- Page 1 7” TFT Monitor HYU-IN-MO7004 User Manual...
-
Page 2: Parts And Function
Parts and function Backlight LED 7” TFT display Mute indicator Divert indicator MIC(bottom) Touch keys Speaker(side) Doorbell button Talk voice volume switch BUS line Talk/Monitor Unlock Scroll up Scroll down Mute Divert Talk voice volume switch: the volume of the speaker voice when talk with door station, up means high, down means low. - Page 3 Connec�ons A B C D DBC4A1 Doorbell Button A B C D DBC4A1 door DPS(V2) HDR-30-24 station NOTICE: the HYU-IN-MO7004 monitor does not support DT-IPG, RLC light mode requries update RLC to support. HYU-IN-MO7004 monitors does not support in-out connection.
-
Page 4: Installation Setup
Mounting Installation Setup 1. Address setup By monitor menu a. Tap ,to get into main menu b. In main menu, long press unlock key c. Tap (refers ) to set monitor address d. Tap (refers ) to set monitor master slave Address. -
Page 5: Master/Slave Setup
By call activate a. When power up and standby (HYU-IN-MO7004 is screen off), press and hold Press and hold Release b. Call from door station with designed address, to activate the address.. Dial desired Dial desired Press desired number number... - Page 6 3. Auto call back After 1 and 2 setups, HYU-IN-MO7004 can apply a calling from HYU-IN-MO7004, simulator a call from door station. When power up and standby (HYU-IN-MO7004 is screen off), press and hold for 3s Press and hold Release User personaliza�on setup...
- Page 7 2. Change ringtone melody 3 sets of the ring tune selectable. When standby, into main menu, tap (refers )to switch the melody between 3 sets, after switch HYU-IN-MO7004 will play the melody for door station calling, inner call, and ring button separately. 01.01 ADDR 01.01...
- Page 8 DS.1 00:03 3. Monitor door sta�on When power up and standby (HYU-IN-MO7004 is screen off), or in main menu, to start monitoring door station 1. In monitoring check “Operation, point 2) for operations. DS.1 00:03 01.01 ADDR 01.01 4. Intercom call / Inner call...
- Page 9 GU: to Guard Unit. INNER: to monitor with the same address. 5. Opera�ng the light thought DT-RLC/Mini RLC When power up and standby (HYU-IN-MO7004 is screen off), into main menu, refer to light up RLC’s light. When the icon turns in yellow means light up 01.01...
- Page 10 Restore Factory Se�ng To restore to the factory default settings, by following steps. 1.Disconnect the HYU-IN-MO7004 from bus line, wait for 30s, and connect to bus line. 2.Within 10s power up, press and hold for 12s, release when and LED 3.A long beep means all setting rest to factory default...
- Page 11 Specifica�on 13.8mm 186.2mm HYU-IN-MO7004 Power Supply: DC20 ~28 V Power Consumption : standby 9mA,working 127mA Working Temperature : -15ºC ~ +55ºC ; Wiring: 2 wires, non-polarity Monitor screen: 7 Inch digital color LCD Operation Dimension: HYU-IN-MO7003:186.2*139.2*13.8mm (not include the metal support)
- Page 12 For Inquiries, Please Contact: Security Shop Vladimira Nazora 1 11077 Novi Beograd, Serbia Tel: +381 11 318 68 68 office@securityshop.rs Imported/Distributed by Security Shop doo Licensed by Hyundai Corporation Holdings, Korea Delivery and After Service shall only be covered within Serbia...
