FD2 x2 1332L A2-20030FD2 x2...
  • Page 19 1359B 1K201-276 1K116-705 11Z8J 133LR 134J4 12P2N 133M9 1K118-179 11D7U 6A-14030FD2 13A0G 133MA x2 134XS 138WJ x2 134XV 1381U 1324V 12R6D x4 1B002-504 134J9 A1-14020FD2 133JU 139GM 134LE 6A-17040FD2 x4 134XT 138WZ 135Y3 1B002-875 134XX 134J1 x2 6E-17030FD2 x2 S1-01200SX 134J0 x2 1K241-679 6A-14030FD2...
  • Page 20 1359B 1311Z 12H9D 1358V 11X05 1324K 134Y4 1K010-592 134J2 133JS 134HU 134J3 1396B x2 134J6 134P2 6A-17040FD2 x4 1331C x4 134HY 6A-17040FD2 134MH 134WY 6A-17040FD2 x4 1K010-592...
  • Page 21 134ZX G1-14025FA x2 1359B 11J9S 133JT 134G0 1K241-465 G1-14025FA 133LZ 11U6U 134FU 6A-17040FD2 134XW 134G5 1380K 1K010-585 139JR 1357F 6A-17040FD2 x2 133LP 1358Z 6A-17040FD2 x8 134FV 139JH 6A-17040FD2 6A-17040FD2 x2 6A-17040FD2 1323S 1357G 6A-17040FD2 x2 1357H 6A-17040FD2 x2...
  • Page 22 138X6 133MB 133L3-A0Z96S 1356B-A0V9J5 1K220-676 133MC 139PC 139HT 133LC T1-01500SX1 133KL 133M4 133KJ 6A-17040FD2 x4 133LB 1356Y 133KK 1357A 133KE 6A-17040FD2 x2 6A-17040FD2 x2 1357B 133LA...
  • Page 23 139PD-A0Z22E 138F3 133TM 133J8 138F4 137KB 133TN 128C2 133UE 139MK 137KC 11H76 133J8 1355Y 133U2 11W3P 6E-17030FD2 x2 12R6D x13 134HZ 133JJ 133U9 x3 134LE x2 133TW 133U3 133TJ 137XE 133SH-A0X0HS 6A-17035FD2 x3 133TK 133U5 133TL 1354B 12U6P x3...
  • Page 24 6A-17045FD2 x2 133TR x2 133TS 135Y1 1264C 12S27 6A-14025FA x2 1277C 139GY 133V7 137LN 133VA 122FN 133V6 6A-17045FD2 x3 128C2 133TU 139MK 11H76 133VC 133VG 1317S 1276H 139L5 133V2 139L4 x4 133V3 133VE 133TT 133TX 12P75 133U1...
  • Page 25 133UN T2-02300SX1 12H4A x4 133SJ 6E-17030FD2 x2 6A-17035FD2 x2 6E-17030FD2 x2 137G8 133R3 12R79 1355P 133V8 12H4B x6 1355W 133V9 12R79 x2 11W3P 12R79 x2 6E-17040FD2 x2 1132W x2 1350V-A0Z2NW 6E-17030FD2 x4 1276S x2 6A-17035FD2 x3 6E-17030FD2 x3 6E-17030FD2 x4 1334J...
  • Page 26 1350T-A113BT 128C2 135VW 1350S-A10V4F 13A0S 133J4 133HV 133J1 11W3P 133HT-A0Z760 127A4 x6 133J3 133J1 133J2...
  • Page 27 The parts highlighted in purple are not included with the CAMERA BODY UNIT(US) (143VR) 143VR...
  • Page 28 Item code Parts name Q'ty 1132W SUB MULTI-SELECTOR BUTTON UNIT 116JR SPRING 11B2S SHUTTER RELEASE BUTTON 11D7U COLLAR 11H76 HOLDER 11J9S CLICK SPRING 11U6U WASHER 11W3P SPONGE 11X05 HOT SHOE MOLD UNIT 11Z8J SPRING 122FN RUBBER 122TJ RUBBER 1264C SHEET 1264Y SCREW 1276H...
  • Page 29 Item code Parts name Q'ty 132DC INSULATION TAPE 1331C SCREW 1332L BATTERY LOCK PLATE 1333K WATERPROOF RUBBER 1333L SPONGE 1333N SPONGE 1333P SPONGE 1334J HEAT DISSIPATION SHEET 1334K NAME PLATE 1334P SHEET 133HT-A0Z760 TILT UNIT 133HV SPONGE 133J1 MOLD 133J2 MOLD 133J3 DOUBLE STICK TAPE...
  • Page 30 Item code Parts name Q'ty 133TL SPONGE 133TM SPONGE 133TN SPONGE 133TP COPPER FOIL TAPE 133TR TAPE 133TS SPEAKER HOLDER 133TT V-POSITION 3-BUTTON 133TU LAN INDICATOR HOLDER 133TW SPONGE 133TX V-POSITION I BUTTON 133TY SCREW 133U1 V-POSITION AF-ON BUTTON 133U3 SPONGE 133U5 SECURITY LOCK COVER...
  • Page 31 Item code Parts name Q'ty 134XV SPONGE 134XW SPONGE 134XX SPONGE 134Y4 DOUBLE STICK TAPE 134YZ SPONGE 134ZX FOUR LEAF BUTTON UNIT 1350K RUBBER CAP 1350S-A10V4F TFT MONITOR FPC UNIT 1350T-A113BT TFT MONITOR UNIT 1350V-A0Z2NW V-POSITION MAIN COMMAND DIAL UNIT 1354B V-POSITION REAR RUBBER UNIT 1355P...
  • Page 32 Item code Parts name Q'ty 138T6 SPONGE 138T7 SPONGE 138T8 TAPE 138TB SPONGE 138WJ SHEET 138WZ SPONGE 138X6 SPONGE 138YS-A110A2 LICENSE LABEL (US 30-) 1396B SPONGE 139GM SPONGE 139GY LIGHT SHIELDING TAPE 139HT LENS ROOM UNIT 139HY GASKET 139JE CONDUCTIVE TAPE 139JH MOISUTURE ABSORBING SHEET 139JJ...
  • Page 33 Item code Parts name Q'ty 6A-17045FD2 SCREW 6E-17030FD2 SCREW 6E-17040FD2 SCREW A1-14020FD2 SCREW A2-20030FD2 SCREW(ROHS) A2-20035FA SCREW G1-14025FA SCREW H1-17060FD2 SCREW S1-01200SX E-RING T1-01500SX1 CLICK BALL T2-02300SX1 STEEL BALL 1K201-276 RELEASE BUTTON 133U2 TAPE...

  • Page 34: Parts Removal And Replacement Procedures

    Parts Removal and Replace- ment Procedures Before disassembling the Product ● As for the Product powered on by the power switch, before disas- sembling the Product, be sure to check that the Product is powered off and that the battery has been removed. ●...

  • Page 35: Reference Pages For Replacement Procedures By Major Parts

    Reference Pages for Replacement Procedures by Major Parts TOP COVER UNIT Disassembly P.32 - P.40 Assembly P.213 - 221 , P.223 - 224 REAR COVER UNIT Disassembly P.32 - P.37 , P.85 - P.86 , P.93 - P.110 Assembly P.111 - P.135 , P.144 - P.145 , P.217 - P.221 , P.223 - P.224 IF COVER UNIT Disassembly P.32 - P.38...

  • Page 36: Disassembly

    Disassembly 1. External parts CABLE CLIP UNIT CABLE CLIP UNIT (135HC) CABLE CLIP UNIT (135HC) BATTERY COVER UNIT...

  • Page 37: Media Cover Lid Unit

    SCREW BATTERY FIXING (1K010-593)× 4 PLATE UNIT (135AF) PLATE SPRING (133PX) (137EM) Hook spring × 2 SCREW (6A-17035FD2) × 2 SPRING (1K241-775) BATTERY COVER UNIT (139PE) MEDIA COVER LID UNIT MEDIA COVER LID UNIT MEDIA COVER LID (135AC) UNIT (135AC)

  • Page 38: Eyepiece Unit

    EYEPIECE UNIT EYEPIECE UNIT (133MP-A100HZ) EYEPIECE UNIT (133MP-A100HZ) NECK-STRAP RING NECK-STRAP RING COVER (1K685-799) × 2 NECK-STRAP RING (1K100-035) × 2 RUBBER CAP (1350K) NAME PLATE NAME PLATE (1334K)
  • Page 39 SCREW (133TG) × 6 BOTTOM COVER PLATE (133UA) RUBBER (122TJ) × 4 COPPER FOIL TAPE (133TP) × 2...

