Seu Mini Hi-Fi System

TABLE OF CONTENTS

Technical specification ...........................................................1-16
Safety instruction......................................................................2-1
ESD protection......... ................................................................2-2
Set Block diagram ...................................................................3-1
Set Wiring diagram ..................................................................4-1
Disassembly diagram ..........................................................5-1-2
Layout diagram.................................................................6-2..6-3
Key & Display
Layout diagram.................................................................7-2..7-5
Amp & Tuner
Layout diagram.................................................................8-3..8-5
Mcu & CD
Layout diagram........................................................9-2~3..10-2~3
Mechanical Exploded view..... .......................................... .....11-1
©
Copyright 2010 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or
transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise without
the prior permission of Philips.
212
Published by LX 1
Service Audio
0
Version 1.
All manuals and user guides at all-guides.com
Circuit diagram....................................................................6-1
board
Circuit diagram....................................................................7-1
board
Circuit diagram............................................................8-1..8-2
board
Circuit diagram............................................................9-1..10-1
Subject to modification
Printed in The Netherlands
FWM6000/
Page
all
3141 785 37530

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FWM6000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Philips FWM6000

Summary of Contents for Philips FWM6000

  • Page 1: Table Of Contents

    Mechanical Exploded view............11-1 © Copyright 2010 Philips Consumer Electronics B.V. Eindhoven, The Netherlands All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise without the prior permission of Philips.

  • Page 2: Technical Specification

    Tuner Board Display Board Main Board Key Board Key Board Amp Board Usb Board Switch power Board Key mic Board VERSION VARIATION Type /Versions: FWM6000 x/77 x/78 Service policy Board in used: (BRAZIL) (EUROPE) (LATAM) (ARGENTINA) Main BOARD display BOARD...
  • Page 3 All manuals and user guides at all-guides.com 1 - 3 FWM6000 SH 190 Contact List 1 GENERAL PART 1 - FRONT PANNEL SPECICFICATION 2 GENERAL PART 2 - BACK PANNEL SPECICFICATION 3 GENERAL PART 3 - GENERAL SPECICFICATION 4 GENERAL PART 4 - TECHNICAL SPECICFICATION...
  • Page 4 Weight ( exclusive packing & batery )?KG Units in Dealercarton Remarks : used into Remark : GENERAL PART 1 - FRONT PANNEL SPECICFICATION Class No Issued Date FWM6000/ All Version 23-Sep-11 NAME : XB.ZHANG SH 190 - 1 CHECK: DATE :...
  • Page 5 All manuals and user guides at all-guides.com 1 - 5 F.M. Anntena A.M. Antenna Aux Input A.C. Voltage Selector AC INTPUT SubWoofer Socket LOW /HIGH Left / Right Speaker Socket CABINET l a i Diemensions without Boxes ( wxhxd ) ?mm X ?mm X ?mm Finshing : Chrome Plate s t i &...

