INSTALLATION GUIDE
Orion
01/27
Copyright © 2024 Salto Systems, S.L.
227992 - ED.0 - 08/07/2024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Orion and is the answer not in the manual?

Questions and answers

Related Manuals for Salto Orion

Summary of Contents for Salto Orion

  • Page 1 INSTALLATION GUIDE Orion 01/27 Copyright © 2024 Salto Systems, S.L. 227992 - ED.0 - 08/07/2024...

  • Page 2: Table Of Contents

    What’s in the box? 05 - 06 Orion Camera Orion Control Unit Placement 09 - 10 Installation 11 - 32 Commissioning 33 -41 Specifications and Requirements 42 -44 02/27 Copyright © 2024 Salto Systems, S.L. 227992 - ED.0 - 08/07/2024...

  • Page 3: Considerations

    The Orion Camera requires a minimum lighting level of 100 Lux in the vertical plane, 600mm from the Orion Camera. In low lighting conditions, (e.g. outdoors at night) lighting should evenly illuminate the user’s face.
  • Page 4 (18-65 with 10mm shoes) Positioning It is important to position the Orion Camera at the spe- cified height. The camera is designed to operate opti- mally for a user population from 5th %ile adult females, to 95th %ile adult males and at a range from approxima- tely 300mm to approximately 600mm.

  • Page 5: What's In The Box

    INSTALLATION GUIDE I Orion What’s in the box? Orion C Orion C Orion C Face Plate Camera Wall Mount Bung (X4) (X4) 3000 (118-1/8”) Orion C 3 meter Cat6 shielded cable 05/27 Copyright © 2024 Salto Systems, S.L. 227992 - ED.0 - 08/07/2024...
  • Page 6 INSTALLATION GUIDE I Orion What’s in the box? Orion CU Orion CU Orion CU (Control Unit) (Control Unit) (Control Unit) DIN mount Fixing plates (X4) (X4) 06/27 Copyright © 2024 Salto Systems, S.L. 227992 - ED.0 - 08/07/2024...

  • Page 7: Orion Camera

    INSTALLATION GUIDE I Orion Orion Camera (3-3/16”) (2-3/16”) (2-3/32”) 07/27 Copyright © 2024 Salto Systems, S.L. 227992 - ED.0 - 08/07/2024...

  • Page 8: Orion Control Unit

    INSTALLATION GUIDE I Orion Orion Control Unit (4-19/64”) Orion C Network (5 -29/32”) 08/27 Copyright © 2024 Salto Systems, S.L. 227992 - ED.0 - 08/07/2024...

  • Page 9: Placement

    INSTALLATION GUIDE I Orion Placement Installation of a Control Unit above a ceiling behind the locked door (not in the corridor or space outside the locked door), using the provided Orion C 3 metre-long cable. (11-13/16”) 09/27 Copyright © 2024 Salto Systems, S.L.
  • Page 10 INSTALLATION GUIDE I Orion Placement Installation of a Control Unit in a cabinet behind the locked door (not in the corridor or space outside the locked door), using the provided Orion C 3 metre-long cable. (11-13/16”) 10/27 Copyright © 2024 Salto Systems, S.L.

  • Page 11: Installation

    Using the window, position the Camera Wall Mount at the correct height and mark the hole centres. Ensure the wall mount is positioned horizontally using a spirit level. 11/27 Copyright © 2024 Salto Systems, S.L. 227992 - ED.0 - 08/07/2024...
  • Page 12 Max Ø 30 ( Ø1-3/16” ) Drill 4 holes for the mount points and the access hole for the RJ45 cable. INSTALLATION Mount the Orion C Wall Mount using the wall Plugs and Screws 12/27 Copyright © 2024 Salto Systems, S.L.
  • Page 13 Route the RJ45 Cable to the Camera Wall Mount making sure the minimum bend radius of 60mm is observed. A larger bend radius is preferred. Ensure there is no strain on the cable connection. 13/27 Copyright © 2024 Salto Systems, S.L. 227992 - ED.0 - 08/07/2024...
  • Page 14 INSTALLATION GUIDE I Orion INSTALLATION Plug the RJ45 cable into the Orion Camera. INSTALLATION Rotate Camera and snap Locate the Wall Mount into the Wall Mount. tongue into the slot on the top of the Orion Ensure there is no strain on Camera casing.