  • Page 40: Rear Cover Unit

    MEDIA MEDIA COVER UNIT COVER UNIT (135AD) (135AD) SCREW (12H45) × 4 This is covered with DOUBLE STICK TAPE. Apply ethyl alcohol and use a cutter or other fine-tipped tool to remove it. Be careful not to scratch it with the cutter. DIOPTER ADJUSTMENT KNOB (127MU) SCREW (H1-17060FD2)
  • Page 41 SCREW (12S07) × 2 SCREW (12H4B) × 2 SCREW (133VJ) × 2 SCREW (12S07) SCREW (12H45) × 4 SCREW (12H45) × 4 IF COVER UNIT (135AH)

  • Page 42: Evf Unit

    IF COVER UNIT (135AH) EVF UNIT Boss × 2...

  • Page 43: Top Cover Unit

    SPONGE (134XU) TOP COVER UNIT TOP COVER SCREW UNIT (1359B) (133VJ) SCREW (1264Y-A0P3H8) × 2 SCREW (1A-17040FD2) SCREW (1A-17030FD2) TOP COVER UNIT (1359B) SCREW (1A-17040FD2) SCREW SCREW (133VJ) (1264Y-A0P3H8) × 2 SCREW (1A-17030FD2)

  • Page 44: Main Pcb Unit

    TOP COVER UNIT (1359B) SCREW (1A-17040FD2) MAIN PCB UNIT Hook...
  • Page 45 SCREW (1A-17050FD2) × 5 Radiate heat plate SPONGE (132CE) GASKET TAPE (137G8) (132CF) TAPE (132CY)
  • Page 46 MAIN PCB UNIT (139PB) Boss × 2 SHEET (1334P)
  • Page 47 HEAT DISSIPATION SHEET (132CA) × 5 HEAT DISSIPATION SHEET (132CB) HEAT DISSIPATION HEAT DISSIPATION SHEET (132C9) × 2 SHEET (132C8)
  • Page 48 Radiate SCREW heat plate (1A-17035FD2) × 3 Boss × 2 SCREW (1A-17035FD2) SCREW (1A-17035FD2) HEAT DISSIPATION SHEET (132CC) INSULATION TAPE (132DC) HEAT DISSIPATION SHEET SHEET (132CD) (132CZ)

  • Page 49: Shading Unit

    2. Front body SHADING UNIT SPONGE (138TB) IF GRIP UNIT (135A9) Double stick tape...

  • Page 50: Grip Rubber Unit

    GRIP RUBBER UNIT SCREW (6A-17045FD2) SCREW (6A-17035FD2) SCREW (12U6M) V-POSITION SCREW (6A-17035FD2) SCREW (6A-17045FD2) GRIP RUBBER UNIT (135A8) SCREW (12U6M) Double stick tape Double stick tape...
  • Page 51 V-POSITION GRIP RUBBER UNIT (135A8) SCREW (6A-17040FD2) GRIP RUBBER UNIT (135AA) SCREW GRIP RUBBER (6A-17040FD2) UNIT (135AA) × 2 SCREW (6A-17040FD2) × 2 Double Double stick tape stick tape Double Double stick tape stick tape...
  • Page 52 GRIP RUBBER UNIT (135AA) SCREW (6A-17040FD2) × 3 Boss...

  • Page 53: V-Position Sub Command Dial Unit

    SCREW (6A-17045FD2) × 2 V-POSITION Guide × 3 COMMAND DIAL UNIT (135AJ) V-POSITION FPC BLOCK UNIT (135AK) Solder × 3 Boss × 3 V-POSITION SUB COMMAND DIAL V-POSITION FPC BLOCK UNIT (135AJ) UNIT (135AK) V-POSITION SUB COMMAND DIAL UNIT SCREW (6A-17045FD2) ×...
  • Page 54 SPONGE (133SX) SPONGE (133SY) SCREW (6A-14025FA) × 2 V-POSITION CLICK PLATE (12A5D) RELEASE COVER (133SU) RUBBER (1K118-179) Boss × 2...

  • Page 55: Bayonet Mount

    V-POSITION LOCK LEVER MOLD (133T2) SHUTTER RELEASE BUTTON (11B2S) SPRING (116JR) E-RING (S1-01200SX) RUBBER (1K116-705) SHUTTER RELEASE BUTTON (11B2S) BAYONET MOUNT SPONGE (138T7) SCREW (6A-17040FD2) × 2 10 PIN UNIT (135A1) Boss × 2 SCREW (6A-17040FD2)

  • Page 56: Lens Contact Unit

    LENS CONTACT UNIT BATTERY LOCK PLATE (1332L) SCREW (ROHS; A2-20030FD2) × 2 SCREW (133TY) × 4 WATERPROOF RUBBER (1333K)

  • Page 57: Tripod Base

    TRIPOD BASE SPONGE SPONGE (138F6) (138F6) TAPE (138T8) TAPE (138T8) SCREW (1E-17020FD2) × 3 VIDEO BOSS (133UF) SCREW (A2-20035FA) × 4 Bottom plate TRIPOD BASE (133R0)

  • Page 58: Lens Release Button

    LENS RELEASE BUTTON SPONGE (138F5) SPONGE SPONGE (134YZ) (1333L) SPONGE SPONGE (138T5) (138T6) SPONGE (1333P) SPONGE (1333N)

  • Page 59: Top Lcd Window

    3. Top cover TOP LCD WINDOW TOP LCD WINDOW (133JT) DOUBLE STICK TAPE (133JU) This is covered with DOUBLE STICK TAPE. Apply ethyl alcohol and use a cutter or other fine-tipped tool to remove it. Be careful not to scratch it with the cutter. SPONGE (134XW)
  • Page 60 MOISUTURE ABSORBING SHEET (139JH) SCREW (6A-17040FD2) × 2 Radiate heat plate INSULATION TAPE (139JR) Boss × 2...

  • Page 61: Command Dial Unit

    COMMAND DIAL UNIT SCREW (6A-17040FD2) × 4 Boss × 2 COMMAND SUB COMMAND DIAL UNIT DIAL UNIT (1357H) (1357H) Solder × 3 COMMAND DIAL FPC (1323S) MAIN COMMAND DIAL UNIT (1357G) Solder × 3 MAIN COMMAND DIAL UNIT (1357G)

  • Page 62: Mic Fpc Unit

    MIC FPC UNIT SCREW (6A-17040FD2) EVF HOLDING PLATE (133LP) Boss × 2 SCREW (6A-17040FD2) × 2 MIC FPC UNIT (1358Z) Boss × 2 Boss × 4...

  • Page 63: Wi-Fi Cable Holder

    WI-FI CABLE HOLDER WI-FI CABLE HOLDER (134FV) Guide × 3 Guide × 6 SCREW (6A-17040FD2) WI-FI CABLE HOLDER (134FV) WI-FI CABLE HOLDER (134FV) Boss × 2...

  • Page 64: Four Leaf Button Unit

    FOUR LEAF BUTTON UNIT FOUR LEAF BUTTON UNIT (134ZX) SCREW (1K010-585) SCREW (1K010-585) SCREW (G1-14025FA) DRIVE MODE SW BRUSH (1K241-465) WASHER (11U6U) Boss × 2...

  • Page 65: Top Cover Fpc Unit

    SCREW (G1-14025FA) × 2 CLICK SPRING (11J9S) MODE DIAL (134G0) Boss × 2 TOP COVER FPC UNIT TOP COVER FPC UNIT (1357F) Hook SCREW (6A-17040FD2) × 4 TOP COVER FPC UNIT (1357F) Boss × 4...
  • Page 66 SCREW (6A-17040FD2) CHARGE LED WINDOW (134FU) TOP COVER FPC UNIT (1357F) TOP COVER FPC UNIT (1357F) CHARGE LED WINDOW (134FU) SCREW (6A-17040FD2) × 4 tweezers etc. to unlock. TOP COVER FPC UNIT (1357F) Boss × 2...

