- Page 1 SL-2 DUAL SUPERSLOT WIRELESS MODULE FOR 8-SERIES MIXER-RECORDERS USER GUIDE...
- Page 2 SL-2 User Guide | Rev 07/2022 This document is distributed by Sound Devices, LLC in online electronic (PDF) format only. Published in the USA. This table provides the revision history and cross-reference WEEE Statement links to “what’s new”...
- Page 3 • Compatible with the 833, 888, and the Scorpio. • Accepts two UniSlot or SuperSlot wireless receivers from Sound Devices, Audio Ltd, Lectrosonics, Sennheiser, Shure, Sony, and Wisycom. • Built-in antenna distribution with antenna powering for active antennas or boosters.
- Page 4 Table of Contents PANEL VIEWS ATTACHING THE SL-2 833 & 888 SCORPIO REMOVING THE SL-2 833 & 888 SCORPIO INSERTING RECEIVERS IN THE SL-2 REMOVING RECEIVERS FROM THE SL-2 SPECIFICATIONS DECLARATION SL-2 User Guide...
- Page 5 Panel Views RE AR FRON T Antenna A Antenna B RF Overload LED RF Overload LED Slot A Antenna Slot B Antenna Slot A Antenna Slot B Antenna AES Inputs 1-4 DC Outputs 1 & 2 A Lead B Lead A Lead B Lead TA3-Male...
- Page 6 Attaching the SL-2 STEP 3 Using the provided 2 mm Allen Wrench, screw in two Rear Keyhole Pegs into the threads Power down the mixer-recorder and remove all power sources. where you removed the screws in Step 2. Proper and complete assembly of the SL-2 is required for optimal RF emission performance.
- Page 7 STEP 5 Make sure that the SL-2 Expansion Connector mates with the 833/888 Expansion Port. Then gently press down on the SL-2 to fully seat the pins of the connector. STEP 6 Using the supplied 2 mm Allen Wrench, secure the SL-2 to the 833/888 top panel with the two captive screws as shown in the image below.
- Page 8 SCO R P IO STEP 3 Using the provided 2 mm Allen Wrench, screw in two Rear Keyhole Pegs into the threads The following instructions describe attaching the SL-2 to the Scorpio. where you removed the screws in Step 2. For this assembly you will need: •...
- Page 9 STEP 5 Position the SL-2 Rear Bracket on the rear panel of the STEP 8 Secure the SL-2 to the Scorpio Front Bracket with SL-2 as shown in the image below. Secure the SL-2 Rear Bracket two 6 mm screws using the supplied 2 mm Allen Wrench. with two 6 mm screws using the supplied 2 mm Allen Wrench.
- Page 10 SL-2. Turn the wrench counterclockwise to STEP 5 Replace the originally provided rear black screws near loosen the screws. Remove the screws and set aside. the Sound Devices logo using #4 Phillips head screwdriver. SL-2 User Guide...
- Page 11 STEP 6 Replace the top plate. SL-2 User Guide...
- Page 12 SCO R P IO STEP 3 Remove the two small black screws. The following instructions describe removing the SL-2 from the Scorpio. For this assembly you will need: • Scorpio Mixer-Recorder (not included) • SL-2 • 2x Rear Keyhole Pegs •...
- Page 13 Inserting Receivers in the SL-2 It is important to turn off power to the SL-2 slot prior to removing and inserting receivers to avoid potential hardware damage. Slot power can be turned off in the Menu>System>Expansion Port menu, Menu>SuperSlot>Options>Slot Power, or by turning the 8-Series Mixer-Recorder Off.
- Page 14 Specifications Specifications are subject to change without prior notice. For the latest information available on all Sound Devices products, visit our website: www.sounddevices.com. POWERING All power supplied by host 8-Series machine SL-2 idle power draw 1.3 W (without receivers or antenna)
- Page 15 EN 62368-1:2014 EN 301 489-9 v2.1.1 2019 EN 301 489-1 v2.2.0 (Draft) This Declaration of Conformity applies to the above-listed product(s) placed on the EU market after: June 29, 2020 Date Matt Anderson - Sound Devices, LLC President SL-2 User Guide...
- Page 16 Post Office Box 576 E7556 State Rd. 23 and 33 Reedsburg, Wisconsin 53959 USA support@sounddevices.com +1 608.524.0625 main +1 608.524.0655 fax 800.505.0625 toll free www.sounddevices.com...
