- Page 1 Hobie Kayak ® Rigging Stand Instructions Please read the instruction manual before using this product.
-
Page 2: Parts And Assembly
Parts and Assembly Parts Floor Bars (2) Kayak Bunks (2) Quick Pins (4) Long Scupper Bolts (Pro Anglers only) (2) Medium Scupper Bolts [2] Short Scupper Bolts (2) Threaded Scupper Tubes (2) - Page 3 Slide the kayak bunk bars over the uprights on the floor bars. Make sure that the mounting holes on the bunks are aligned. Mounting Holes Lock the quick pins through the holes to hold the stand together.
- Page 4 Attaching Kayak to Stand Single Kayaks Please note that if you are putting a Sport, Lanai or Inflatable kayaks on the stand, you will not be able to use the bolts and should be strapped down by other means. Place the kayak on the stand and line up the suppers in the cargo well (behind seating area) with the holes located toward the back of the kayak stand.
- Page 5 Tandem Kayaks Tandem kayak displays require two stands. For the back stand, place the kayak on the stand and line up the suppers in the cargo well (behind seat- ing area) with the holes located toward the back of the kayak stand. Set the front stand in a loaction that will not interfere with the Mirage Drive.
- Page 6 Attaching Kayak to Stand Pro Angler Kayaks Make note of directions 1A and 1B. Use direction 1A if you have a Pro Angler without a Vantage Seat and direction 1B if you do have the Vantage Seat. Non-Vantage Seat Pro Anglers Unthread and remove the two forward-most drain plugs under the seat and place the kayak on the stand.
- Page 7 3. Never stand up in the kayak. 4. This stand is designed to hold Hobie kayaks only. 5. If you use a Plug-in Cart to transport the stand, remove them before allowing anyone to sit in the display kayak.
- Page 8 Hobie Cat Company Holding Company Oceanside, California, USA 1-800-HOBIE-49 hobiecat.com Hobie Cat Australasia Subsidiary Huskisson, New South Wales, Australia 1-800-4-HOBIE hobiecat.com.au Hobie Cat Europe Subsidiary Toulon, France +33(0)494 08 78 78 hobie-cat.net Hobie Kayak Europe Independent Distributor Stellendam, The Netherlands +31(0)187 499 440 hobie-kayak.com...
