Mitek Jack Table Equipment Manual

Platen press

Quick Links

Download this manual

Equipment Manual

Jack Table

™

Platen Press

001094

Rev. A

Patented. See Legal Notice for list of patents.

Table of Contents

Troubleshooting

Need help?

Do you have a question about the Jack Table and is the answer not in the manual?

Questions and answers

Summary of Contents for Mitek Jack Table

Page 2 Equipment Manual Jack Table ™ Platen Press U.S. and other patents pending. MiTek Part Number 001094 Machinery Division Date Created 1 August 2007 Created By R. Widder 301 Fountain Lakes Industrial Drive Reviewed By R. Tucker St. Charles, MO 63301 Approved By G.
Page 3: Legal Notice
Document Evaluation Form in the appendices. Mail or fax the form to: MiTek, Machinery Division 301 Fountain Lakes Industrial Drive St. Charles, MO 63301 Attn: Engineering Manager Fax: 636-328-9218 Your support in helping MiTek provide unsurpassed machinery and support is appreciated. 001094 Rev. A Legal Notice...
Page 4: Notice Of Change
Notice of Change Use this page to record Service Bulletins and Notices that you receive to keep your manual updated. Jack Table™ Platen Press Service Bulletin Dated Title or Notice # 001094 Rev. A Notice of Change...
Page 5: Table Of Contents
Web Site ....... . .3 Contacting MiTek ......3...
Page 6: Contents
Equipment Layout ......19 Installing the Jack Table ..... . 19 Placing the Table .
Page 7 Contents Wearing Personal Protective Equipment ..34 Conducting Safety Tests ....34 Overview Graphics ......35 Operating Procedures for Maintenance Personnel 36 Adjustments .
Page 8 Contents Maintenance Checklists Appendix C ........79 Technical Information Appendix D .
Page 9: Safety (English)
Safety (English) For safety information in Spanish, refer to page xix. Be Careful. Be Safe. 001094 Rev. A Safety (English) viii...
Page 10: Safety Indicators
Jack Table™ Platen Press Safety Indicators The following safety alert symbols and signal words are used throughout this document to indicate safety hazards. Please pay careful attention when you see them. The level of severity differs for each symbol or signal word.
Page 11: Safety Rules
Jack Table™ Platen Press Safety Rules Because it is impossible to anticipate every circumstance that might involve a hazard, the safety information provided in this equipment manual and on the machine is not all- inclusive. If this machine is operated or serviced using a procedure not specifically recommended by the manufacturer, the procedure shall be approved by a professional engineer to ensure it will not render the equipment unsafe.
Page 12: Electrical Safety
Jack Table™ Platen Press Lockout/Tagout • Before performing maintenance on the pneumatic or hydraulic systems, bleed the lines to eliminate pressure. • Lockout/tagout all energized systems before performing maintenance on them. Refer to the Lockout/Tagout Guidelines section on page xii.
Page 13: Lockout/Tagout
Jack Table™ Platen Press Lockout/Tagout Lockout/Tagout Guidelines All lockout/tagout guidelines must be met according to OSHA 29 CFR 1910.147. A specific procedure should be included in your company’s energy control program. This manual is not intended to replace your company’s de- energizing or lockout/tagout procedure required by OSHA, but merely to provide general guidance.
Page 14: Electrical Lockout/Tagout Procedures
Jack Table™ Platen Press Electrical Lockout/Tagout Procedures When Working on a Machine Outside the Machine’s Main Electrical Enclosure If working on the electrical transmission line to the machine, follow the procedure on page xv. Before performing maintenance on any machine with electrical power, lockout/tagout the machine properly.
Page 15 Jack Table™ Platen Press Figure SAFETY-1: Lockout/Tagout on the Main Electrical Enclosure Sample of a Lock and Tag Attached to a Machine’s Electrical Enclosure 001094 Rev. A Safety (English)
Page 16 Jack Table™ Platen Press When Working on a Machine Inside the Machine’s Main Electrical Enclosure or in the Electrical Transmission Line to the Machine Before opening the main electrical enclosure, or attempting to repair or replace an electrical transmission line to the machine, lockout/tagout the machine properly. Follow your company’s approved lockout/tagout procedures which should include, but are not...
Page 17: Troubleshooting With An Energized Machine
Jack Table™ Platen Press Hydraulic System Lockout/Tagout Procedure When Lockout/Tagout is Not Required If working on components other than the hydraulic system, but that requires you to be near the vicinity of movable hydraulic components, you must, at a minimum, physically restrain the hydraulic components from moving.
Page 18: Restricted Zone
Jack Table™ Platen Press Restricted Zone DANGER Stay out of the restricted zone when equipment is in use. Serious injury or death may result if personnel are in the restricted zone. 001094 Rev. A Safety (English) xvii...
Page 19: Safety Test
Jack Table™ Platen Press Safety Test WARNING CRUSH HAZARD. Perform the safety tests described before operating the equipment at the initial startup, after performing any maintenance, and in accordance with the maintenance schedule. The test procedure MUST be performed by qualified personnel at startup and after ANY maintenance, adjustment, or modification.