  • Page 67: Top Lcd Unit

    SPRING (1380K) MODE DIAL LOCK BUTTON (134G5) MONITOR SWITCHING BUTTON (133LZ) TOP LCD UNIT SCREW (1K010-592) Hook spring × 2 SPRING (134WY) SPRING (134WY)
  • Page 68 SCREW (6A-17040FD2) × 4 SCREW (1331C) Solder × 4 SCREW (6A-17040FD2) × 4 TOP LCD UNIT (1358V)
  • Page 69 SHEET (134P2) TOP LCD (1324K) TOP LCD (1324K) DOUBLE STICK TAPE (134Y4)
  • Page 70 SCREW LIGHT SHIELDING SHEET (1K010-592) (134J2) Hook × 2 Boss × 2 LIGHT GUIDE (133JS) Hook × 2 Boss × 2 REFLECT SHEET (134HU) Hook × 2 Boss × 2...
  • Page 71 LIGHT SHIELDING SHEET (134MH) Boss × 2 Guide × 2 Double stick tape SCREW (6A-17040FD2) Top LCD FPC Boss × 5...
  • Page 72 DOUBLE STICK TAPE (134J3) Boss × 2 SPONGE (1396B) × 2 SPONGE (134HY)

  • Page 73: Shoe Mold Unit

    3-BUTTON (134J6) SHOE MOLD UNIT Boss × 2 HOT SHOE MOLD UNIT (11X05) SHOE (12H9D) HOT SHOE SPRING (1311Z)
  • Page 74 SCREW (6A-14030FD2) ON-OFF SW BRUSH (1K241-679) Boss RELEASE BUTTON (1K201-276) E-RING (S1-01200SX) RUBBER (1K116-705) RELEASE BUTTON (1K201-276) SPRING (11Z8J)

  • Page 75: Main Sw Dial

    SPONGE (138WZ) MAIN SW DIAL SCREW (6E-17030FD2) × 2 CLICK PLATE UNIT (1B002-875) RUBBER (1K118-179) Boss MAIN SW DIAL (134J4)

  • Page 76: Gps Pcb

    GPS PCB Boss × 2 SCREW (6A-17040FD2) × 4 SCREW (6A-14030FD2) RUBBER (133M9) GPS PCB (12P2N) GPS COVER (133LR)

  • Page 77: Sync Terminal

    SYNC TERMINAL SYNC TERMINAL (1B002-504) Guide SCREW HARNESS (A1-14020FD2) (1324V) SYNC TERMINAL (1B002- 504) SYNC TERMINAL (1B002-504) HARNESS (1324V) Solder HARNESS (1324V) SYNC TERMINAL (1B002-504)

  • Page 78: Top Cover Unit

    TOP COVER UNIT SHEET (138WJ) × 2 SPONGE (1381U) SPONGE (133MA) × 2...
  • Page 79 SPONGE SPONGE (134J1) (134J0) SPONGE SPONGE (134J0) (134J1) SPONGE (134LE) SPONGE (134XV) SPONGE (135Y3) SPONGE (134XX) SPONGE (134XT) SPONGE (139GM) SPONGE (134XV) SPONGE (134J9)

  • Page 80: Eyelet

    EYELET (N3-04000FA) EYELET SCREW (113ZU) (1264U) EYELET (1B002-961) SHEET (12R6D) × 4 COLLAR (11D7U) TAPE (13A0G)

  • Page 81: Eyepiece Block Unit

    4. EVF unit EYEPIECE BLOCK UNIT GASKET (139HY) CONDUCTIVE TAPE (139JE) MOISUTURE ABSORBING MOISUTURE SHEET ABSORBING (139JJ) SHEET (139JL) MOISUTURE ABSORBING SHEET (139JK) × 2...
  • Page 82 MOISUTURE ABSORBING SHEET (139JM) HEAT DISSIPATION SHEET (133M4) Hook Boss...
  • Page 83 TAPE (133LA) SPONGE (133MB) SPONGE (133MC)
  • Page 84 TAPE (133LC) TAPE (133LB) SCREW (6A-17040FD2) × 2 DIOPTER ADJUSTMENT CAM CASE (133KK) DIOPTER ADJUSTMENT CAM (133KJ) CLICK BALL (T1-01500SX1) SPRING (133KL)
  • Page 85 EVF BOTTOM COVER UNIT (1357B) BOTTOM COVER UNIT (1357B) Hook × 4 SCREW (6A-17040FD2) × 2 Boss × 4 EVF DUSTPROOF PLATE UNIT (1357A) Boss × 4...

  • Page 86: Evf Panel Unit

    EVF PANEL UNIT EVF PANEL UNIT (1356Y) EVF DUSTPROOF PLATE UNIT (1357A) SPRING (133KE) SCREW (6A-17040FD2) × 4 EVF UNIT (139PC) SCREW (6A-17040FD2) × 2 Boss × 2 SCREW EVF UNIT (6A-17040FD2) × 2 (139PC)
  • Page 87 LENS ROOM UNIT (139HT) SPRING (1K220-676) Projecting section EYEPIECE LOCK BUTTON (133L3-A0Z96S) EYE SENSOR FPC UNIT SPONGE (138X6) GND plate Boss × 2...
  • Page 88 Guide axis EYEPIECE BLOCK UNIT (1356B-A0V9J5)

  • Page 89: Rear Cover Unit

    5. Rear cover REAR COVER UNIT GASKET (137G8) SCREW (6E-17030FD2) × 2 Retainer plate...

  • Page 90: Tft Monitor Unit

    TFT MONITOR UNIT SCREW (12H4A) × 4 Boss × 2...
  • Page 91 MOLD (133J2) MOLD (133J2) MOLD (133J2) MOLD (133J1) Double stick tape MOLD MOLD (133J1) (133J1)

  • Page 92: Tilt Unit

    TILT UNIT SCREW (127A4) × 6 SCREW (127A4) × 3 SCREW (127A4) × 3 Unfold the tape on the left side Unfold the tape on the Lift the FPC and right side turn it upside down...
  • Page 94 MOLD (133J1) MOLD (133J1) MOLD (133J1) Double stick tape Boss × 2...
  • Page 95 DOUBLE STICK TAPE (133J4) DOUBLE STICK TAPE (133J3) SPONGE (11W3P) SPONGE (133HV) TILT UNIT (1404P)

  • Page 96: Tft Monitor Unit

    TFT MONITOR UNIT LATCH (135VW) LATCH (135VW) SPRING (128C2) SPRING (128C2) TFT MONITOR UNIT (1350T-A113BT) LATCH (135VW) TFT MONITOR FPC UNIT (1350S-A10V4F) Double stick tape Double stick tape...
  • Page 97 SCREW (6A-17035FD2) × 3 Boss × 3 HEAT DISSIPATION SHEET (1334J) Heat dissipation plate SCREW (12R79) SECURITY LOCK COVER (133U5)
  • Page 98 SCREW (6A-17035FD2) × 2 Solder × 3 Boss × 2 Guide BATTERY HOLDER (133R3) BATTERY HOLDER (133R3) SCREW (12H4B) × 6 SCREW (12H4B) × 3 BATTERY HOLDER (133R3) SCREW BATTERY HOLDER (12H4B) × 3 (133R3)

  • Page 99: Security Lock Unit

    SCREW (12R79) × 2 V-POSITION MAIN COMMAND DIAL UNIT (1350V) Boss SECURITY LOCK UNIT SCREW (12R79) × 2 SECURITY LOCK UNIT (1355W) Projecting section...
  • Page 100 SCREW (6E-17040FD2) × 2 SCREW Retainer plate (6E-17030FD2) × 2 SPONGE (133SJ) STEEL BALL (T2-02300SX1) SPRING (133UN)
  • Page 101 SCREW (6E-17030FD2) × 4 Retainer plate SCREW (6E-17030FD2) × 3 Retainer plate SCREW (6E-17030FD2) × 4 Retainer plate SPONGE (11W3P)

