- Page 1 Installation Guide For HyPanel Pro Smarter Home Sweeter Life...
- Page 2 Welcome! This guide applies to the following models of HyPanel Pro: PG71-KNX-EU and PG71N-KNX-EU.
-
Page 3: Before We Start
Before We Start Your first time installing this product may take up to 40 minutes. You'll get faster after each installation. Warning! The installation procedure may involve handling high voltage wiring. Please be careful. To avoid serious personal injury, death, or property damage, turn OFF the power to the circuit and follow all safety precautions before proceeding. - Page 4 In the Box HyPanel Pro x 1 Flush Mounted Module x 1 Hex Key x 1 ST3x20mm Phillips Self Tapping Screw x 2...
-
Page 5: Check Compatibility
Check Compatibility Product dimensions IO GND BOTTOM VIEW 42.8 214.0 31.0 L L L2 L1 11.8 RJ45 AUX- AUX+ KNX- KNX+ BACK VIEW RIGHT VIEW FRONT VIEW LEFT VIEW 50.0 TOP VIEW... -
Page 6: Working Space
Working space Make sure HyPanel Pro is compatible with the location where you want to install it. 50mm HYPANEL PRO FRONT VIEW 40mm SIDE VIEW: HYPANEL PRO IN WALL A 50mm(2 inches) deep electrical box is highly recommended for ease of installation. In some scenarios, especially when the wires ADA Compliance Requirement can be pushed back into the wall far enough, it may be possible to GROUND... -
Page 7: Maximum Load
Maximum load The total load of the device(s) connected to HyPanel Pro must be less than 1800W(Max load). The wattage of a resistive load appliance, e.g., an incandescent bulb, must be less than 900W. The wattage of a LED lamp or compact fluorescent lamp(CFL) must be less than 150W. - Page 8 Wiring Warning! Turn OFF the circuit breaker before wiring and proceeding! Always use a voltage detector to verify the power is OFF before wiring and installation!
-
Page 9: Rear Connections
Rear connections L In(Connect to any L port) L1 Out AUX- AUX+ KNX- KNX+... - Page 10 RING RING IO GND IO GND The Line wire (L) provides 100-240 Volts of power to the HyPanel Pro. L1 and L2 are Load wires that connect the HyPanel Pro to the light bulbs or other devices, e.g., fans or curtain motors. KNX+ and KNX- are connected to KNX bus.
-
Page 11: Connect Wires
Connect wires Strip and straighten wires The line and load wires connected to HyPanel Pro should be 0.75mm² - 1.6mm² in size and must have stripped and straight ends. Remove the plastic sheathing of the wire, and make sure the exposed wire ends measure approximately 8 mm (5/16 inch) in length. - Page 12 Connect all wires Always make sure the arrow on the front of the flush mounted module is pointing up.
- Page 13 RJ45 AUX- KNX+ AUX+ KNX- Connect KNX and AUX cables to the corresponding terminals. If you need to link other devices Connect the Line wire into any one of the L ports. Insert the Load wire(s) to the L1 and/or L2 ports. Tighten the screws clockwise with a flat-head screwdriver until wires are secure.
-
Page 14: Installation
Installation Insert screws Insert the supplied screws into the designated holes on the electrical box. Change the torque on the electric screwdriver to 5kgf.cm. Turn screws clockwise with the screwdriver. Do not fully tighten the screws. The screw head must protrude at least 3 mm (1/8 inch) from the wall surface. - Page 15 Install flush mounted module Attach the flush mounted module to the electrical box. The screws should go through the holes on the module.
- Page 16 Adjust the module to be level and ensure it is flush against the wall. Tighten the screws to attach the module to the wall, taking care not to over-tightened them.
- Page 17 Install panel Turn OFF the circuit breaker before you install the panel. Line up the two clips on the flush mounted module with the notches on the panel. Snap the panel into place and press it down.
- Page 18 Check the panel is properly clipped onto the module and is flush against the wall. Locate the screw hole on the bottom of the panel. There is a screw already in it. Tighten the screw with the included hex key.
- Page 19 If you need to remove the panel 1.Turn the screw with the hex key until the rear edge of the panel comes loose. 2.Hold the panel's top with one hand, and pull the panel outwards from the bottom.
- Page 20 Congratulations! You are done with the HyPanel Pro installation! Start your smart home journey with Akubela now! Get Help For help or more assistance, contact us at: https://ticket.akuvox.com/ For videos, guides, and additional product formation, visit us at: https://knowledge.akuvox.com...