Page 20: Seguridad (Español)
Seguridad (Español) Sea cuidadoso. Protéjase. 001094 Rev. A Seguridad (Español)
Page 21: Indicadores De Seguridad
Jack Table™ Platen Press Indicadores de seguridad Los siguientes símbolos de alerta de seguridad y palabras de advertencia se utilizan a lo largo de este documento para indicar riesgos de seguridad. Preste suma atención cuando los vea. Cada símbolo o palabra indica un nivel de gravedad diferente.
Page 22: Reglas De Seguridad
Jack Table™ Platen Press Reglas de seguridad Debido a la imposibilidad de anticipar todas las circunstancias que podrían constituir un riesgo, la información de seguridad suministrada en este manual del equipo y sobre la máquina no es exhaustiva. Si se utiliza o realiza el mantenimiento de esta máquina utilizando un procedimiento no recomendado específicamente por el fabricante, el...
Page 23 Jack Table™ Platen Press Instalación del equipo • Siga las instrucciones de instalación al pie de la letra. Procedimientos de Bloqueo/Etiquetado • Antes de realizar el mantenimiento de los sistemas neumáticos o hidráulicos, purgue las líneas para eliminar la presión.
Page 24 Jack Table™ Platen Press • Verifique que todos los dispositivos de seguridad estén en buen funcionamiento al comienzo de cada turno. Todos los dispositivos protectores y de seguridad deben estar en su lugar antes y durante el uso de la máquina. No desconecte ni evite nunca ningún dispositivo de seguridad ni interbloqueo eléctrico.
Page 25: Bloqueo/Etiquetado
Jack Table™ Platen Press Bloqueo/Etiquetado Pautas de bloqueo/etiquetado Deben cumplir con todas las pautas de bloqueo/etiquetado conforme a la norma OSHA 29 CFR 1910.147. El programa de control de energía de la compañía debe incluir un procedimiento específico. El objetivo de este manual no es reemplazar el procedimiento de desenergización o bloqueo/...
Page 26 Jack Table™ Platen Press Procedimientos de bloqueo/etiquetado eléctricos Cuando trabaja en una máquina fuera del gabinete eléctrico principal de la máquina Si trabaja en la línea de transmisión eléctrica a la máquina, siga el procedimiento de la página xxvii. Antes de realizar el mantenimiento de cualquier máquina con alimentación eléctrica, bloquee y etiquete la máquina de forma adecuada.
Page 27 Jack Table™ Platen Press Figura SEGURIDAD-1: Bloqueo/etiquetado en el gabinete eléctrico principall Ejemplo de un candado y etiqueta fijados al gabinete eléctrico de una máquina 001094 Rev. A Seguridad (Español) xxvi...
Page 28: Procedimiento De Bloqueo/Etiquetado De Sistema
Jack Table™ Platen Press Cuando trabaje en una máquina dentro del gabinete eléctrico principal de la máquina o en la línea de transmisión eléctrica a la máquina Antes de abrir el gabinete eléctrico principal o intentar reparar o reemplazar una línea de transmisión eléctrica a la máquina, bloquee y etiqueta la máquina en forma adecuada.
Page 29 Jack Table™ Platen Press Cuando se requiere bloqueo/etiquetado Antes de intentar reparar o realizar el mantenimiento de una línea o componente hidráulico, bloquee y etiquete la máquina en forma apropiada. Siga los procedimientos de bloqueo/etiquetado aprobados por la compañía. 001094 Rev. A Seguridad (Español)
Page 30: Solución De Problemas Con Una Máquina Energizada
Jack Table™ Platen Press Solución de problemas con una máquina energizada Sólo un electricista calificado que utilice el equipo de protección personal y siga los procedimientos recomendados en la norma NFPA 70E debe intentar realizar tareas de reparación o mantenimiento en un área o componente energizados de la máquina o en su proximidad.
Page 31: Zonas Restringida
Jack Table™ Platen Press Zonas restringida Manténgase afuera de la zona restringida cuando el equipo esté en uso. Pueden producirse lesiones graves o incluso la muerte si el personal está en la zona restringida. 001094 Rev. A Seguridad (Español)
Page 32: Prueba De Seguridad
Jack Table™ Platen Press Prueba de seguridad RIESGO DE APLASTAMIENTO. Realice las pruebas de seguridad descritas antes de utilizar el equipo al ponerlo en marcha por primera vez, después de realizar cualquier tarea de mantenimiento y conforme al plan de mantenimiento.
Page 33: Introduction
This manual addresses the most recent versions of the equipment as of the creation or revision date on the title page. For earlier revisions, contact MiTek Machinery Division Customer Service. The part number is listed on the title page, but the revision you require depends on the date your equipment was manufactured.
Page 34: Navigation
Jack Table™ Platen Press Navigation The graphics in Table 1-1 are used throughout the manual to quickly communicate a specific type of information. Table 1-1: Navigational Tools Used Throughout the Manual Graphic Explanation Important safety note! Indicates that you must lockout/tagout at the disconnect switch located on the equipment using approved methods described in OSHA 29 CFR 1910.147 before continuing...
Page 35: Additional Resources
MiTek manual provides. Web Site Visit the MiTek Web site at www.mii.com for up-to-date information on all MiTek equipment. View the latest revision of this manual and all Service Bulletins, or order parts...
Page 36: General Information Chapter