  • Page 102: Rear Fpc Unit

    REAR FPC UNIT REAR FPC UNIT (1355P) Brush Boss × 4 SUB MULTI- MOLD SELECTOR (1276S) × 2 BUTTON UNIT (1132W) × 2 AF-ON BUTTON (133V8) Boss × 2 RETAINER PLATE (133V9)
  • Page 103 SPRING (128C2) HOLDER (11H76) LAN INDICATOR HOLDER (133TU) Boss V-POSITION 3-BUTTON (133TT) Boss × 2...
  • Page 104 V-POSITION AF-ON BUTTON (133U1) V-POSITION RUBBER I BUTTON Boss × 4 (12P75) (133TX) Boss × 2 FOURTH RUBBER BUTTON (133V3) (133VE) I BUTTON (133VC) Boss × 2 Boss × 4...
  • Page 105 OK BUTTON (133V2) ACCESS LAMP MULTI WINDOW (133VG) SELECTOR SPONGE (1276L) (1276H) Boss WASHER (139L4) × 4 WASHER (139L5)

  • Page 106: Fn4/Delete Button Fpc Unit

    SCREW (6A-17045FD2) × 3 LIGHT SHIELDING TAPE (139GY) FN4/DELETE BUTTON FPC UNIT (137LN) Double stick tape Boss FN4/DELETE BUTTON FPC UNIT FN4/DELETE BUTTON FPC FN4/DELETE UNIT (137LN) BUTTON (133VA) Boss × 2 Boss × 3...

  • Page 107: Speaker Unit

    SPEAKER UNIT SCREW Boss (6A-17045FD2) × 2 TAPE (133TR) × 2 SPEAKER HOLDER (133TS) SPEAKER UNIT (135Y1) SHEET (1264C) DISP BUTTON (133V7) MOLD (1277C) Brush...
  • Page 108 DISP BUTTON (133V7) RUBBER (122FN) DISP BUTTON (133V7) DISP BUTTON (133V7) DISP SELECTOR (133V6) DISP SELECTOR SCREW MOLD UNIT (6A-14025FA) × 2 (12S27) DISP SELECTOR MOLD UNIT (12S27) REAR COVER UNIT (139PD-A0Z22E) DISP SELECTOR (133V6) Boss × 2...

  • Page 109: Rear Rubber Unit

    REAR RUBBER UNIT REAR RUBBER SECURITY LOCK UNIT (1355Y) PATCH PLATE UNIT (137XE) SCREW (6A-17035FD2) × 3 SPONGE SCREW (11W3P) (6E-17030FD2) × 2 Boss × 2 Retainer plate...
  • Page 110 SPONGE (133J8) × 2 Boss × 4 SPRING (128C2) HOLDER (11H76) TAPE (139MK) × 2...

  • Page 111: V-Position Rear Rubber Unit

    V-POSITION REAR RUBBER UNIT TAPE (133TJ) V-POSITION REAR RUBBER UNIT (1354B) SCREW (12U6P) × 3 SCREW (133U9) × 3 SHEET (12R6D) × 8 SHEET (12R6D) × 5...
  • Page 112 SPONGE SPONGE (133JJ) (133TW) SHEET (133UE) TAPE (133U2) SPONGE (133U3)
  • Page 113 SPONGE (134LE) × 2 SPONGE (138F3) SPONGE (138F4) SPONGE SPONGE (133SX) SPONGE SPONGE (133TK) (133TL) SPONGE (133TM) (133TN)
  • Page 114 SECURITY LOCK COVER (133U5) SPONGE (133SH-A0X0HS) SWITCHING LEVER RING (137KB) DOUBLE STICK TAPE (137KC)

  • Page 115: Assembly

    Assembly 1. Rear cover REAR COVER UNIT SWITCHING DOUBLE STICK TAPE LEVER RING (137KC) (137KB) DOUBLE STICK TAPE (137KC) Reference position for attachment Match the shape. SPONGE (133SH-A0X0HS) SPONGE OS-30P (133SH-A0X0HS) Reference position for attachment SPONGE (133SH-A0X0HS)
  • Page 116 Cut off if the parts are replaced SECURITY LOCK COVER (133U5) SECURITY LOCK COVER (133U5) DN-C3HN SPONGE (133TN) SPONGE (133TN) SPONGE (133TN) OS-30P Reference position for attachment SPONGE (133TK) SPONGE (133TK) OS-30P SPONGE (133TK) Reference position for attachment...
  • Page 117 SPONGE SPONGE (133SX) (133SX) SPONGE (133SX) OS-30P Reference position OS-30P for attachment SPONGE SPONGE (133TM) (133TM) OS-30P SPONGE (133TM) Reference position for attachment SPONGE SPONGE (133TL) (133TL) OS-30P SPONGE (133TL) Reference position for attachment...
  • Page 118 Reference position for attachment SPONGE SPONGE (138F3) (138F4) SPONGE SPONGE (138F3) SPONGE (138F4) (138F3) OS-30P OS-30P SPONGE (138F4) SPONGE (134LE) SPONGE (134LE) OS-30P SPONGE (134LE) × 2 Reference position for attachment SPONGE (134LE) SPONGE (134LE) Reference position for attachment...
  • Page 119 TAPE SPONGE (133U2) (133U3) TAPE (133U2) Reference position for attachment SPONGE (133U3) Reference position for attachment SHEET (133UE) SHEET Reference position (133UE) for attachment...
  • Page 120 SPONGE SPONGE (133TW) (133JJ) SPONGE (133TW) OS-30P OS-30P Reference position for attachment SPONGE (133TW) SPONGE (133JJ) SHEET SHEET (12R6D) × 5 (12R6D) × 8...

  • Page 121: V-Position Rear Rubber Unit

    TAPE (133TJ) TAPE (133TJ) Reference position for attachment V-POSITION REAR RUBBER UNIT V-POSITION REAR RUBBER V-POSITION REAR UNIT (1354B) RUBBER UNIT (1354B) SCREW (12U6P) × 3 Boss × 2 V-POSITION REAR RUBBER UNIT Reference position (1354B) for attachment SCREW (133U9) × 3...
  • Page 122 TAPE (139MK) TAPE (139MK) TAPE (139MK) × 2 Reference position for attachment Reference position for attachment SPRING (128C2) HOLDER (11H76)
  • Page 123 SPONGE OS-30P (133J8) × 2 SPONGE (133J8) × 2 SPONGE (133J8) Boss × 4 SPONGE (133J8) SPONGE (11W3P) SECURITY LOCK PATCH PLATE UNIT (137XE) Reference position for attachment SCREW (6E-17030FD2) × 2 Retainer plate Boss × 2 SECURITY LOCK PATCH PLATE UNIT (137XE) Reference position...

  • Page 124: Rear Rubber Unit

    REAR RUBBER UNIT REAR REAR RUBBER UNIT RUBBER (1355Y) UNIT (1355Y) Boss × 3 REAR RUBBER UNIT (1355Y) SCREW Reference position (6A-17035FD2) × 3 for attachment Do NOT apply to the red area. OS-30P REAR COVER UNIT (139PD-A0Z22E)
  • Page 125 SCREW (6A-14025FA) × 2 FG-30 DISP SELECTOR DISP SELECTOR MOLD UNIT MOLD UNIT (12S27) (12S27) REAR COVER UNIT (139PD-A0Z22E) DISP SELECTOR (133V6) Align the position in the figure. DISP SELECTOR (133V6) FG-30 Boss × 2 Do NOT apply to the red area. DISP SELECTOR (133V6) DISP BUTTON RUBBER...

