BEFORE YOU BEGIN
Please read these instructions carefully to familiarize
yourself with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation. This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
All information in these instructions is based upon the latest
product information available at the time of publication.
Kohler China reserves the right to make changes in product
characteristics, packaging, or availability at any time without
notice.
These instructions contain important care, cleaning, and
warranty information - please leave instructions for the
consumer.
ORDERINGINFORMATION
HYGIENE URINAL (0.5L/1L/2.5L)................................................................................................................................ K-5777ID-ER
RECOMMENDED TOOLS AND MATERLALS (NOT SUPPLIED)
• Open end/adjustable wrenches
• Tape measure
• Basin wrench
• Pipe wrench
• Square
• Level
• Pliers
• Socket wrench with sockets
No.2 KOHLER ROAD, SANSHUI CENTRAL INDUSTRIAL PARK, LEPING TOWN, SANSHUI DIST.,
8# MENGSHAN RD, ECONOMIC DEVELOPMENT ZONE OF HUANTAI, ZIBO,
NO.1 KOHLER STREET, ECONOMIC DEVELOPMENT ZONE OF FAKU COUNTY, SHENYANG
1493733-T01-A
FOSHAN, GUANGDONG, PRC POST CODE: 528137
SHANDONG, CHINA POST CODE: 256410
LIAONING PROVINCE, PRC POST CODE: 110400
Observe all local plumbing and building codes.
Carefully inspect the new urinal for damage.
Site preparation may require additional tools and hardware.
Fixture dimensions are nominal and conform to tolerances
established by ASME Standards (A112.19.2-2018).
The product complies with GB/T 6952-2015, GB
28377-2019.
CAUTION: Risk of personal injury or product damage.
Handle with care. Vitreous china can break or chip if the
product is handled carelessly.
• Screw driver
• Seal tape
• Connection wire
• Wire cutter
• Insulation tape
• Bushing
• Drill
• Sealant
© Copyright Kohler China Investment Co., Ltd. 2021
-1-
STRUKTURA
INSTALLATION INSTRUCTIONS
HYGIENE URINAL (0.5L/1L/2.5L)
K-5777ID-ER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STRUKTURA K-5777ID-ER and is the answer not in the manual?

Questions and answers

Summary of Contents for Kohler STRUKTURA K-5777ID-ER

  • Page 1 • Drill • Sealant • Socket wrench with sockets No.2 KOHLER ROAD, SANSHUI CENTRAL INDUSTRIAL PARK, LEPING TOWN, SANSHUI DIST., FOSHAN, GUANGDONG, PRC POST CODE: 528137 8# MENGSHAN RD, ECONOMIC DEVELOPMENT ZONE OF HUANTAI, ZIBO, SHANDONG, CHINA POST CODE: 256410 NO.1 KOHLER STREET, ECONOMIC DEVELOPMENT ZONE OF FAKU COUNTY, SHENYANG...
  • Page 2: Prepare The Site

    Floor Fig.1 Kohler reserves the right to change marked dimensions without prior notice. Notice: To ensure an effective flush performance, strongly recommended inner diameter of water supply (including water meter, valve, etc.) is no less than 25mm, and supplied water pressure (sensor inlet dynamic pressure) is 0.18MPa ~0.55MPa.
  • Page 3: Installation

    INSTALLATION A. Install hangers, L-shaped block, waste pipe connector and hygiene spout inlet angle valve. Drill holes according to the template. Install hangers, L-shaped block, waste pipe connector and hygiene spout inlet angle valve. (Gasket of waste pipe connector shall be soaked in water for 2 seconds to lubricate), install inlet hose ( for connect the control box) Note: the angle valve and inlet hose need to be purchased by the customer Insert the connector into the...
  • Page 4 3. Hang the urinal onto the hangers. 4. Pull the bottom of the urinal outwards to make space. Align the big nut with the waste pipe and then tighten. 5. Push the urinal against wall and tighten it with screws. Connect the Connect the control box control box cable...
  • Page 5 3. Connect the hose with the trap. 4. Screw the trap onto the drain and screw tight. 5. Screw tight the nut of the drain mentioned in step. Fig.9 6. Screw on the drain lid. Fig.10 E. Install the control box assembly Install the control box assembly as shown below 1.
  • Page 6: Important Consumer Information

    (calcium hypochlorite) can seriously damage fittings in the urinal. This damage can cause leakage and property damage. Kohler Company shall not be responsible or liable for any damage to these urinal fittings caused by the use of cleaners containing chlorine (calcium hypochlorite).