Variations include U-channel jigging slots, dual operator controls, 30- or 50-ton hydraulic press, and plastic, wood, or drilled steel table tops. Figure 2-1 and Figure 2-2 show a Jack Table. Refer to the Maintenance chapter for more detailed graphics.
Page 37 Jack Table™ Platen Press Figure 2-2: Getting to Know Your System (U-Channel with 30-Ton Hydraulic Unit Shown) Unistrust Jigging Slots (Optional) Gantry Operator Controls Table Main Electrical Enclosure Festoon System Table Hydraulic Power Unit (HPU) 001094 Rev. A General Information...
Page 38: Main Components And Optional Equipment
Jack Table™ Platen Press Main Components and Optional Equipment Table 2-1 lists the main components that comprise this system. Table 2-1: Main Components Component Description Part # Provides a pressing surface for the truss; Table with U-channel available in 20', 25', 30', 35' and 40' lengths...
Page 39: General Specifications
Jack Table™ Platen Press General Specifications Table 2-3: General Specifications General Maximum truss height Maximum truss length Length of table Blocking 2'' standard, 3'' and 4'' available Table length 20', 24', or 30'' Table width Table top material 3/4'' plywood and 1'' plastic, drilled steel...
Page 40: Truss Terminology
Jack Table™ Platen Press Truss Terminology Table 2-4: Truss Terminology Length Types Height Types Overall length Board height Centerline length Centerline height Top length Centerline height Bottom length Centerline height Figure 2-3: Terminology Diagram Overall Length Top Length Bottom Length...
Page 41 Jack Table™ Platen Press Figure 2-4: Parts of a Truss 001094 Rev. A General Information...
Page 42: Prior To Installation Chapter
2. A layout showing how you have indicated that you wish the equipment to be arranged within your building. During Installation For an additional fee, a MiTek Customer Service Technician (CST) can be present to oversee the installation of your equipment. 001094 Rev. A...
Page 43: Customer Responsibilities
Space should have adequate lighting. Reinforced concrete, a minimum of 6 in. thick 3,500 psi, is required to support the weight of the Jack Table. Location The equipment discussed in this manual must be used in dry...
Page 44: Space Requirements
Space Requirements Refer to your individual layout when planning your space allocation. Refer to Table 3-2 for approximate dimensions. MiTek can provide help with plant layout and space utilization upon request. Figure 3-1: Sample of a Layout for a Complete System 001094 Rev.
Page 45: Location Requirements
Jack Table™ Platen Press Space for the Equipment It is the customer’s responsibility to provide adequate space for the installation, operation, and protection of the equipment. The physical dimensions of the equipment are shown in Table 3-2. Additional space is required for operation, maintenance, and optional equipment.
Page 46: Electrical Requirements
Jack Table™ Platen Press Electrical Requirements WARNING ELECTRICAL HAZARD! All electrical work must be performed by a licensed electrician. Follow approved lockout/tagout procedures (OSHA 29 CFR 1910.147). The standard electrical requirements are shown in Table 3-3. Each machine can be adapted for use with any of the incoming voltages listed.
Page 47: Hydraulic System Requirements
Jack Table™ Platen Press Hydraulic System Requirements WARNING 10 gallons of HIGH PRESSURE HAZARD. hydraulic fluid must be available Compressed air and hydraulic lines should be installed only by for the initial qualified personnel familiar with all governing regulations. Failure...
Page 48: Customer-Supplied Parts
If a MiTek representative is not required to be present, it is your responsibility to ensure all necessary personnel read the Equipment Manual and address all guidelines and safety instructions given.
Page 49: Installation Chapter
These requirements are explained in the Prior to Installation chapter. This equipment generally does not need a MiTek representative to be present for the installation. All customer responsibilities before and during installation are...
Page 50: Unloading
Refer to... Table 3-4 on Even if a MiTek representative is present, it is the customer’s responsibility to provide page 15 for the equipment and labor for unloading, placement, and wiring of the equipment. Two heavy- weight of each...
Page 51: Equipment Layout
Equipment Layout Each component must be located in specific locations. Refer to your own layout during installation. Your MiTek representative will provide your layout to you before the equipment is installed. Installing the Jack Table Placing the Table 1.
Page 52: Leveling The Table
Jack Table™ Platen Press 1) Using an industrial hammer drill and a 1/2-in. drill bit, drill a hole at least 6 in. deep through the holes in the table anchor plates. For best results, drill the hole completely through the concrete pad.
Page 53: Hydraulic System
Jack Table™ Platen Press Hydraulic System Hydraulic Fluid See Table 7-1 on page 41 in the Maintenance chapter for hydraulic fluid specifications. The indicated amount of hydraulic fluid must be available during installation. CAUTION Add hydraulic fluid before turning on the system.
Page 54: Electrical System