  • Page 126: Speaker Unit

    MOLD (1277C) MOLD (1277C) Match the shape. Boss × 2 DISP BUTTON (133V7) Brush SPEAKER UNIT SCREW (6A-17045FD2) × 2 SPEAKER HOLDER SPEAKER (133TS) UNIT (135Y1) SPEAKER HOLDER (133TS) SHEET Reference position for (1264C) attachment SHEET (1264C)

  • Page 127: Fn4/Delete Button Fpc Unit

    Reference position for attachment TAPE (133TR) Boss TAPE (133TR) × 2 TAPE (133TR) × 2 FN4/DELETE BUTTON FPC UNIT FN4/DELETE FN4/DELETE BUTTON FPC BUTTON UNIT (137LN) (133VA) Boss × 2 FN4/DELETE BUTTON (133VA) Boss × 3...
  • Page 128 LIGHT SHIELDING TAPE (139GY) Reference position for attachment SCREW FN4/DELETE (6A-17045FD2) × 3 BUTTON FPC LIGHT UNIT (137LN) SHIELDING TAPE (139GY) Boss FN4/DELETE BUTTON FPC UNIT (137LN) Reference position Double stick tape for attachment...
  • Page 129 The curved shape of washer must be upper side as shown in the image below. WASHER (139L4) × 4 Curved shape Cross section of the multi-selector OK button Muiti selector MULTI SELECTOR (1276H)(Multi selector) NG (Tilt) (The curved shape of washer is upper side) (The curved shape of washer is lower side) MULTI SELECTOR (1276H)
  • Page 130 WASHER (139L5) NG: Tilt OK BUTTON (133V2) WASHER (139L5) OK BUTTON (133V2) MULTI ACCESS LAMP SELECTOR WINDOW (133VG) (1276H) Boss MULTI OK BUTTON SELECTOR MULTI ACCESS LAMP (133V2) (1276H) SELECTOR WINDOW (1276H) (133VG)
  • Page 131 Do NOT attach WASHER (139L5) to RUBBER (133V3) FOURTH BUTTON I BUTTON (133VE) (133VC) RUBBER (133V3) Boss × 4 Boss × 2 V-POSITION AF-ON RUBBER BUTTON V-POSITION (12P75) (133U1) I BUTTON Boss × 4 (133TX) Boss × 2...
  • Page 132 V-POSITION 3-BUTTON (133TT) INDICATOR HOLDER (133TU) Boss Boss × 2 SPRING (128C2) HOLDER (11H76)
  • Page 133 MOLD (1276S) × 2 Boss × 4 SUB MULTI- SELECTOR BUTTON UNIT (1132W) × 2 AF-ON BUTTON (133V8) Valley-fold Mountain-fold RETAINER Boss × 2 PLATE (133V9)

  • Page 134: Rear Fpc Unit

    REAR FPC UNIT REAR FPC UNIT (1355P) PL-1016EL Patterned surface of the encoder REAR FPC UNIT (1355P) Do NOT touch red area of the Rear FPC unit (1355P). REAR FPC UNIT (1355P) Brush Boss × 16 REAR FPC Boss × 8 UNIT (1355P)
  • Page 135 SCREW (6E-17030FD2) × 4 SPONGE Retainer plate (11W3P) Reference position for attachment Boss × 7 SCREW Retainer plate (6E-17030FD2) × 3 Boss × 5 SCREW (6E-17030FD2) × 4 Retainer plate Boss × 4...
  • Page 136 STEEL BALL SPRING (T2-02300SX1) STEEL BALL (133UN) (T2-02300SX1) MG-74CM SPRING (133UN) 74CM STEEL BALL (T2- 02300SX1) SCREW SPONGE (133SJ) (6E-17030FD2) × 2 Boss × 3 Retainer plate Reference position for attachment SCREW (6E-17040FD2) × 2...

  • Page 137: Security Lock Unit

    SECURITY LOCK UNIT SCREW (12R79) × 2 Boss × 2 SECURITY LOCK UNIT (1355W) SECURITY LOCK UNIT (1355W) Projecting SECURITY LOCK section OS-30P UNIT (1355W) SECURITY LOCK COVER (133U5) SCREW (12R79) × 2 V-POSITION MAIN COMMAND DIAL UNIT (1350V) Boss...
  • Page 138 SCREW (12H4B) × 6 BATTERY HOLDER (133R3) Cutout BATTERY HOLDER (133R3) SCREW (12H4B) × 3 BATTERY HOLDER SCREW BATTERY (133R3) (12H4B) × 3 HOLDER (133R3) SCREW (6A-17035FD2) × 2 Solder × 3 Boss × 2 Guide BATTERY HOLDER (133R3) BATTERY HOLDER (133R3)
  • Page 139 SCREW (12R79) SECURITY LOCK COVER (133U5) HEAT DISSIPATION SHEET (1334J) HEAT DISSIPATION SHEET (1334J) Reference position for attachment Heat dissipation plate SCREW (6A-17035FD2) × 3 Boss × 3...

  • Page 140: Tft Monitor Unit

    TFT MONITOR UNIT TFT MONITOR FPC UNIT (1350S-A10V4F) Double stick tape Double Reference position for attachment stick tape Mountain-fold Valley-fold TFT MONITOR UNIT (1350T-A113BT)

  • Page 141: Tilt Unit

    LATCH (135VW) LATCH (135VW) TFT MONITOR UNIT (1350T-A113BT) SPRING (128C2) LATCH LATCH (135VW) (135VW) SPRING (128C2) TILT UNIT Do NOT touch red circle area. TILT UNIT (1404P)
  • Page 142 Reference position for attachment Reference position for SPONGE attachment (11W3P) SPONGE (133HV) SPONGE (11W3P) SPONGE (133HV) OS-30P DOUBLE STICK DOUBLE TAPE STICK TAPE (133J4) (133J3) DOUBLE STICK TAPE (133J3) DOUBLE STICK TAPE (133J4) Reference position for attachment Reference position for attachment...
  • Page 143 Double stick tape Reference position for attachment Double stick tape MOLD (133J1) MOLD (133J1) MOLD (133J1)
  • Page 144 Reference position for attachment...
  • Page 145 Put some like a thin Lift the FPC and stick under the FPC turn it upside down Fold the left side tape Fold the right side tape SCREW (127A4) × 6 SCREW (127A4) × 3 SCREW (127A4) × 3 Boss × 2...
  • Page 146 MOLD (133J1) MOLD (133J1) MOLD Double stick tape (133J1) Reference position for attachment...
  • Page 147 MOLD (133J2) MOLD MOLD (133J2) (133J2)
  • Page 148 SCREW (12H4A) × 4 Boss × 2...
  • Page 149 OS-30P SCREW (6E-17030FD2) × 2 Retainer plate GASKET (137G8) GASKET (137G8) Reference position for attachment...

  • Page 150: Eyepiece Block Unit

    2. EVF unit EYEPIECE BLOCK UNIT Guide axis 28.9- 29.5mm 28.9- 29.5mm EYEPIECE BLOCK UNIT EYEPIECE C3HN (1356B-A0V9J5) BLOCK UNIT (1356B-A0V9J5) SENSOR SENSOR FPC UNIT FPC UNIT GND plate Boss × 2 Valley-fold...
  • Page 151 SPONGE (138X6) OS-30P SPONGE (138X6) SPONGE (138X6) Reference position for attachment LENS ROOM UNIT (139HT) SPRING Projecting section (1K220-676) EYEPIECE LOCK BUTTON (133L3-A0Z96S)

  • Page 152: Evf Panel Unit

    SCREW (6A-17040FD2) × 4 EVF UNIT DN-C3HN (139PC) EVF UNIT (139PC) SCREW (6A-17040FD2) × 2 Boss × 2 SCREW EVF UNIT (6A-17040FD2) × 2 (139PC) EVF PANEL UNIT EVF PANEL UNIT (1356Y) SPRING (133KE)
  • Page 153 EVF DUSTPROOF PLATE UNIT (1357A) Reference position for attachment PANEL UNIT (1356Y) PANEL UNIT (1356Y) DUSTPROOF PLATE UNIT (1357A) SCREW (6A-17040FD2) × 2 Boss × 4 DUSTPROOF DUSTPROOF PLATE UNIT PLATE UNIT (1357A) (1357A)
  • Page 154 EVF BOTTOM COVER UNIT (1357B) EVF BOTTOM COVER UNIT (1357B) Hook × 4 Boss × 4...
  • Page 155 DIOPTER CFD409Z Do NOT apply to the red area. ADJUSTMENT CAM (133KJ) Projecting section Align the position in the figure. DIOPTER ADJUSTMENT CAM (133KJ) PANEL UNIT (1356Y) DIOPTER ADJUSTMENT CAM (133KJ) DIOPTER ADJUSTMENT CAM (133KJ) PANEL UNIT (1356Y) EVF PANEL UNIT (1356Y) CFD409Z...
  • Page 156 SCREW (6A-17040FD2) × 2 DIOPTER ADJUSTMENT CAM CASE (133KK) Boss × 2 CLICK BALL (T1-01500SX1) CFD409Z CLICK BALL (T1-01500SX1) SPRING (133KL) CFD409Z SPRING SPRING (133KL) (133KL)
  • Page 157 TAPE TAPE (133LC) (133LB) TAPE (133LB) TAPE (133LC) Reference position for attachment Reference position for attachment SPONGE SPONGE OS-30P (133MC) (133MC) SPONGE (133MC) Reference position for attachment...
  • Page 158 SPONGE (133MB) SPONGE (133MB) SPONGE (133MB) SPONGE Attach to overlap. (133MC) Attach to overlap. SPONGE (133MC) Reference position for attachment SPONGE (133MB) TAPE (133LA) TAPE (133LA) TAPE (133LA) Reference position for attachment...

