- Page 1 Analog Card Model FAM4400-01 User's Manual Description – Installation – Technical Data Hardware Revision: 1.0.0 Software Revision: 2.0.0 Manual Revision: 1.0.0...
- Page 2 Technical specifications of the Analogcard General Model FAM4400-01 Dimensions 10 cm (length) × 5.6 cm (height) × 18.5 cm (depth) Weight 0.2 Kg Operating Temperature -10°C to 45°C Storage Temperature -20°C to 60°C Operating Humidity 0% to 60% Warranty 2 years...
-
Page 3: Safety Precautions
SAFETY PRECAUTIONS (Before using this product, read the precautions) Please carefully read this manual before using the product and pay full attention to the mentioned points to use the product correctly. In this guide, safety measures are classified into two levels: " Warning"... - Page 4 environment may result in electric shock, fire, malfunction, or damage, and degrade the quality of the module. ● Never directly touch the conductive parts or electronic components of the Analog card. Doing so may cause malfunction or failure of the data logger. Note: Never insert or remove cards while the device is powered on.
- Page 5 1. Introduction The analog data card model FAM4400-01 is one of the analog data acquisition cards with very high accuracy and an error rate of 0.1% FSO. It is compatible with the data logger FIDAQUIRE model FCD6455-01. This card can simultaneously receive four differential voltage lines from 0 -10 volts and four current lines from 4-20 mA.
- Page 6 2. Settings 1.2 Data Transmission Settings To change the data transmission settings, five dip switches are provided on the card ( Figure ). The three switches on the left determine the interval between data transmissions, covering intervals of one second, 5 seconds, 10 seconds, one minute, two minutes, five minutes, and ten minutes.
- Page 7 Figure 2: Image related to card settings o Connect the maximum current or voltage value (depending on the type of channel) to the input terminal. o By briefly pressing the `func` button, the maximum value of the current channel will be recorded. o Repeat this process for all channels.
- Page 8 Figure 3: Image related to the card surface 3.2. Connections The power supply and input circuit of the analog data card model FAM4400-01 are designed to be completely isolated. Additionally, a connection point to the chassis is provided on the ground of the isolated section of this card (by default, this connection is open) so that it can be connected to the chassis if needed, depending on the schematic of the existing equipment.
- Page 9 3- Installing the Analog card on the FIDAQUIRE data logger The process of identifying and initializing the card is fully automated, and after the data logger device is installed and set up, the card will appear on the "Cards list" page.
- Page 10 4. Card and Channel Settings ● To configure the analog card, follow the steps below: (1) Select the "Config" menu to open the "General" page from the settings menu (Figure 6). (2) Fill in the fields for "Card Name" and "Card Description ".
- Page 11 Figure 7: Active Channels Page from the Config Menu (4) By selecting the "Next Step" option, you will enter the "Channels Data Map" page, where you can configure the settings for each channel (Figure 8). Figure 8: Channels Data Map Page from the Config Menu...
- Page 12 (5) Select "Save Config" to save the applied settings (Figure 8). Note: To deactivate the card, you can do so on the "General" page from the Config menu. ● The "Alarms" menu displays a list of defined alarms for each channel. It allows you to edit alarms, enable or disable them, and delete alarm alerts.
-
Page 13: Contact Information
Contact information Fidar Electronics co. Add: West Azarbaijan, Urmia, Iran Tel: 021- 91308515 E-mail: info@fidarelectronics.com Website: www.fidarelectronics.com...