The machine design addresses electrical components starting with the disconnect enclosure. Installation and maintenance of all electrical requirements up to the disconnect enclosure are the responsibility of the customer. Your MiTek representative can provide guidance regarding when the electrical will need to be available during the installation.
Page 55: Installation Checklist
Connect power to the machine’s main electrical enclosure  WARNING ELECTROCUTION, HIGH PRESSURE, CRUSH, CUT, AND CHEMICAL HAZARDS! Do not attempt to start the system without a MiTek representative present! Serious injury and/or equipment damage may result. 001094 Rev. A Installation...
Page 56: Preparing The Hydraulic System
Startup Chapter 5 This chapter describes the procedures required before operating Purpose of Purpose of your equipment. Chapter Chapter Preparing the Hydraulic System Fill the hydraulic reservoir with hydraulic fluid that matches the specification listed in Table 7-1 on page 41. Ensure that you have the required amount of hydraulic fluid prior to The equipment is planning the startup.
Page 57: Operation
Operation Chapter 6 This chapter describes the operating mechanisms on Purpose of Purpose of this equipment and the procedure to operate it in most Chapter Chapter circumstances. Before You Begin Safety Operating Notes WARNING ELECTROCUTION, HIGH PRESSURE, CRUSH, CUT, AND CHEMICAL HAZARDS! Read this section AND the safety section in the preliminary pages before operating or maintaining this equipment.
Page 58: Stopping The Machine
Jack Table™ Platen Press Stopping the Machine Emergency stops (E-stops) immediately cease electrical power transmitting to the control circuit. Utilize the E-stop on this machine to cease power, which will stop the pressing action of the machine. The gantry will coast a few inches after an E-stop is pressed.
Page 59: Disconnect Switch
Jack Table™ Platen Press Disconnect Switch Figure 6-3: Disconnect Switch Figure 6-3 shows the location of the disconnect switch that controls the power supplied from that switch to the rest of the machine. Turning the disconnect handle to the ON position supplies electrical power to the entire machine.
Page 60: Operator Control Interface
Jack Table™ Platen Press Operator Control Interface Figure 6-4: Overview of Control Mechanisms Auto-Raise Enabled Hydraulic Filter Element Indicator Replacement Indicator Raise Start Stop E-Stop Opto-Touch Opto-Touch Button Button Joystick Auto-Raise/Disable Switch Table 6-2: Functions of Control Mechanisms Mechanism Function...
Page 61: Operating Procedure
See Table 7-1 on page 41. • In extremely cold climates, it is recommended that you install an optional heater unit. Contact your MiTek Sales Representative for more information. 5. Turn the AUTO-RAISE/DISABLE switch to auto-raise to enable the auto-raise function.
Page 62: Restart Procedure
• In cold weather, allow the pump and hydraulic fluid to warm up until they reach the recommended operating temperature. See Table 7-1 on page 41. • In extremely cold climates, it is recommended that you install an optional heater unit. Contact your MiTek Sales Representative for more information. 001094 Rev. A Operation...
Page 63: Hydraulic System Operation
Jack Table™ Platen Press Hydraulic System Operation Hydraulic System Overview The hydraulic motor controls the horizontal motion of the gantry. It is controlled by a solenoid valve. The pressing motion is controlled by two vertically-oriented hydraulic cylinders which are controlled by separate solenoid valves.
Page 64: Maintenance
Certain operating environments may necessitate preventive maintenance at more frequent intervals. Because consistent preventive maintenance is so important for keeping mechanical equipment in good operating condition, MiTek recommends that you stock certain replacement parts to minimize downtime. Review the table of contents and utilize the index to locate the information you need. The following appendices will also assist in maintaining and repairing your equipment: •...
Page 65: Performing Maintenance Safely
Jack Table™ Platen Press Performing Maintenance Safely Read the safety pages in the preliminary pages and adhere to all rules and guidelines. This section provides additional safety information specific to maintenance topics. Before Operating This Equipment Adhere to these warnings before operating this equipment:...
Page 66: Making Adjustments
Order all replacement parts through MiTek. Do not substitute parts without first consulting MiTek to determine if it is safe and effective. No electrical system component, cable, connector, or device should be modified, removed, disconnected, or changed without specific approval and guidance from MiTek.
Page 67: Overview Graphics
Overview Graphics Figure 7-1 provides an important overview of the equipment to help you better understand the procedures in the Maintenance chapter. Figure 7-1: Gantry and Hydraulic Components Discussed in the Maintenance Chapter 001094 Rev. A Maintenance...
Page 68: Operating Procedures For Maintenance Personnel
Jack Table™ Platen Press Operating Procedures for Maintenance Personnel The platen should be in the lowered position for all maintenance unless specifically indicated otherwise. After performing any maintenance that requires the hydraulic lines to be drained, cycle the cylinders and motors at least five (5) times before operating the system.
