Kramer T-IN2-REC1 Quick Start Manual

Scan to see website
Step 1: Check What's in the Box
The 4 products listed above represent the basic order.
Enclosure sheet
metal box
For White or Aluminum frame and/or White locking device, order separately frame and locking device
accordingly.
Step 2: Table Cutout Dimensions
•
T-IN2-REC1 – 131 x 58mm (5.16" x 2.28")
•
T-IN4-REC1 - 231 x 58mm (9.09" x 2.28")
•
T-IN6-REC1 - 331 x 58mm (13.03 " x 2.28")
Kramer recommends using the cutout template (packed with device) and a hole saw for maximal accuracy.
Step 3: Place Enclosure – Fasten Screws
1. Keep screws until the 'dog ear' is fastened to the table.
2. Fit to standard table thickness between 10-50 mm (0.39" - 1.97").
T-IN2-REC1, T-IN4-REC1, T-IN6-REC1
Quick Start
T-IN2-REC1, T-IN4-REC1, T-IN6-REC1
Quick Start Guide
This guide helps you install and use your
Go to www.kramerav.com/downloads/T-IN2-REC1, www.kramerav.com/downloads/T-IN4-REC1
www.kramerav.com/downloads/T-IN6-REC1
upgrades are available.
Black Locking
device
T-IN2-REC1, T-IN4-REC1,
to download the latest user manual and check if firmware
Black frame
Cutout
template
P/N: 2 9 0 0 - 3 0 1 7 7 9 QS
T-IN6-REC1 for the first time.
&
Rev: 2
