Related Manuals for Elfi FWL1600-01
Summary of Contents for Elfi FWL1600-01
- Page 1 LoRa Card Model FWL1600-01 User's Manual Description – Installation – Technical Data Hardware Revision: 1.0.0 Software Revision: 2.0.0 Manual Revision: 1.0.0...
- Page 2 Technical specifications of the Analogcard General Model FWL1600-01 Dimensions 10 cm (length) × 5.6 cm (height) × 18.5 cm (depth) Weight 0.2 Kg Operating Temperature -10°C to 45°C Storage Temperature -20°C to 60°C Operating Humidity 0% to 60% Warranty 2 years...
-
Page 3: Safety Precautions
SAFETY PRECAUTIONS (Before using this product, read the precautions) Please carefully read this manual before using the product and pay full attention to the mentioned points to use the product correctly. In this guide, safety measures are classified into two levels: " Warning"... - Page 4 may result in electric shock, fire, malfunction, or damage, and degrade the quality of the module. ● Never directly touch the conductive parts or electronic components of the LoRa card. Doing so may cause malfunction or failure of the data logger. Note: Never insert or remove cards while the device is powered on.
- Page 5 1. Introduction The LoRa Data Card Model FWL1600-01 is one of the data reception cards for wireless sensors and is also compatible with the FIDAQUIRE Data Logger Model FCD6455-01. The data received from the sensors can be either analog or digital. The LoRa card has the capability to simultaneously receive data from all sensors connected to it.
- Page 6 2. Indicators on the card Figure 2: Cover card image ● The top row lights indicate the online and offline status of the channels. If no data is received from any channel for 30 seconds, the light corresponding to that channel will turn off.
- Page 7 3- Installing the LoRa card on the FIDAQUIRE data logger The process of identifying and initial setup of the card is completely automatic, and after installing and setting up the data logger, the card will be displayed on the "Cards list"...
- Page 8 4- Card and Nodes settings ● To configure the LoRa card, follow these steps: (1) Select the "Config" menu and enter the settings page (Figure 5). (2) Fill in the "Card Name" and "Card Description " fields. (3) In the Lora Setting section, the configurations for Bandwidth, Spread Factor, and Channel can be adjusted.
- Page 9 Figure 5: Card settings page ● The "Alarms" menu displays the list of alarms defined for each channel or subchannel. It allows for editing alarms, enabling or disabling them, and deleting alarm alerts. Additionally, the "Logs" menu provides a detailed list of alarm information and the time of occurrence (Figure 6).
- Page 10 Figure 7: Errors Log Page for the Card To apply further settings to each channel, click on any of them to display the Node settings page (Figure 8). ● The "General" menu includes information about the Node's status, model, serial number, input data type, and Node number.
- Page 11 Figure 9: Config Menu of the Node Settings Page ● The "SDO" menu is used to modify the parameters of Interval , Bandwidth, Spread Factor and Channel. The "Write" sub-menu is used for changing settings, and the "Read" sub-menu is used for reading settings (Figure 10). Figure 10: SDO Menu from the Node Settings page.
- Page 12 ● To read each of the Interval, Bandwidth, Spread Factor, and Channel parameters: (1) Click on the "Read". (2) Select the desired parameter. (3) By selecting the "Send Command", you can view the information related to that parameter. ● To change any of the Interval, Bandwidth, Spread Factor, and Channel parameters: (1) Click on the "Write".
- Page 13 (4) Adjust the Bandwidth, Spread Factor, and Channel of the card to match the values set for the Node. The second method is more efficient because it allows testing after each of the three parameters of the card and Node have been changed.
-
Page 14: Contact Information
Contact information Fidar Electronics co. Add: West Azarbaijan, Urmia, Iran Tel: 021- 91308515 E-mail: info@fidarelectronics.com Website: www.fidarelectronics.com...
