Radium LMZA4537 User Manual

Read all instructions before using or installing the product. Keep for future reference. Include the user manual when
passing the product on to third parties.
• The product is designed to control one
zone of lighting devices.
• Up to 30 lighting devices can be paired
with the product.
Product introduction
1
2
Status LED
1
On/Off button / Brightness button
2
Press once to turn on or off the light.
Press and hold to increase or decrease the brightness.
Pairing the controller to a zone of the remote control (without using a ZigBee hub)
1
Disconnect the cable
connection 4 times in
succession between the
controller and driver unit.
4×
2
Check the LED strip
light. It flashes twice
when ready for pairing.
4
Check the LED strip light. It flashes twice slowly, then turns off for a few
seconds, and finally flashes twice slowly when pairing is successful.
slow (2×)
• The product only works with the
LMZA4376 controller.
• Protocol: ZigBee 3.0
• Transmission frequency: 2.4 GHz
• Transmission line: 10 mW
N
L
LMZA4376
Zigbee LED Controller
DC INPUT
Input Voltage: DC 24V
Red: V+
Max. Output Current: 3.5A
Black: V-
Max Output Power: 84W .
Made in China
OFF for a few seconds
Installing the wall holder
2.
1.
1. Attach the holder to a wall with a screw.
2. Insert the product onto the holder by aligning the notch with the
groove.
Installing/replacing the battery
Remove the insulation film from the battery before first use.
− The product requires a CR2025 (3 V) coin
− Slide open the battery tray for battery
− Make sure the polarity (+/-) is correct when
< 10 cm
Radium Lampenwerk GmbH
Dr.-Eugen-Kersting-Str. 6
51688 Wipperfürth
Germany
www.radium.de
LED OUTPUT
Red: LED+
Black: LED-
The paring mode has started when the status
LED
slow (2×)
Remote control
LMZA4537 | REMOTE DOT
User manual
• Transmission range (free field): 30 m
• Operation voltage: 3 V DC (CR2025)
• Protection rating: IP20 (Do not expose to
moisture)
Caution: Pay attention that the notch
must align with the groove. Otherwise,
it may be very difficult to remove the
product from the holder again.
battery.
installation or replacement.
installing the battery (with the "+" side
facing upward).
3
Place the product near
the controller (< 10 cm)
and press and release
the On/Off button
3 times consecutively.
Then within 2 seconds,
press and hold the On/Off
button for 4 seconds.
3×
1
flashes quickly for approx. 5 seconds.
5 sec.
OKM 4103524 AA V01