Page 69: Adjustments
2. When the pressing height is properly adjusted, retighten the mounting bolt to secure the puck in place. 3. If the pressing height has been adjusted, you must replace the blocking. See Replacing the Blocking on page 66. Contact your MiTek Sales Representative to order additional blocking. Adjusting the Finger Guide Bars CAUTION PINCH HAZARD.
Page 70 Jack Table™ Platen Press Adjusting the Support Wheel Pressure The support wheels provide support to the underside of the table and hold the gantry drive wheels in contact with the track. See Figure 7-11 on page 58. CAUTION Improper adjustment of the support wheels could cause the wheels to slip while the gantry is driven.
Page 71: Cleaning, Lubricating, And Inspecting
Jack Table™ Platen Press Cleaning, Lubricating, and Inspecting Cleaning DANGER CRUSH AND CUT HAZARD Guards must always be in place during operation to avoid serious injury and possibly death. Always replace guards after maintenance is complete and before removing the lockout/tagout device.
Page 72: Lubricating With Grease
Jack Table™ Platen Press Lubricating With Grease Bearings Grease all bearings weekly. Refer to the Bearings section for bearing locations and the procedure for lubricating them. CAUTION Do not overgrease the bearings. Excess grease may cause bearing seals to rupture.
Page 73: Hydraulic System
Jack Table™ Platen Press Hydraulic System CAUTION HIGH PRESSURE HAZARD. Bleed all pressure from the lines before performing any maintenance on the hydraulic components. Hydraulic Fluid Specifications Refer to Table 7-1 for hydraulic fluid specifications. See the footnote if operating outside the recommended temperature range.
Page 74: Replacing The Filter Element
Jack Table™ Platen Press Replacing the Filter Element Figure 7-5: Return Line Filter Refer to Figure 7-5 for the location of the filter element. Replace the filter element when the indicator light on top of the operator control station illuminates to indicate a filter change is necessary, and two weeks after the annual hydraulic fluid replacement.
Page 75 Jack Table™ Platen Press Tips for Replacing Hydraulic Fluid • It is best to change hydraulic fluid when the system is at operating temperature. This will drain off as much of the impurities in suspension as possible. • To eliminate the possibility of spillage, use a suction pump to remove the fluid from the reservoir.
Page 76 Jack Table™ Platen Press Hydraulic Components Reservoir The reservoir contains the hydraulic fluid. Electric Motor The electric motor turns the hydraulic pump to create flow of hydraulic fluid. For replacement instructions, see Replacing the HPU Electric Motor on page 50.
Page 77 Jack Table™ Platen Press Regenerative Valve (50-Ton Unit Only) The regenerative valve allows the hydraulic fluid to cycle faster, compensating for the slower cycle time that would normally occur with the larger cylinders. To replace the regenerative valve: 1. Unscrew the regenerative valve cartridge.
Page 78 Jack Table™ Platen Press Check Valve The check valve creates back pressure in the system, which allows the directional valves to shift. To replace the check valve: 1. Unscrew the damaged valve Install a new valve. 001094 Rev. A Maintenance...
Page 79 Jack Table™ Platen Press Replacing the Hydraulic Motor Removing the Hydraulic Motor 1. Move the gantry to the end of the table. 2. Lockout/tagout the machine. 3. Drain the hydraulic lines. 4. Remove the drive chain guard. 5. Relieve chain tension and remove the motor drive chain.
Page 80: Replacing The Hydraulic Cylinders
Jack Table™ Platen Press Replacing the Hydraulic Cylinders The platen MUST be up to remove the gantry from the table. Removing the Hydraulic Cylinders 1. Remove the gantry from the table. a) Support the table with a fork lift. Figure 7-6: Removing the...
Page 81: Replacing The Hydraulic Pump
Jack Table™ Platen Press 4. Put the gantry assembly back on the table. a) Place the gantry on the table. b) Re-install the legs. c) Lower the table to the floor. 5. Remove the lockout/tagout devices and restart the machine.
Page 82: Replacing The Hpu Electric Motor
Jack Table™ Platen Press Replacing the HPU Electric Motor Figure 7-7: HPU Electric Motor Removing the HPU Electric Motor 1. Close the ball valve and drain the hydraulic lines. 2. Disconnect the hydraulic lines from the pump. See Figure 7-7.
Page 83: Hydraulic Adjustments
Jack Table™ Platen Press 10. Remove the lockout/tagout devices and restart the machine. Cycle the cylinders and hydraulic motor at least five (5) times before beginning normal operation. Hydraulic Adjustments Adjusting the Operating Pressure for Pressing 1. Turn the auto-raise option off. The indicator light on the right side on top of the operator control should turn off.
Page 84 Jack Table™ Platen Press 8. Remove the lockout/tagout devices and restart the machine. 9. Repeat steps 3 through 7 until the desired pressure is reached. Adjusting the Operating Pressure for Motor Torque 1. Move the gantry toward the end of the table.
Page 85: Bearings
Bearings Figure 7-9: Bearing Drive Shaft Bearings The Jack Table has seven (7) drive shaft bearings, including four (4) wheel bearings, two (2) center support bearings, and one (1) motor support bearing. All bearings should be lubricated with grease weekly.