  • Page 6: General Description

    Tested according to General Test Instruction refer to PHILIPS standary ( UAN -D1591 ) Measured according to PHILIPS standary ( UAN - L1059 ) unless other wise stated All not mentioned date, please refer to PHILIPS standary ( XUW - 0010 - JUNE 2001 ) Remarks...
  • Page 7 Measuremend output power only for AUX model and CD model of used audio analyzer equipment. (*2) GENERAL PART 1 - TECHNAICAL SPECICFICATION Class No Issued Date 23-Sep-11 FWM6000 All Version NAME : XB.ZHANG SH 190 - 4 CHECK DATE :...
  • Page 8 Reference level for the test is 1.7V on the speaker terminals. Tabel 2 ( Tolerance ± 3dB ) Frequency DBB OFF DBB 1 DBB 2 DBB 3 60 Hz +1.5 GENERAL PART 1 - GENERAL SPECICFICATION Class No Issued Date 23-Sep-11 FWM6000/All Version NAME :XB.ZHANG SH 190 - 6 CHECK...
  • Page 9 Inject sine wave 2V to AUX-IN or Line input socket withfrequency indicated in Table 5 (input level 600mV for /37,2V for /55 ). FREQ Max OFF Max ON 60 Hz 1 kHz 12 kHz GENERAL PART 1 - AUDIO SIGNAL SPECICFICATION ( 2 ) Class No Issued Date 23-Sep-11 FWM6000/ All Version CHECK...
  • Page 10 No of Timer Settings Nom : 1 sec/day Limit : 2 sec/day Clock Accuracy INDICATORS Display Type(only FWM462/FWM653) Display Type(only FWM663) Remark Input sensitivity CLOCK / TIMMER SPECICFICATION Class No Issued Date 23-Sep-11 FWM6000/ All Version SH 190 - 8 CHECK DATE :...
  • Page 11 Electrical Parameters are to be measured at speaker teminals across 6 ohm load with 500mW output and DSC setting in Jazz Mode i t a > e t l > USB SPECICFICATION Class No Issued Date 23-Sep-11 FWM6000/ All Version NAME : XB.ZHANG CHECK DATE :...
  • Page 12 30db Nom. FM 98 MHz 108 dBu 25db Lim. 116 dBu 45db Nom. FM 108 MHz 108 dBu Lim. Remarks：MAX.Sens -6dB TUNER SPECICFICATION Class No Issued Date 23-Sep-11 FWM6000/ All Version NAME :XB.ZHANG SH 190 - 10 CHECK DATE :...
  • Page 13 3. This unit can playback (only) CD-R or CD-RW discs. For performance specification, Please refer to module. specification of CD99 (3103 308 52190) CD / MP3 SPECICFICATION Class No Issued Date 23-Sep-11 FWM6000/ All Version NAME : XB.ZHANG SH 190 -11 CHECK DATE :...

  • Page 14: General Part

    Microphone Frequency response ±3 63HZ volume 23,input leven 1mv rms, FL/FR ch 1KHZ connect main load ±3 10KHZ Remarks : testing with 20 to 20k Hz filter USB SPECICFICATION Class No Issued Date 23-Sep-11 FWM6000/ All Version CHECK DATE :...
  • Page 15 < ± 2 ± 3 i t a i t a input sensitivity Remark ( *1 ) Measured at iPOD level 2)testing with 20 to 20k Hz filter iPOD SPECICFICATION Class No Issued Date 23-Sep-11 FWM6000 All Version NAME : XB.ZHANG CHECK...

  • Page 16: Version Overview

    All manuals and user guides at all-guides.com 1 - 16 VERSION OVERVIEW FWM6000 DEST SURR MAINS SAFETY Wave RANGE GRID AERIAL SOCKET AERIAL SUPPLIED SOC. CORD . SPK. VOLTAGE EN60065 110-127V FM 87.5-108MHz MW 100kHz CLASS II 75 Ohm Coaxial...

  • Page 17: Block Diagram

    AC CORD (SI4730/31) LCD DRIVER 3CD LOADER SENSOR ET8862 MOTOR DRIVER POWER Board Motor Driver IC SA5888 TA7291S PICK UP FWM6000 8M SERIAL (FOR 300W) FALSH MOTOR CONTROL DATA EN25T80 CD SERVO BU9543 SWITCH POWER SUPPLY BX8805 128pin QFP 16M SDRAM...

