Kramer TS-PEU Installation Instructions

Universal socket power extension for modular tbus

Installation Instructions

MODEL:

TS-PEU

for Modular TBUS

SAFETY WARNING

Disconnect the unit from the power supply before opening and servicing

See

www.KramerAV.com

For the latest information on our products and a list of Kramer distributors, visit our Web site where

updates to these installation instructions may be found.

We welcome your questions, comments, and feedback.

www.KramerAV.com

info@kramerel.com

Universal Socket Power Extension

for updated safety information

2900- 300777QS

P/N:

Rev:

Table of Contents

Do you have a question about the TS-PEU and is the answer not in the manual?

Page 1: Installation Instructions
Disconnect the unit from the power supply before opening and servicing www.KramerAV.com for updated safety information For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to these installation instructions may be found. We welcome your questions, comments, and feedback.
Page 2 The TS-PEU includes six universal power sockets: one on the surface of the unit and five hidden neatly under the table. To use TS-PEU, simply pull it out of the TBUS surface using the handles and lay it on the table. When not in use, carefully slide the TS-PEU into the TBUS.
Page 3 Installing the TS-PEU The Kramer TS-PEU fits into a dual power socket opening. To install the TS-PEU: Place the TS-PEU under the dual power socket opening of a frame. Tighten the bracket using the two M3x8 screws (supplied with the package).
Page 4 Technical Specifications Ports 6 power universal connectors Power Source Universal: 100-240V AC, 50/60Hz, 5A, maximum 5A per power outlet (AC power limits): Fully compatible with power plugs in the UK, India, Italy and Denmark, as well as with the 2-prong Europlug. Partially compatible (if the polarity is reversed) with plugs in China, Switzerland, Israel and the USA.
