  • Page 1 MAS1015 User’s Manual...

  • Page 2: Copyright Notice

    Copyright Notice The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 3 Thank you for choosing MACTRON Tablet This instruction serves to enable users to get to know our product as soon as possible. Here we have made a brief introduction to the key layout and definitions in figures and words. And a brief explains for the basic operating functions.

  • Page 4: Table Of Contents

    Contents 1. Getting Started ..............1 1.1. Packing List ....................1 1.3. Turning On and Off the Tablet ............... 3 2. Product Information ............. 4 2.1. Specification ....................4 2.2. Product Overview ..................6 2.3. System Configuration ..................8 2.3.1. Front Components ......................8 2.3.2.
  • Page 5 5.1.3. Connecting a Monitor ....................20 5.1.4. Connecting an Audio Device ..................21 6. Using BIOS Setup ..............22 6.1. Menu Descriptions ..................23 6.1.1. Main Menu ........................23 6.2. Advanced Menu & Chipset Menu ............... 25 6.3. Boot Menu ....................27 6.4.

  • Page 7: Getting Started

    1. Getting Started This chapter first tells you step by step how to get the tablet up and running. Then, you will find a section briefly introducing the external components of the tablet. 1.1. Packing List After unpacking the shipping carton, you should find these standard items: If you discover any of the items listed below are damaged or lost, please contact your local distributor immediately.

  • Page 8: Connecting To Ac Power

    1.2. Connecting to AC Power CAUTION: Use only the AC adapter included with your Tablet. Using other AC adapters may damage the Tablet. It must be connected to AC power supply when it is turned on for the first time. 1.

  • Page 9: Turning On And Off The Tablet

    1.3. Turning On and Off the Tablet Turning On Press the power button ( ). The Windows operating system should start. Turning Off When you finish a working session, you can stop the system by turning off the power or leaving it in Sleep or Hibernation mode: To…...

  • Page 10: Product Information

    2. Product Information 2.1. Specification Display Display Type 10.1 inch IPS LCD Resolution 1200×1920 Brightness 1000 nits Touch Panel 10 point G+G capacitive touch screen, Hardness Above 7H, Scratch-Resistant, Supports Glove Touch System Intel N100 Processor Intel® UHD Graphics Memory 8GB LPDDR5 Storage 128 GB eMMC...
  • Page 11 Color Caesious Dimensions 274.9 x 188.7 x 22.2 mm (WxHxD) Weight 1130g Button 1 x Power 1x Volume + Key 1 x Volume - Key 1 x P1 Key (HOME Key) 1 x F Key (Barcode Scanning, Connected to GPIO) Sensor G-sensor Battery...

  • Page 12: Product Overview

    2.2. Product Overview Note: Depending on the special model you purchased, the look and colour of the device may be different from the graphics shown in this manual. Note: Please open the waterproof plug before using the ports or device. When not using ports or device, please completely cover the waterproof plug to isolate water and dust.
  • Page 13 Top View Bottom View Side View...

  • Page 14: System Configuration

    2.3. System Configuration 2.3.1. Front Components Ref. No. Component Description ❶ F Key 2D scan key (customized) ❷ Home Key Used to open a Windows shortcut. ❸ Volume + Key Used to increase the device volume. ❹ Volume - Key Used to decrease the device volume.

  • Page 15: Rear Components

    2.3.2. Rear Components Ref. No. Component Description ❶ Flashlight Used for lighting ❷ Rear Carema Used for photo and video recording. ❸ Cover latch To lock the battery cover. ❹ Battery cover To protect the internal battery. ❺ Battery lock To lock the internal battery.

  • Page 16: Left-Side Components

    2.3.3. Left-Side Components Ref. No. Component Description ❶ I/O Port One of RJ45 LAN, USB2.0 & RS232 can be chosen. Default is RJ45 LAN. ❷ DC Charging Port Connects to a 12V/4A adapter for power supply. 2.3.4. Right-Side Components Ref. No. Component Description ❶...

