Fan LEDs
Fan LEDs
Table 11: Fan LED Indicators
Color/State
Off
Green
Amber
XPS LED
Note
Table 12: XPS LED
Color
Off
Green
Blinking green
Amber
Blinking amber
For information about the XPS 2200, see the Cisco eXpandable Power System 2200 Hardware Installation
Guide on Cisco.com:
http://www.cisco.com/go/xps2200_hw
S-PWR LED
Table 13: S-PWR LED
Color
Off
Green
Blinking green
Cisco Catalyst 9300 Series Switches Hardware Installation Guide
18
This LED is not supported on Cisco Catalyst 9300L Series switches.
Description
XPS cable is not installed.
Switch is in StackPower mode.
XPS is connected and ready to provide back-up power.
XPS is connected but is unavailable because it is providing power to another device
(redundancy has been allocated to a neighboring device).
The XPS is in standby mode or in a fault condition. See the XPS 2200
documentation for information about the standby mode and fault conditions.
The power supply in a switch has failed, and the XPS is providing power to that
switch (redundancy has been allocated to this device).
Description
StackPower cable is not connected, or the switch is in standalone mode.
Each StackPower port is connected to another switch.
This appears on the switch in a StackPower ring configuration that detects an open
ring or has only one StackPower cable connected.
Description
The fan is not receiving power; the fans have stopped.
All fans are operating normally.
One or more fans have encountered tachometer faults.
