Number Name
Raspberry Pi
①
GPIO Header
② Switch
③ M.2 Interface
④ SIM Card Holder
USB 3.1
⑤
Connector
USB Type-C
⑥
Connector
⑦ Audio Port
Antenna
⑧
Connector
⑨ Reset Switch
⑩ Power Switch
Cooling Fan
⑪
Indicator
⑫
Easily connect to Raspberry Pi
Enable the corresponding pin
Compatible with RM500U-CN / RM500Q-CN / RM500Q-GL /RM50XQ-AE and
other series of 5G modules
Onboard two SIM card slots, dual card single standby. The default SIM1 card
slot works, SIM2 is on the back, requires module support, and must be switched
through AT commands
Backward compatible with USB 2.0, can be used to connect to PC/Raspberry
Pi/Jetson Nano, etc.
5V 3A input; stable and flexible power supply
SIM82XX series support audio function, RM50XX series do not support this
audio function
Onboard four-way antenna, strong signal
One-key reset
To facilitate the power supply mode of the control module:
——If set to USB, the module will provide power through the "⑤.USB3.1
interface";
——If set to EXT PWR, the module will provide power through the "⑥.USB
Type-C interface" external power supply
Cool down the Raspberry Pi and 5G module at the same time
Check the module running status anytime, anywhere
Description