  • Page 17: Top Components

    2.3.5. Top Components Ref. No. Component Description ❶ Modular Interface Barcode scanning module 2.3.6. Bottom Components Ref. No. Component Description ❶ Pogo Pin Matched with the positioning hole to connect the Vehicle Mount and Docking Charger for expanding USB, RJ45 and RS232 communication interfaces. ❷...

  • Page 18: Installation And Uninstallation Of Sim And Tf Card

    2.4. Installation and uninstallation of SIM and TF card Step 1. Remove the battery, take out the card tray at this location, and insert the TF card and NANO SIM card. The NC card slot currently has no function. Step 2. After placing the TF card and Nano SIM card into their designated slots, reinsert the tray to enable use, as shown in the image below.

  • Page 19: Operating Your System

    3. Operating Your System This chapter provides information about the use of the Tablet. If you are new to Tablets, reading this chapter will help you learn the operating basics. If you are already a Tablet user, you may choose to read only the parts containing information unique to your Tablet.

  • Page 20: Using Wireless Connections

    3.2. Using Wireless Connections 3.2.1. Using the WLAN The built-in WLAN (Wireless Local Area Network) module supports WIFI 802.11(a/b/g/n/ac/ax). 3.2.2. Turning On / Off the WLAN Radio To turn on the WLAN radio: → [Settings] → [Network & Internet] → [WLAN]，Slide the WLAN Click switch to the [On] position.

  • Page 21: Using The Bluetooth Feature

    3.3. Using the Bluetooth Feature The Bluetooth technology allows short-range wireless communications between devices without requiring a cable connection. Data can be transmitted through walls, pockets and briefcases as long as two devices are within range. 3.3.1. Turning On / Off the Bluetooth Radio To turn on the Bluetooth radio: Click →...

  • Page 22: Managing Power

    4. Managing Power Your Tablet operates either on external Type-C power, DC or on internal battery power. This chapter tells you how you can effectively manage power. To maintain optimal battery performance, it is important that you use the battery in the proper way. 4.1.

  • Page 23: Battery Pack

    4.2. Battery Pack The battery pack is the internal power source for the Tablet. It is rechargeable using the AC adapter. CAUTION: The time to unplug the battery pack is limited to when the battery is not being charged. NOTE: Care and maintenance information for the battery is provided in the ”Battery Pack Guidelines”...

  • Page 24: Battery Low Signals And Actions

    4.2.3. Battery Low Signals and Actions When the battery is low, please connect the adapter immediately, put the Tablet into hibernation, or turn off the Tablet's power. 4.2.4. Replacing the Battery Pack CAUTION:  There is danger of explosion if the battery is incorrectly replaced. Replace the battery only with the Tablet manufacturer’s optional battery packs.

  • Page 25: Power-Saving Tips

    4.3. Power-Saving Tips Aside from enabling your Tablet’s power saving mode, you can do your part to maximize the battery’s operating time by following these suggestions.  Do not disable Power Management.  Decrease the LCD brightness to the lowest comfortable level. ...

  • Page 26: Expanding Your Tablet

    5. Expanding Your Tablet You can expand the capabilities of your Tablet by connecting other peripheral devices. When using a device, be sure to read the instructions accompanying the device together with the relevant section in this chapter. 5.1. Connecting Peripheral Devices 5.1.1.

  • Page 27: Connecting An Audio Device

    5.1.4. Connecting an Audio Device Your Tablet is equipped with a composite audio port, which is 3.5mm in size, which can be connected to a compatible headset microphone. AFETY WARNING: To prevent possible hearing damage, do not listen at high volume levels for long period.

  • Page 28: Using Bios Setup

    6. Using BIOS Setup BIOS Setup Utility is a program for configuring the BIOS (Basic Input / Output System) settings of the Tablet. BIOS is a layer of software, called firmware, that translates instructions from other layers of software into instructions that the Tablet hardware can understand.

  • Page 29: Menu Descriptions

    6.1. Menu Descriptions 6.1.1. Main Menu The Main menu contains the various system settings.  Build Date and Time (BIOS version date): Record the Tablet bios version.  Serial number (SN): Record Tablet factory code.  EC FM Version: Record EC firmware information ...