  • Page 159: Heat Desipation Sheet

    Boss Hook HEAT DESIPATION SHEET HEAT DISSIPATION Reference SHEET HEAT DISSIPATION position for (133M4) SHEET (133M4) attachment...
  • Page 160 MOISUTURE MOISUTURE ABSORBING ABSORBING SHEET SHEET (139JJ) (139JM) MOISUTURE ABSORBING SHEET Reference position for attachment (139JJ) MOISUTURE ABSORBING SHEET (139JM) Reference position for attachment MOISUTURE ABSORBING MOISUTURE SHEET (139JK) ABSORBING MOISUTURE SHEET (139JK) MOISUTURE ABSORBING ABSORBING SHEET SHEET (139JJ) (139JJ) MOISUTURE Reference position for attachment ABSORBING...
  • Page 161 MOISUTURE Reference position for attachment ABSORBING SHEET (139JL) MOISUTURE ABSORBING SHEET (139JL) CONDUCTIVE TAPE (139JE) Boss CONDUCTIVE TAPE (139JE) CONDUCTIVE TAPE (139JE) Reference position for attachment GASKET (139HY) GASKET (139HY) Reference position for attachment...

  • Page 162: Top Cover Unit

    3. Top cover TOP COVER UNIT Do NOT apply to the red area. OS-30P area CFD409Z area...
  • Page 163 COLLAR (11D7U) COLLAR (11D7U) TAPE (13A0G) TAPE (13A0G) SHEET (12R6D) × 4 SPONGE (134J9) SPONGE OS-30P SPONGE (134J9) (134J9)

  • Page 164: Eyelet

    EYELET #Super X No.8008 SCREW SCREW (1264U) EYELET (1264U) (1B002- 961) Do NOT apply to the red area. EYELET NUT (N3-04000FA) (113ZU) Apply to the point of screw. L-648 NUT (N3- 04000FA) Do NOT apply to the Super X No.8008 red area.
  • Page 165 SPONGE (134XT) SPONGE (134XT) OS-30P Reference position for attachment SPONGE OS-30P (139GM) SPONGE (139GM) Reference position for attachment SPONGE (134XV) OS-30P SPONGE (134XV) Reference position for attachment SPONGE (134XV)
  • Page 166 SPONGE (134XV) SPONGE (134XV) SPONGE (134XV) Reference position for attachment OS-30P SPONGE (135Y3) SPONGE (135Y3) OS-30P Reference position for attachment OS-30P SPONGE (134LE) SPONGE (134LE)
  • Page 167 Reference position for attachment SPONGE (134J1) SPONGE (134J1) SPONGE (134J0) SPONGE SPONGE (134J1) (134J0) SPONGE (134J0) SPONGE (134J1) SPONGE SPONGE (134J1) (134J0) SPONGE SPONGE (134J0) (134J1) OS-30P SPONGE (133MA) SPONGE (133MA) Reference position for attachment...
  • Page 168 SPONGE OS-30P (133MA) Reference position for attachment SPONGE (133MA) SPONGE SPONGE Attach to overlap. (133MA) (133MA) SPONGE (1381U) SPONGE (1381U) OS-30P SHEET (138WJ) SHEET (138WJ) × 2 SHEET (138WJ) × 2 OS-30P SHEET (138WJ)

  • Page 169: Sync Terminal

    SYNC TERMINAL SYNC TERMINAL (1B002-504) HARNESS (1324V) Solder HARNESS (1324V) SYNC TERMINAL (1B002-504) SYNC TERMINAL (1B002-504) Guide SCREW HARNESS (A1-14020FD2) (1324V) SYNC TERMINAL (1B002-504) Turn clockwise as far as it will go.

  • Page 170: Gps Pcb

    GPS PCB SCREW (6A-14030FD2) RUBBER (133M9) (12P2N) GPS PCB (12P2N) GPS COVER (133LR) RUBBER (133M9) Reference position for attachment Boss × 2 SCREW (6A-17040FD2) × 4...

  • Page 171: Main Sw Dial

    MAIN SW DIAL Direction for mounting RUBBER (1K118-179) RUBBER FG-30 (1K118-179) MAIN SW DIAL MAIN SW (134J4) FG-30 DIAL (134J4) CLICK PLATE UNIT SCREW (1B002-875) (6E-17030FD2) × 2 FG-30 CLICK PLATE UNIT (1B002-875) Do NOT apply to the red area. FG-30 FG-30 Boss...
  • Page 172 SPONGE (138WZ) SPONGE (138WZ) Reference position for attachment RUBBER (1K116- 705) RUBBER (1K116-705) RELEASE BUTTON SPRING FG-30 (1K201- (11Z8J) 276) Do NOT apply to the red area. RELEASE BUTTON (1K201-276) RELEASE BUTTON (1K201-276) E-RING (S1-01200SX) E-RING (S1-01200SX)

  • Page 173: Shoe Mold Unit

    SCREW (6A-14030FD2) ON-OFF SW BRUSH (1K241-679) Boss SHOE MOLD UNIT HOT SHOE DN-C3HN (12H9D) Do NOT apply to the red area. HOT SHOE (12H9D) HOT SHOE SPRING (1311Z)
  • Page 174 HOT SHOE (12H9D) HOT SHOE MOLD UNIT (11X05) HOT SHOE MOLD UNIT (11X05) Boss KE347B Boss × 2 3-BUTTON (134J6) 3-BUTTON (134J6) Boss × 6...

  • Page 175: Top Lcd Unit

    TOP LCD UNIT SPONGE OS-30P (134HY) SPONGE (134HY) Reference position for attachment SPONGE (1396B) × 2 SPONGE (1396B) SPONGE Reference position for attachment (1396B) Cutout DOUBLE STICK TAPE (134J3) Boss × 2...
  • Page 176 Guide × 2 Top LCD FPC Boss × 5 Boss × 2 LIGHT SHIELDING SHEET (134MH) SCREW (6A-17040FD2) LIGHT SHIELDING SHEET (134MH) Reference position for attachment...
  • Page 177 REFLECT SHEET (134HU) Hook × 2 Boss × 2 LIGHT GUIDE (133JS) Hook × 2 Boss × 2 Tightening torque: 0.12 N·m LIGHT SHIELDING SCREW (1K010-592) SHEET (134J2) Hook × 2 Boss × 2...
  • Page 178 LIGHT DOUBLE STICK DOUBLE SHIELDING TAPE (134Y4) STICK TAPE SHEET (134J2) (134Y4) LIGHT SHIELDING SHEET (134J2) Reference position for attachment TOP LCD (1324K) TOP LCD Double stick (1324K) tape Hook × 2...
  • Page 179 SHEET (134P2) SHEET (134P2) SHEET (134P2) Reference position for attachment FG-30 SCREW Do NOT (6A-17040FD2) × 4 apply to the red area. Patterned surface of the encoder TOP LCD UNIT PL-1016EL (1358V) Boss × 2 Boss × 2...
  • Page 180 SCREW (1331C)× 4 Boss × 4 Solder × 4 SCREW (6A-17040FD2) × 4...
  • Page 181 MDF-1176BE SPRING SCREW (134WY) (1K010-592) Hook spring × 2 SPRING (134WY) SPRING (134WY) MODE DIAL LOCK BUTTON (134G5) C3HN SPRING (1380K) MODE DIAL LOCK BUTTON (134G5) MONITOR SWITCHING BUTTON (133LZ)

  • Page 182: Top Cover Fpc Unit

    TOP COVER FPC UNIT TOP COVER MG-74CM area FPC UNIT OS-30P (1357F) area PL-1016EL Patterned surface of the encoder SCREW (6A-17040FD2) × 4 TOP COVER FPC UNIT (1357F) TOP COVER FPC UNIT (1357F) Boss × 2 Guide...
  • Page 183 SCREW (6A-17040FD2) CHARGE LED WINDOW (134FU) TOP COVER FPC UNIT (1357F) TOP COVER FPC UNIT (1357F) CHARGE LED WINDOW (134FU) SCREW (6A-17040FD2) × 4 TOP COVER FPC UNIT (1357F) Boss × 4...
  • Page 184 COVER FPC UNIT (1357F) Hook...