  • Page 18: Wiring Diagram

    All manuals and user guides at all-guides.com WIRING DIAGRAM...
  • Page 19 All manuals and user guides at all-guides.com 1)Remove 9 screws A and 6 screws B/C as indicated to loosen the outer plate. 3CD PARTS Front Cab. Rear Plate Bottom Plate...
  • Page 20 All manuals and user guides at all-guides.com 1)Remove 2 screws A and 1 screw B as indicated to loosen the Main Board. 2)Remove 2 screws C and 1 screw D as indicated to loosen the Tuner Board. 3)Remove 2 screws E and 4 screws F as indicated to loosen the Amp Board. 4)Remove 6 screws G as indicated to loosen the Switch power Board.
  • Page 21 All manuals and user guides at all-guides.com...
  • Page 22 All manuals and user guides at all-guides.com PCB LAYOUT - MAIN BOARD TOP SIDE...
  • Page 23 All manuals and user guides at all-guides.com PCB LAYOUT - MAIN BOARD BOTTOM SIDE...

  • Page 24: Circuit Diagram

    All manuals and user guides at all-guides.com CIRCUIT DIAGRAM - KEY BOARD CN611 MUTE AMP ON AM_HOPPNG1 240K R692 R613 CN602 C668 C674 33U 16V C669 C623 RIGHT CD-R C691 R615 R654 470P R668 220R C605 10U R626 C675 0.15u AGND R612 R-IN...
  • Page 25 All manuals and user guides at all-guides.com PCB LAYOUT - KEY BOARD...
  • Page 26 All manuals and user guides at all-guides.com PCB LAYOUT - KEY/MIC BOARD...
  • Page 27 All manuals and user guides at all-guides.com PCB LAYOUT - DISPLAY BOARD TOP SIDE...
  • Page 28 All manuals and user guides at all-guides.com PCB LAYOUT - DISPLAY BOARD...

  • Page 29: Circuit Diagram

    All manuals and user guides at all-guides.com CIRCUIT DIAGRAM - AMP BOARD...

  • Page 30: Circuit Diagram

    All manuals and user guides at all-guides.com CIRCUIT DIAGRAM - TUNING/POWER BOARD 1N5401 D815 3300UF/35V C806 C802 1K 1W C803 0.02U CON801 R837 1N5401 D817 +29V 1K 1W R801 C826 0.02U R836 D816 1N5401 1K 1W R838 T801 1K 1W C804 0.02U -29V...
  • Page 31 All manuals and user guides at all-guides.com PCB LAYOUT - AMP BOARD TOP SIDE...
  • Page 32 All manuals and user guides at all-guides.com PCB LAYOUT - AMP BOARD...
  • Page 33 All manuals and user guides at all-guides.com PCB LAYOUT - TUNER BOARD...

  • Page 34: Circuit Diagram

    All manuals and user guides at all-guides.com CIRCUIT DIAGRAM - MCU BOARD +3V3 +3V3 L109 +3V3 FB220R USB+5V R1126 USB+5V ENC R ENC_R 8 VCC GND1 R1105 ENC L 7 /HOLD ENC_L AMP_ALC# AMP_ALC# R180 AMP_ALC IC102 6 CLK IP_TX# IP_TX# R103 N25S80(8MB)
  • Page 35 All manuals and user guides at all-guides.com PCB LAYOUT - MCU BOARD TOP SIDE...
  • Page 36 All manuals and user guides at all-guides.com PCB LAYOUT - MCU BOARD BOTTOM SIDE...

  • Page 37: Circuit Diagram - Cd Board

    All manuals and user guides at all-guides.com 10-1 10-1 CIRCUIT DIAGRAM - CD BOARD FWM3000/35000 NC GPIO193 R533 R535 TO CON551 3U3/50v DM+1 C536 DOOR MOTOR CD-R DM-1 CON1 This GND 2PIN/2.5MM/90C must be 100n C532 C520 R536 C533 use AGND 470P C519 100u/16v...
  • Page 38 All manuals and user guides at all-guides.com 10-2 10-2 PCB LAYOUT - CD BOARD TOP SIDE...
  • Page 39 All manuals and user guides at all-guides.com 10-3 10-3 PCB LAYOUT - CD BOARD BOTTOM SIDE...

  • Page 40: Exploded View

    All manuals and user guides at all-guides.com 11-1 11-1 EXPLODED VIEW...

Table of Contents
