Safety Precautions
INSTRUCTIONS
The rating plate and'the safety caution are on the rear of the unit.
WARNING — DANGEROUS. VOLTAGE INSIDE
TO PREVENT FIRE OR SHOCK HAZARD, DO. NOT EXPOSE THIS UNIT TO
WARNING:
RAIN OR MOISTURE.
IMPORTANT
Connection to the mains supply plug in the
United Kingdom.
Do not make any connection to the Larger Terminal coded E
or Green. The. wires in the mains lead are coloured in
accordance with the following code:
Blue to N (Neutral) or Black
Brown to L (Live) or Red
If these colours do not correspond with the terminal
identifications of your plug, connect as follows:
Blue wire to terminal coded N (Neutral) or coloured Black.
Brown wire to terminal coded L (Live) or coloured Red.
if in doubt — consult a competent electrician.
CAUTION
m When you are not using the recorder for a long period of time,
it ts recommended that you disconnect the power cord from
the AC outlet.
™ Dangerous voltage inside. Refer internal servicing to qualified
service personnel. To prevent electric shock or fire hazard,
remove the power cord from the AC outlet prior to connecting
or disconnecting any signal lead or aerial.
The OPERATE button does not completely shut off mains
power from the unit, but switches operating current on and
off.
This unit. is produced to comply with Directives 76/889/
EEC, 82/499/EEC, 87/308/EEC and Standard 1EC Publ. 65.
| IMPORTANT:
Please read the "Precautions" section of this instruction
manual before installing or operating the recorder.
BEMAERK: | stilling OFF er apparatet stadig forbundet med
lysnettet Hvis det gonskes fuldsteendig afbrudt skai
netledningen treekkes ud.
Omkoppiaren OPERATE pa denna apparat ar
sekundart kopplad och skiljer Inte apparaten fran
natet | lage OPERATE OFF.
EE
IMPORTANT: It may be unlawful to record or play back
copyrighted materia! without the consent of the copyright
owner,
Video tapes recorded with this video recorder in the LP
{Long Play) mode cannot be played back on a single-
speed video recorder.
625
Cassettes marked "S-VHS" and "VHS" can. be used with this
video cassette recorder. However, S-VHS recordings are
possible only with cassettes marked "S-VHS".
-COPYRIGHT © 1992 VICTOR COMPANY OF JAPAN, LTD.
Contents
Controls, indicators, And Connectors...
Getting To Know Your Video Recorder...
Getting Started With
Your Video Recorder
Making The Right Connections.
Handling Video Cassettes.
Setting The COCK...
Setting The Tuner
Mode Displays — What They Mean..
On-Screen Set Up.....csccsscccsscrerseenseesnen
Basic Operation Of
Your Video Recorder
Playback...
Recording...
Tirmer-RECOrdING ...sccssccssescssserseccscccssescoreessaserscnsensensseras 20
Special Functions On
Your Video Recorder
For Playback...
For Tape Access..
For Recording
For Timer-Recording...
For Convenience...
For Editing..
For Reception... .
Using The Remote Controj For TV Operation...
Using The Optional Teletext Adapter...
Display Panel Messages..
PrecautiOns.....ccccsscscmseceesoe
Specifications ..........
In Case Of Difficulties:
Special Note On Head Cleaning.
How To Use This Instruction Manual
This instruction manual has been
designed with both new and experienced
users in mind. The first half offers detailed,
step-by-step instructions for setting up your
video recorder, and on using its basic
functions. The second half provides
instructions on the many other functions
available on your video recorder. So just by
following the instructions on the "Getting
Started" and "Basic Operation" sections of
this manual, you: can master all of your
recorder's basic functions, including timer-
recording. Once you're sufficiently familiar
with basic operation, or if you're already an
experienced video user, you can move on to
_the more advanced functions introduced on
the following pages. Related features have
all been clustered together for easy |
reference, and their categories (playback,
recording, timer, etc.) are easily recognisable
. by the symbol appearing in the page header.
If you ever need to refer to another. page for
instructions or information; you will be told so
by a> mark pointing to the page number.
Remember, you must use your video
recorder correctly to fully enjoy it. Please use |
this manual effectively. It's the surest and
quickest way to unlock the full potential of
your new JVC video recorder.