  • Page 185: Four Leaf Button Unit

    FOUR LEAF BUTTON UNIT SCREW (G1-14025FA) × 2 SCREW (G1-14025FA) CLICK SPRING (11J9S) DRIVE MODE FG-30 SW BRUSH (1K241-465) Boss × 2 Boss × 2 MODE DIAL (134G0) FG-30 WASHER (11U6U) WASHER (11U6U) Black is the lower side. OS-30P...
  • Page 186 Reference position for mounting "S" SCREW (1K010-585) FOUR LEAF BUTTON UNIT (134ZX) SCREW (1K010-585)

  • Page 187: Wi-Fi Cable Holder

    Guide × 6 SCREW (6A-17040FD2) WI-FI CABLE HOLDER (134FV) WI-FI CABLE HOLDER (134FV) Boss × 2 WI-FI CABLE HOLDER WI-FI CABLE HOLDER (134FV) Guide × 3...

  • Page 188: Mic Fpc Unit

    MIC FPC UNIT Mountain-fold Valley-fold MIC FPC UNIT (1358Z) SCREW (6A-17040FD2) × 2 MIC FPC UNIT (1358Z) Boss × 2 Boss × 4 SCREW (6A-17040FD2) EVF HOLDING PLATE (133LP) Boss × 2...

  • Page 189: Command Dial Unit

    COMMAND DIAL UNIT SUB COMMAND DIAL UNIT (1357H) OS-30P SUB COMMAND DIAL UNIT (1357H) SUB COMMAND DIAL UNIT (1357H) Solder × 3 COMMAND DIAL FPC (1323S) MAIN COMMAND DIAL UNIT (1357G) Solder × 3 COMMAND COMMAND DIAL UNIT DIAL FPC (1357H) (1323S) MAIN COMMAND DIAL...
  • Page 190 SUB COMMAND SCREW DIAL UNIT (1357H) (6A-17040FD2) × 4 Cutout Boss × 2 SUB COMMAND DIAL UNIT (1357H) SCREW INSULATION TAPE (6A-17040FD2) × 2 (139JR) Radiate heat plate Boss × 2 INSULATION TAPE (139JR) Reference position for attachment...
  • Page 191 MOISUTURE ABSORBING SHEET (139JH) MOISUTURE ABSORBING SHEET (139JH) Reference position for attachment Reference position for attachment SPONGE SPONGE (134XW) (134XX) Attach to overlap. SPONGE SPONGE (134XW) (134XW) SPONGE (134XW) OS-30P...
  • Page 192 TOP LCD WINDOW (133JT) DOUBLE STICK TAPE (133JU) TOP LCD WINDOW (133JT) Reference position for attachment DOUBLE STICK TAPE (133JU)

  • Page 193: Front Body Unit

    4. Front body FRONT BODY UNIT SPONGE (1333N) OS-30P SPONGE (1333N) SPONGE (1333N) Reference position for attachment SPONGE (1333P) OS-30P SPONGE (1333P) SPONGE (1333P) Reference position for attachment...
  • Page 194 OS-30P SPONGE SPONGE (138T5) (138T5) SPONGE (138T5) Reference position for attachment SPONGE SPONGE (138T6) (138T6) OS-30P SPONGE (138T6) Reference position for attachment...
  • Page 195 SPONGE (134YZ) SPONGE (134YZ) OS-30P SPONGE (134YZ) Reference position for attachment SPONGE (1333L) SPONGE (1333L) SPONGE (1333L) OS-30P Reference position for attachment...
  • Page 196 SPONGE (138F5) SPONGE (138F5) OS-30P SPONGE (138F5) Reference position for attachment SHEET (12R6D) × 3 TAPE (1285V) × 2 SHEET (12R6D) × 2...

  • Page 197: Tripod Base

    TRIPOD BASE SCREW (A2-20035FA) × 4 Bottom plate TRIPOD BASE (133R0) SCREW (1E-17020FD2) × 3 VIDEO BOSS VIDEO BOSS (133UF) (133UF) Boss SPONGE (138F6) SPONGE (138F6) TAPE (138T8) TAPE (138T8)
  • Page 198 WATERPROOF RUBBER (1333K) Cutout SCREW (133TY) × 4...
  • Page 199 SCREW (6A-17040FD2) × 2 Boss × 2 10 PIN UNIT (135A1) SCREW (6A-17040FD2) SPONGE (138T7) SPONGE (138T7) OS-30P SPONGE (138T7) Reference position for attachment...

  • Page 200: V-Position Sub Command Dial Unit

    V-POSITION SUB COMMAND DIAL UNIT V-POSITION RELEASE COVER V-POSITION RELEASE COVER (133SU) (133SU) FG-30 area OS-30P area DN-C3HN area SPRING (116JR) RUBBER (1K116-705) Do NOT apply to the red area. SHUTTER RELEASE FG-30 RUBBER BUTTON (11B2S) FG-30 (1K116-705) SHUTTER RELEASE BUTTON (11B2S)
  • Page 201 V-POSITION LOCK LEVER MOLD (133T2) V-POSITION LOCK LEVER MOLD (133T2) FG-30 SHUTTER RELEASE BUTTON (11B2S) SHUTTER RELEASE E-RING BUTTON (11B2S) (S1-01200SX) Do not lose the E-ring. E-RING (S1-01200SX) RUBBER (1K118-179) RUBBER (1K118-179) RUBBER FG-30 (1K118-179)
  • Page 202 SCREW (6A-14025FA) × 2 CLICK PLATE V-POSITION RELEASE COVER (133SU) (12A5D) V-POSITION Align the position in the figure. RELEASE COVER (133SU) Boss × 2 SPONGE SPONGE (133SY) (133SY) OS-30P SPONGE (133SY) Reference position for attachment...
  • Page 203 SPONGE SPONGE (133SX) (133SX) OS-30P Reference position for attachment SPONGE Attach to overlap. (133SX) SPONGE (133SY) SPONGE (133SY) SCREW (6A-17045FD2) × 2 V-POSITION SUB COMMAND DIAL UNIT (135AJ) V-POSITION SUB COMMAND Boss × 2 DIAL UNIT (135AJ)
  • Page 204 V-POSITION 2-BUTTON (133T7) OS-30P V-POSITION 2-BUTTON (133T7) V-POSITION FPC BLOCK UNIT (135AK) V-POSITION FPC BLOCK UNIT (135AK) Valley-fold...
  • Page 205 SCREW V-POSITION (6A-17045FD2) × 2 COMMAND Guide × 3 DIAL UNIT (135AJ) V-POSITION FPC BLOCK UNIT (135AK) Solder × 3 Boss × 3 V-POSITION SUB V-POSITION FPC COMMAND DIAL BLOCK UNIT UNIT (135AJ) (135AK) SCREW (6A-17040FD2) × 3 Boss...

  • Page 206: Grip Rubber Unit

    5. External parts GRIP RUBBER UNIT Reference position for attachment GRIP RUBBER UNIT (135AA) GRIP RUBBER UNIT (135AA) GRIP RUBBER UNIT (135AA) Boss Double stick tape Double stick tape Double stick tape Double stick tape...
  • Page 207 SCREW (6A-17040FD2) GRIP RUBBER UNIT (135AA) GRIP RUBBER UNIT SCREW (135AA) (6A-17040FD2) × 2 SCREW (6A-17040FD2) × 2 Reference position for attachment V-POSITION GRIP RUBBER UNIT (135A8) V-POSITION GRIP RUBBER UNIT (135A8)
  • Page 208 Double stick tape Double stick tape SCREW SCREW (6A-17045FD2) SCREW (6A-17035FD2) (6A-17045FD2) SCREW (6A-17035FD2) SCREW (12U6M) V-POSITION GRIP RUBBER UNIT (135A8) SCREW (12U6M)
  • Page 209 IF GRIP UNIT (135A9) Reference position for attachment IF GRIP UNIT (135A9) Double stick tape...
  • Page 210 SPONGE SPONGE (138TB) (138TB) OS-30P SPONGE (138TB) Reference position for attachment...