  • Page 15: Commissioning

    Avoid using electric screwdrivers to minimise damage to the device. INSTALLATION STOP DO NOT Remove backing! WARNING: Face Plate must only be attached after commissioning. 15/27 Copyright © 2024 Salto Systems, S.L. 227992 - ED.0 - 08/07/2024...
  • Page 16 INSTALLATION GUIDE I Orion INSTALLATION Control Unit Din Rail Mounting Option INSTALLATION Orion CU Din Rail Type assembly 16/27 Copyright © 2024 Salto Systems, S.L. 227992 - ED.0 - 08/07/2024...
  • Page 17 INSTALLATION GUIDE I Orion INSTALLATION INSTALLATION 17/27 Copyright © 2024 Salto Systems, S.L. 227992 - ED.0 - 08/07/2024...
  • Page 18 INSTALLATION GUIDE I Orion INSTALLATION Control Unit Wall Mounting Option INSTALLATION Orion CU Wall mount assembly 18/27 Copyright © 2024 Salto Systems, S.L. 227992 - ED.0 - 08/07/2024...
  • Page 19 INSTALLATION GUIDE I Orion INSTALLATION 74.5 (2-15/16”) INSTALLATION INFORMATION DRILL BIT Ø 5 (Ø 13/64”) DRILL BIT Ø 3.5 (Ø 9/64”) 19/27 Copyright © 2024 Salto Systems, S.L. 227992 - ED.0 - 08/07/2024...
  • Page 20 INSTALLATION GUIDE I Orion INSTALLATION INSTALLATION 20/27 Copyright © 2024 Salto Systems, S.L. 227992 - ED.0 - 08/07/2024...
  • Page 21 INSTALLATION STOP DO NOT Power off. Leave system on in readiness for commissioning Status display returns to alternating yellow and white to indicate precommission standby mode. 21/27 Copyright © 2024 Salto Systems, S.L. 227992 - ED.0 - 08/07/2024...
  • Page 22 Be sure to engage the screwdriver with one of the slots before attempting to turn it. Turn very small amounts to adjust. Take care not to damage the head of the adjuster 22/27 Copyright © 2024 Salto Systems, S.L. 227992 - ED.0 - 08/07/2024...
  • Page 23 INSTALLATION GUIDE I Orion COMMISSION For instructions regarding commissioning the Orion Server, please go to the Orion Software User Manual. The Orion Console allows each Orion Camera to COMMISSION be paired with its associated SALTO door using a uniquely generated QR code.
  • Page 24 Press the “Ready” the lis of doors, and show the QR code to the Orion button to check that the select the correct one. Camera. This will initiate the UCMe has appeared on pairing, and the camera will display the ready list.
  • Page 25 LED will turn off and then show a flashing blue light whilst the Camera is initializing. This will turn to continuous white once initialization is complete. 25/27 Copyright © 2024 Salto Systems, S.L. 227992 - ED.0 - 08/07/2024...
  • Page 26 A final layer of protection and integrity is provided by this cover. Therefore, take special care to ensure that the cover is stuck correctly to the full surface of the camera casing. 26/27 Copyright © 2024 Salto Systems, S.L. 227992 - ED.0 - 08/07/2024...

  • Page 27: Specifications And Requirements

    Orion devices do not require access outside of the VLAN. DHCP DHCP is required to provide IP addresses to Orion devices. The Orion server must have a reserved IP address that cannot change once Orion devices have been commissioned. Orion Server will require access to DNS.
