- Page 1 HyPanel Lux Quick Guide...
-
Page 2: Table Of Contents
Welcome This guide applies to RT61-KNX-EU model of HyPanel Lux. Contents Before We Start In the Box Check Compatibility Wiring Installation Get Help... -
Page 3: Before We Start
Before We Start Your first time installing this product may take up to 40 minutes. You’ll get faster after each installation. WARNING The installation procedure involves handling high voltage wiring. Please be careful. To avoid serious personal injury, death, or property damage, turn OFF the power to the circuit and follow all safety precautions before proceeding. -
Page 4: In The Box
In the Box HyPanel Lux x 1 Flush Mounted Module x 1 Silicone Washer x 6 M4x20mm Phillips Machine Screw x 2 M2x5mm Phillips Machine Screw x 2 ST3x20mm Phillips Self Tapping Screw x 2... -
Page 5: Check Compatibility
Check Compatibility Product dimensions(mm) BOTTOM VIEW 86.5 20.5 12.8 31.0 RIGHT VIEW LEFT VIEW FRONT VIEW BACK VIEW 51.0 TOP VIEW... -
Page 6: Working Space
Working space Make sure HyPanel Lux is compatible with the location where you want to install it. A 50mm(2 inches) deep electrical box is highly recommended for ease of installation. In some scenarios, especially when the wires can be pushed back into the wall far enough, it may be possible to use a 40mm(1.6 inches) deep box. -
Page 7: Power Requirements
For HyPanel Lux: A 21-30VDC power supply is required. For load devices: A 100 - 240VAC power supply is needed. Support Wi-Fi and Ethernet connections HyPanel Lux can operate with both wireless and wired networks. A wired connection is recommended for greater reliability and faster data exchange. -
Page 8: Wiring
The Line wire (L) connects to any one of the L terminals, providing 100-240 Volts of power to the load devices. L1 and L2 are Load wires that connect the HyPanel Lux to the light bulbs or other devices, e.g., fans or curtain motors. -
Page 9: Connect Wires
Connect wires �.Strip and straighten wires Wires connected to your HyPanel Lux should be 1.5mm² ~ 2.5mm² in size and must have stripped and straight ends. Remove the plastic sheathing of the wire, and make sure the exposed wire ends measure approximately 8 mm (5/16 inch) in length. -
Page 10: Installation
Installation Confirm installation direction HyPanel Lux can be either vertically or horizontally installed. If you want to mount the flush mounted module vertically, we strongly recommend that you have its clips on the top and the screw holes at the bottom. - Page 11 Select screws Select the proper screws fitting your electrical box. Change the torque on the electric screwdriver to 5kgf.cm. Turn the screws clockwise with a screwdriver. Do not fully tighten the screws. The screw head must protrude at least 3 mm (1/8 inch) from the wall surface.
- Page 12 Install flush mounted module Attach the flush mounted module to the electrical box. The screws should go through the holes on the module. Adjust the module to be level and ensure it is flush against the wall. Tighten the screws to attach the module to the wall, taking care not to over-tightened them.
- Page 13 Test connected devices Test Button Turn on the circuit breaker to provide power to the flush mounted module. Press the button on the module to check if the connected device can work properly. Press the button once to turned on/off the device. Long press the button to adjust the brightness of the device.
- Page 14 Install panel WARNING Turn OFF the circuit breaker before you install the panel. Line up the two clips on the flush mounted module with the notches on the panel. Snap the panel into place and press it down.
- Page 15 Since HyPanel Lux can be mounted either vertically or horizontally, the screw holes would be in different positions depending on the chosen orientation. Check the panel is properly clipped onto the module and is flush against the wall. Use two M2x5mm machine screws to secure...
- Page 16 If you need to remove the panel Remove the machine screws. Press firmly on the panel with one hand on the clips side. With your other hand, grasp the panel from the screwing side and pull it outward.
-
Page 17: Get Help
Congratulations! You are done with the HyPanel Lux installation! Start your smart home journey with Akubela now! Get Help For help or more assistance, contact us at: https://ticket.akuvox.com/ For videos, guides, and additional product formation, visit us at: https://knowledge.akuvox.com...