  • Page 211: Main Pcb Unit

    MAIN PCB UNIT HEAT DISSIPATION SHEET (132CC) INSULATION TAPE (132DC) Radiate heat plate HEAT DISSIPATION INSULATION SHEET (132CC) TAPE (132DC) Reference position for attachment Reference position for attachment SHEET HEAT DISSIPATION HEAT (132CZ) SHEET (132CD) DISSIPATION SHEET (132CC) HEAT DISSIPATION HEAT SHEET SHEET...
  • Page 212 SCREW (1A-17035FD2) × 3 Boss × 2 SCREW (1A-17035FD2) SCREW (1A-17035FD2) HEAT DISSIPATION HEAT SHEET DISSIPATION (132C9) × 2 SHEET (132C8) HEAT HEAT DISSIPATION DISSIPATION SHEET SHEET (132C9) × 2 (132C8) Reference position for attachment Reference position for attachment...
  • Page 213 HEAT HEAT DISSIPATION DISSIPATION SHEET SHEET (132CA) × 2 (132CA) × 3 HEAT HEAT DISSIPATION DISSIPATION SHEET SHEET (132CA) × 2 (132CA) × 3 Reference position for attachment Reference position for attachment HEAT DISSIPATION SHEET SHEET (1334P) (132CB) HEAT DISSIPATION SHEET SHEET (132CB)
  • Page 214 MAIN PCB UNIT (139PB) Boss × 2 Radiate heat plate TAPE (132CY) TAPE (132CY) Reference position for attachment TAPE (132CY)
  • Page 215 TAPE (132CF) TAPE (132CY) TAPE (132CY) TAPE (132CY) TAPE (132CF) Reference position for attachment TAPE (132CF) SPONGE (132CE) GASKET (137G8) SPONGE (132CE) Reference position for attachment Reference position for attachment...
  • Page 216 SCREW (1A-17050FD2) × 5 Boss × 2 Hook...

  • Page 217: Top Cover Unit

    TOP COVER UNIT TOP COVER UNIT (1359B) TOP COVER UNIT (1359B) TOP COVER UNIT SCREW (1359B) (133VJ) SCREW SCREW SCREW (1264Y-A0P3H8) × 2 (1A-17040FD2) (1A-17030FD2) TOP COVER UNIT (1359B) SCREW (1A-17040FD2) SCREW SCREW (133VJ) SCREW (1A-17030FD2) (1264Y-A0P3H8) × 2...
  • Page 218 TOP COVER UNIT (1359B) SCREW (1A-17040FD2)

  • Page 219: Evf Unit

    EVF UNIT Boss × 2 Reference position for attachment SPONGE SPONGE OS-30P (134XU) (134XU) SPONGE (134XU)
  • Page 220 IF COVER UNIT (135AH) Boss × 2 IF COVER UNIT (135AH) SCREW (12H45) × 4 IF COVER UNIT SCREW (12H45) × 4 (135AH)

  • Page 221: Rear Cover Unit

    REAR COVER UNIT SCREW (12S07) × 2 SCREW (12H4B) × 2 SCREW (133VJ) × 2 SCREW (12S07) SCREW (12H46) SCREW (12H46) SCREW (12H45) SCREW (133TY) × 4 SCREW (12H48) × 2...
  • Page 222 Match the shape. DIOPTER ADJUSTMENT KNOB (127MU) SCREW (H1-17060FD2) MEDIA COVER UNIT Projecting section (135AD) MEDIA COVER MEDIA UNIT OS-30P COVER UNIT (135AD) (135AD) SCREW (12H45) × 4 COPPER FOIL TAPE (133TP) × 2 COPPER FOIL TAPE (133TP) × 2 Reference position for mounting...

  • Page 223: Name Plate

    SCREW BOTTOM (133TG) × 6 COVER PLATE (133UA) RUBBER (122TJ) × 4 NAME PLATE NAME PLATE (1334K) NAME PLATE (1334K) RUBBER CAP RUBBER CAP (1350K) RUBBER CAP (1350K)

  • Page 224: Neck-Strap Ring

    NECK-STRAP RING The cutting part of the neck-strap ring (1K100-035) should be incorporated inside the neck-strap ring cover (1K685-799). Cutting part Cutting part NECK-STRAP NECK-STRAP RING COVER RING (1K100- (1K685-799) 035) NECK-STRAP RING COVER (1K685-799) × 2 NECK-STRAP RING (1K100-035) × 2 NECK-STRAP RING (1K100-035) ×...

  • Page 225: Media Cover Lid Unit

    Match the shape. DIOPTER ADJUSTMENT KNOB COVER (12G7R) MEDIA COVER LID UNIT MEDIA COVER LID UNIT (135AC) Projecting section MEDIA COVER LID UNIT MEDIA COVER LID UNIT (135AC) (135AC)

  • Page 226: Battery Cover Unit

    BATTERY COVER UNIT SCREW (6A-17035FD2) × 2 SPRING (1K241-775) BATTERY COVER UNIT (139PE) Boss × 2 SPRING (137EM) BATTERY FIXING PLATE UNIT (135AF) CFD409Z BATTERY FIXING PLATE UNIT (135AF) SPRING (137EM) Hook spring × 2...
  • Page 227 SCREW (1K010-593) × 4 PLATE (133PX) Cutout Projecting section Reference position for mounting...

  • Page 228: Cable Clip Unit

    LEN317A CABLE CLIP UNIT CABLE CLIP UNIT (135HC) CABLE CLIP UNIT (135HC) CABLE CLIP UNIT (135HC) Boss...

  • Page 229: Switch Inspection Process

    Switch Inspection Process Tools and parts required: ● Your mirrorless camera Switch inspection Follow the steps below to perform a switch inspection. Inspection procedure Check the switch Operate the all switches of camera and check whether the assigned function is working. ●...

  • Page 230: Af Accuracy Inspection Process

    – Focus charts can be purchased at stores that sell camera-related products or online stores that sell camera-related products. – Nikon hereby disclaims all responsibility and liability for any focus charts or other items purchased from third party retailers. Camera settings ●...
  • Page 231 ● Diffraction correction: ON ● Automatic distortion correction: ON ● Vignette control: Standard ● Body VR: OFF ● Exposure delay mode: one to two seconds ● AF fine adjustment: OFF Shooting environment Install the camera/lens and chart, referring to the figure below. Shoot in a location that meets the following requirements: ●...

  • Page 232: Af Accuracy Inspection

    AF accuracy inspection Follow the steps below to inspect the AF accuracy. Inspection procedure Adjust the camera position 1. Adjust the shooting distance so that the entire focus chart is displayed on the screen as shown in the image below. •...
  • Page 233 Shoot the chart 1. Press the release button to shoot the target chart. 2. When checking before disassembling, check the inside of the red frame in the image, and record the focus position. 3. When checking after disassembling, confirm that there is no difference from the focus position recorded before disassembling.

  • Page 234: Vr Function Inspection Process

    – A Chart can be purchased at stores that sell camera-related products or online stores that sell camera-related products. – Nikon hereby disclaims all responsibility and liability for any focus charts or other items purchased from third party retailers. VR function inspection Follow the steps below to perform a VR function inspection.
  • Page 235 Camera settings Image quality FINE Focus mode AF-S Picture Control OFF / ON Image correction function (vignetting, diffraction, distortion) Metering method Center-weighted metering Exposure mode Shutter-priority auto (S) White balance Auto0 (Keep white) Aperture F4(Full open), The reciprocal of the focal length of a lens Shutter Speed (For example, if use a 50mm lens, set it to 1/50.)
  • Page 236 No reproduction in any form of this document, in whole or in part (except for brief quotation in critical articles or reviews), may be made without written authorization from NIKON CORPORATION. Out of concern for the environment, Nikon is working to reduce its use of paper. © 2024 Nikon Corporation...