  • Page 31: Advanced Menu & Chipset Menu

    6.2. Advanced Menu & Chipset Menu The settings in the Advanced and Chipset menus are for developer debugging purposes. Please do not alter these settings without proper knowledge. 6.2.1. Security Menu The Security menu contains the security settings, which safeguard your system against unauthorized use.

  • Page 33: Boot Menu

    6.3. Boot Menu The Boot menu sets the sequence of the devices to be searched for the operating system.

  • Page 34: Save & Exit Menu

    6.4. Save & Exit Menu The Save & Exit menu displays ways of exiting BIOS Setup Utility. After finishing with your settings, you must save and exit so that the changes can take effect.  Save Changes and Exit: Saves the changes you have made and exits BIOS Setup Utility.

  • Page 35: Care And Maintenance

    7. Care and Maintenance Taking good care of your Tablet will ensure a trouble-free operation and reduce the risk of damage to your Tablet. This chapter gives you guidelines covering areas such as protecting, storing, cleaning, and traveling. 7.1. Protecting the Tablet To safeguard the integrity of your Tablet data as well as the Tablet itself, you can protect the Tablet in several ways as described in this section.
  • Page 36 overheating may occur that results in damage to the Tablet.  As the Tablet can become very hot during operation, keep it away from objects that are vulnerable to heat.  Keep the Tablet at least 13 cm (5 inches) away from electrical appliances that can generate a strong magnetic field such as a TV, refrigerator, motor, or a large audio speaker.
  • Page 37 Cleaning Guidelines  Never clean the Tablet with its power on.  Use a soft cloth moistened with water or a non-alkaline detergent to wipe the exterior of the Tablet.  Gently wipe the display with a soft, lint-free cloth. ...
  • Page 38  avoid installing or removing the battery pack when the Tablet is in Sleep mode. Abruptly removing the battery pack may cause loss of data or the Tablet may become unstable.  avoid touching the battery pack terminals or damage may occur, thereby causing improper operation to it or the Tablet.
  • Page 39 When Traveling  Make sure that the battery pack is fully charged.  Make sure that the device is turned off.  Make sure that all the connector covers are closed completely to ensure the waterproof integrity.  Disconnect the AC adapter from the Tablet and take it with you. Use the AC adapter as the power source and as a battery-charger.

  • Page 40: Troubleshooting

    8. Troubleshooting Tablet problems can be caused by hardware, software, or both. When you encounter any problem, it might be a typical problem that can easily be solved. This chapter tells you what actions to take when solving common Tablet problems. 8.1.
  • Page 41  If the battery doesn't charge after it has been stored in very low temperatures, try disconnecting and reconnecting the AC adapter to solve the problem.  Make sure that the battery pack is installed correctly.  Make sure that the battery terminals are clean. The operating time of a fully charged battery becomes shorter.
  • Page 42  The screen output may be switched to an external device. Please switch the display via Windows [Control Panel]. The characters on the screen are dim.  Adjust the brightness and / or contrast. Bad dots appear on the display at all times. A small number of missing, discolored, or bright dots on the screen are an intrinsic characteristic of TFT LCD technology.
  • Page 43 The Tablet does not resume from Sleep or Hibernation mode.  The Tablet automatically enters Sleep or Hibernation mode when the battery pack is empty. Do any one of the following:  Connect the AC adapter to the Tablet.  Replace the empty battery pack with a fully charged one. Software Problems An application program does not work correctly.
  • Page 44 properly.  If you are using the battery power, make sure that the battery is not discharged. WLAN Problems I cannot use the WLAN feature.  Make sure that the WLAN feature is turned on. Transmission quality is poor.  Your Tablet may be in an out-of-range situation. Move your Tablet closer to the Access Point or another WLAN device it is associated with.

  • Page 45: Restart The Tablet

    I cannot access the network.  Make sure that the network configuration is appropriate.  Make sure that the user’s name or password is correct.  You have moved out of range of the network. 8.3. Restart the Tablet When the Tablet crashes due to a problem, you may need to restart the Tablet. If you are sure that the Tablet has crashed and you cannot use the reboot function provided by the operating system, please reboot in one of the following ways: ...