Page 86 Jack Table™ Platen Press 2. Remove the drive wheels. a) Remove the outer snap ring. b) Remove the wheel and key. c) Remove the inner snap ring. 3. Remove the chain guards. 4. Relieve the tension on the motor drive chain.
Page 87 Jack Table™ Platen Press 4. Replace the drive wheels. a) Replace the inner snap ring. b) Re-install the wheel and key. c) Replace the outer snap ring. 5. Put the gantry assembly back on the table. a) Place the gantry on the table.
Page 88: Wheels
Jack Table™ Platen Press Wheels It is recommended that you replace all drive wheels or support wheels when replacing one drive wheel or support wheel. Replacing the Drive Wheels The platen MUST be up to remove the gantry from the table.
Page 89 Jack Table™ Platen Press 4. Put the gantry assembly back on the table. a) Place the gantry on the table. b) Re-install the legs. c) Lower the table back to the floor. 5. Remove the lockout/tagout devices and restart the machine.
Page 90: Replacing The Support Wheels
Jack Table™ Platen Press Replacing the Support Wheels Figure 7-11: Support Wheel The platen should be in the up position to replce the support wheels. Removing the Support Wheels 1. Move the gantry to the end of the table so the support wheels can be easily accessed.
Page 91: Replacing The Support Wheel Die Spring
Jack Table™ Platen Press Replacing the Support Wheel Die Spring The platen should be in the up position to replce the support wheels. 1. Move the gantry to the end of the table so the support wheels can be easily accessed.
Page 92: Chains
Jack Table™ Platen Press Chains Lubricating Chains The drive chain and the transfer drive chain should be lubricated daily. The lubricant used should be a high-grade, non-detergent, petroleum-base oil. Anti-foam, anti-rust, and film- strength improving additives are often beneficial. SAE 30 grade is recommended.
Page 93 Jack Table™ Platen Press Replacing a Chain Removing the Chain 1. Move the gantry head to a position where the master link is clear of the sprockets so it can easily be reached. The master link is shown in Figure 7-13.
Page 94: Wear Strips
Jack Table™ Platen Press Wear Strips If the pressing motion of the platen is no longer vertical, the wear strips should be replaced. There are six wear strips. You should replace one wear strip at a time. Do not begin replacing other wear strips until the replacement of the first wear strip is complete.
Page 95: Replacing The Guide Bar Wear Strips
Jack Table™ Platen Press Replacing the Guide Bar Wear Strips WARNING CRUSH HAZARD. Remove only one guide bar wear strip at a time. Removing more than one guide bar wear strip may cause the trolley assembly to fall out of the platen assembly, which could result in severe personal injury or death and damage to the machine.
Page 96 Jack Table™ Platen Press b) Remove the bolts that attach the end legs to the main table frame. See Figure 7-6 on page 48. c) Remove the legs. d) Remove the gantry from the table. 2. Remove the trolley assembly from the outer frame.
Page 97: Jigging And Blocking
Jack Table™ Platen Press 7. Remove the lockout/tagout devices and restart the machine. Cycle the cylinders and hydraulic motor at least five (5) times before beginning normal operation. Jigging and Blocking The jigging is designed for durability and accuracy with minimal maintenance. It is important, however, to promptly remove from service any damaged fixtures or components.
Page 98: Replacing The Blocking
Jack Table™ Platen Press Replacing the Blocking The Jack Table is shipped with blocking for 2- Figure 7-16: Blocking in. lumber. To press thicker lumber, you will need to replace the blocking with optional blocking for 3-in. or 4-in. lumber. Contact your MiTek Sales Representative to order additional blocking.
Page 99: Bumpers
Jack Table™ Platen Press Bumpers To replace the bumpers: Figure 7-17: Bumpers 1. Unbolt the bumpers. 2. Remove the damaged bumpers. 3. Replace bumpers. 4. Re-insert bolts and tighten. 001094 Rev. A Maintenance...
Page 100: Electrical Components
6. Vacuum the enclosure. Environmental Temperature The air temperature around the Jack Table should never exceed 110°F. In high ambient temperatures, the motors are unable to dissipate heat effectively. When the temperature of the motor windings exceeds a preset value, the motor overload will automatically shutdown the motor to prevent it from burning up.
Page 101: Troubleshooting
Troubleshooting Appendix A Navigating the Troubleshooting Appendix If you continue to have problems after performing all applicable troubleshooting steps and reviewing the topic in the Maintenance chapter, call MiTek Machinery Division Customer Refer to... Service for assistance. Maintenance chapter for...
Page 102 Jack Table™ Platen Press Electrical Troubleshooting Safety Tips • Make sure you have the proper tools needed for the job. See Tools Needed on page 71. • Ensure the person performing the troubleshooting is qualified from an electrical knowledge standpoint. If you feel uncertain about troubleshooting electrical power, remember, it is better to spend money to hire an electrician than to risk an injury.
Page 103: Getting Started With Troubleshooting
