JW Speaker 6130 Installation Instructions

INSTALLATION INSTRUCTIONS
To properly install this light you should have a good understanding of electrical procedures and systems. IF YOU DO NOT,
PLEASE SEEK PROFESSIONAL ASSISTANCE.
BEFORE INSTALLATION:
Estimated Time:
90 minutes
Tools Needed: Drill
6mm or ¼ in. drill bit
T30 Torx driver
#2 Phillips head screwdriver
7/16" wrench
Wire Functions: See Wiring Chart on page 3.
In the Box: (x1) Adjuster Ring
(x1) Adjuster Plate
(x3) Springs
(x3) ¼ x 1.5" Screws
(x3) 8x32 x ¼" Screws
(x3) ¼" Locknut Hex
Input Voltage: 12-24V DC
Operating Voltage: 10-30V DC
PRODUCT WARRANTY:
If you have issues with a J.W. Speaker product, please
contact the authorized retailer where you purchased it.
6544520a Rev: 03/29/2018 J.W. Speaker Corporation Germantown, WI U.S.A. www.jwspeaker.com speaker@jwspeaker.com
PRE-INSTALLATION INSTRUCTIONS:
1. Read all safety notes and mounting guidelines before
installing the product. Verify that all parts listed under "In the
Box" are present and complete.
2. Inspect the product for damage. DO NOT install the product if
there is any damage. Contact the authorized retailer where you
purchased it to initiate a warranty claim if there is damage.
3. Verify that all power supply and/or charging systems comply
to the specified voltage limits for the light.
INSTALLATION INSTRUCTIONS:
1. Turn off the vehicle and disconnect the battery.
2. Ensure that the mounting location is a FLAT, SOLID surface of
the same (or larger) size as the bracket or light. This will prevent
warping or distortion that can cause cracking or damage to the
light and/or bracket.
3. Check condition of all wires, connectors, mating connectors,
or gaskets. All connections should be adequately protected
against moisture. Shrink tubing is recommended.
4. Carefully connect the wires or connector using the "Wire
Functions" and "Voltage" information above. With connectors,
push firmly to ensure that it is properly mated with the lamp,
creating a seal to protect against water ingress.
5. Lay and secure the wiring so that no pulling or abrasion can
occur. Proper installation requires there to be a little slack near
the lamp to avoid pulling on the connector (which can create a
path for water ingress). Wires should be adequately secured to
avoid damage.
6. Secure it to the mounting surface then aim the light (if
applicable).
7. Periodically check the light to make sure that it is working
properly and is securely attached.
Model 6130
© Copyright 2018
