- Page 1 Hobie Rudder Ready Transducer Mount Please read the instruction manual before using this product.
- Page 2 These instructions will guide you through the installation of the fishfinder kit on your kayak. These are basic guide- lines that will allow you to understand the kit, but keep in mind that all kayaks and transducers are slightly different and you can customize your installation in many ways.
- Page 3 Parts Parts 2 X Rudder Ready Adapters 2 X Rubber Washers 2 X Screws 6-32x1-5/8” Screw 6-32x 3/4” 3 X 6-32 Nylock Nuts 7 X Zip -ties Tools needed: Drill 5/32” drill bit 3/16” drill bit Phillips screwdriver Angle pliers or knife...
-
Page 4: Mounting The Transducer
A video of this install is available on YouTube to help guide you through the installation process. You can find it by searching for “Hobie rudder ready installation kit” on YouTube. Mount the transducer... - Page 5 3C) Using the holes in the rudder ready mounts, drill 5/32” Pro tip holes. : Drill the first hole and place a screw through it to hold the mount and aid hole alignment.
- Page 6 Mounting the Transducer Using the remaining screws and nuts, fas- ten the transducer to the rudder. Tighten all screws.
- Page 7 Running the Transducer Cable Run the Transducer Cable Using a 3/16” drill bit, drill holes and use the included zip-ties to fasten the transducer wire to the back of the rudder.
- Page 8 Running the Transducer Cable Note: If your boat is a rigid hull, we recommend running the cable inter- nally using the Hobie Thru-hull Plug kit included with Fishfinder Installation kit PN: 72020101. Be sure your transducer cable has enough slack to not interfere with any rudder operations.
-