Jack Table™ Platen Press Getting Started With Troubleshooting Tools Needed Gather these tools before beginning the troubleshooting process and before calling MiTek for technical assistance. 1. Slotted screwdriver, insulated 2. Phillips screwdriver, insulated 3. Equipment manual and drawings, specifically electrical schematics 4.
Page 104 Jack Table™ Platen Press The First Steps For Mechanical Troubleshooting Always clean and lubricate the equipment as a first step in most troubleshooting processes. Most mechanical malfunctions are caused by inadequate preventive maintenance. For Electrical Troubleshooting 1. Lockout/tagout at the disconnect switch located on the equipment.
Page 105 Jack Table™ Platen Press 5. Determine where the electrical problem begins. To do this, you need a multimeter. If you are unfamiliar with your multimeter, consult the manufacturer’s manual. • Determine if you are working with AC (alternating current) or DC (direct current) before checking for voltage.
Page 106: Symptoms And Solutions
Jack Table™ Platen Press Should you lockout/tagout to safely perform this action? Symptoms and Solutions Table A-1: Jack Table Troubleshooting Problem Possible Cause Possible Solution Page Wear strips are damaged Replace the wear strips Platen not square with Gantry trolley not sitting flat on the...
Page 107 Jack Table™ Platen Press Should you lockout/tagout to safely perform this action? Table A-1: Jack Table Troubleshooting (Continued) Problem Possible Cause Possible Solution Page Obstruction under the platen Clear obstruction — Cylinder is broken Replace cylinder Platen will not press —...
Page 108: Parts List
Parts List Appendix B Ordering the Parts With Your Part Number There are several easy ways to order your part after you determine the part number. Each column in Table B-1 describes one method. Table B-1: How to Order Your Part Using the Part Number Using Our eStore™...
Page 109 Jack Table™ Platen Press Safety Notes for Replacing Parts CAUTION Only use the exact replacement parts that are specified by MiTek. Substitutions may harm your equipment. WARNING CRUSH, CUT, ELECTROCUTION, HIGH PRESSURE AND CHEMICAL HAZARDS. Perform the safety tests described in the Safety Test section...
Page 110: Part Numbers
Jack Table™ Platen Press Part Numbers Table B-2: Replacement Parts Keep Part Location Refer to MiTek Part # Part Description Category Drawing # Stock Gantry 30035 Drive wheel 30006-501 Gantry 30044 End guide bar 30003-501 — Gantry 30045 Guide bar 30003-501 —...
Page 111: Maintenance Checklists
Maintenance Checklists Appendix C Navigating the Maintenance Checklists These checklists guide you through all preventive maintenance tasks required to keep this equipment in top working condition. These pages are supplied with the intent that you will photocopy them and leave the original in the manual for future use.
Page 112: Daily Checklist
Jack Table Daily Checklist Month and Year: _______________________ Week: __________________________ Dates Action Page Shift 1 Vacuum the electrical enclosures Shift 2 Shift 3 Shift 1 Blow out the U-channel jigging Shift 2 slots with compressed air Shift 3 Shift 1...
Page 113: Weekly Checklist
Jack Table Weekly Checklist Year: _____________ Month: _________________ Dates See Page Action Grease all bearings Grease the support wheels axles Inspect all jigging; replace as needed Check hydraulic fluid levels Notes Date 001094 Rev. A Maintenance Checklists...
Page 114 Jack Table Monthly and Annual Checklists Year: _____________ APRIL JUNE Action Interval Page Check indicator light bulbs 1 month Check chain tension 1 month Replace hydraulic fluid 1 year JULY SEPT Interval Action Page Check indicator light bulbs 1 month...
Page 115: Technical Information
Technical Information Appendix D This appendix provides general information that will help you better understand how this equipment works. Understanding Overloads Purpose and Scope The information below has been collected to help you understand the role of an overload, how an overload works, and how to calculate the overload setting to protect the motor. The Importance of Protecting Your Motor The following statement describes the importance of protecting electric motors and is a good illustration of why we need overloads.
Page 116: Starting Current
Jack Table™ Platen Press What is an Overload? So, what is an overload? The term literally means that too much load (what the motor is driving) has been placed on the motor. A motor is designed to run at a certain speed, called its synchronous speed.
Page 117 Jack Table™ Platen Press Figure D-1: Motor Inrush Curve Inrush Normal Current Operating Current 1000 Current A 300 % Overload .01 0.1 10 100 1000 Time (s) An overload condition will occur when the rotor has difficulty turning and draws more current than it normally would need to keep it turning.
Page 118 Jack Table™ Platen Press • A design that meets the special protective needs of motor control circuits • Allow harmless temporary overloads, such as motor starting, without disrupting the circuit • Will trip and open a circuit if current is high enough to cause motor damage over a period of time •...
Page 119 Class 30 has a longer time delay to be used on high inertia loads that require a long acceleration or have shock loading that causes repetitive motor inrush. The overload class that MiTek normally specifies for equipment is a Class 10. Since it is possible to burn out a motor in less than 20 seconds, we have chosen to protect the motor with the highest degree of protection.
Page 120: Codes And Standards
Jack Table™ Platen Press Codes And Standards NFPA 79—Electrical Standard for Industrial Machinery, 2002 7.3.1.1 Motors. Motor overload protection shall be provided to each motor in accordance with Article 430, Part III, of NFPA 70, National Electrical Code. NEC 2002—National Electrical Code 430.32 (A) (1) Separate Overload Device.
Page 121 Jack Table™ Platen Press Example 3 40 hp, 208V, 3 phase, wound rotor motor, FLA 118 amps. Overload Protection = 118 amps times 115%=136 amps The motor overloads must be calculated using the nameplate current and not from Tables 430-148 or 430-150 of the National Electrical Code.
Page 122: Insulation Class
Jack Table™ Platen Press Glossary of Overload Terms Full Load Amps (FLA) This is the current flow required by a motor during normal operation under normal loading to produce its designated horsepower. Motors having nothing attached to their shaft will draw less than the FLA current.
Page 123 Jack Table™ Platen Press motor load. The motor load “seen” by a motor is dependant upon how the load is connected to the motor, the dimensions of the load, and the weight of the load. A load connected to a motor by a gearbox reduces the load by the square of the gear ratio.
Page 124 Jack Table™ Platen Press NEMA Design Ratings NEMA ratings refer to the torque ratings. The following ratings apply to motors: NEMA B The NEMA B motor’s percentage of slip ranges from 2 to 4%. It has medium values for starting or locked rotor torque, and a high value of breakdown torque.
Page 125 Jack Table™ Platen Press Class 20, and Class 30. Class 10, for example, has to trip the motor off-line in 10 seconds or less at 600% of the full load amps. This is usually sufficient time for the motor to reach full speed.
Page 126: Drive Faults
Before troubleshooting a drive fault, determine whether the fault is a motor, drive, or application fault. Use the fault codes of the drive. If you are unable to locate the source of the fault, contact MiTek Customer Service. 001094 Rev. A...
Page 127 Drawing Set Appendix E Drawings are inserted at the back of the manual. Table E-1: Attached Drawings Description Drawing Number Gantry 30001-501 Table assembly, 30' U-channel 30002-501 Gantry mechanical assembly 30003-501 Hydraulic assembly 30005-501 Trolley assembly 30006-501 Support assembly 30010-501 Festoon assembly 30067-501 Table assembly, 30' solid top...
Page 128 Document Evaluation Appendix F A form is included in this appendix so you can provide MiTek with feedback on the usefulness of this manual. We make an ongoing effort to improve the value of our documentation, and your views are important to us.
Page 129 Document Evaluation Form We appreciate your comments on how we can make this document more useful. Document Identification: ™ Operation and Maintenance Manual 001094 Jack Table General Ratings: Poor Fair Good Excellent Content     Organization  ...
Page 130 Address: Phone: Email: Please mail this form to: Or fax this form to: 636-328-9218 MiTek Attn: Engineering Manager Machinery Operations 301 Fountain Lakes Industrial Drive St. Charles, MO 63301 Attn: Engineering Manager If you do not receive a reply within 45 days, please call our Customer Service Department and ask for the Documentation Specialist or Engineering Manager: 800-523-3380.
Page 131 Glossary actuate to activate, put into action amperage the strength of an electric current, expressed in amperes anchor plate a steel plate that holds the tables in place; it is anchored to the concrete floor bumper a safety device that prevents the gantry from crashing into the edge of the table connector plate the nail-plate that is embedded into the production...
Page 132 Glossary qualified person a person or persons who, by possession of a recognized degree or certificate of professional training, or who, by extensive knowledge, training, or experience, has successfully demonstrated the ability to solve problems relating to the subject matter and work—ANSI B30.2- 1983;...
Page 133 Index drawing set 95 bearings lubricaiton 39, 40 motor 53 electrical blocking 7, 65, 66 checking voltage 71 bumpers 67 components 68 customer-supplied parts 16 installation 22 requirements 14 caution logo ix emergency stops, see E-stop centerlines 8 environment 13 chains environmental logo ix adjusting tension 60...
Page 134 Index specifications 41 adjusting tension 60 motor 47 lubrication 60 pump 44, 49 motors changing rotation 24 overloads 68 starters 68 multimeter 71 installation checklist 23 customer responsibilities 11 delivery 17 electrical 22 notice logo ix hydraulic system 21 notice of change iii jigging oil, hydraulic, see fluid, hydraulic blocking 65...
Page 135 Index tests xviii shipping information 15 space for equipment 13 for maintenance 13 for operation 13 spare parts, see replacement parts specifications features 6 general 7 stop motion, see E-stop training 16 truss terminology 8 unloading 18 unpacking 19 warning logo ix weight 15 001094 Rev.
Page 136 1-1/2” binder 1/2” binder 1” binder 2” binder 001094 001094 001094 001094...
