Summary of Contents for MACTRON auto TRON MAS1227
- Page 1 MAS1227 User’s Manual...
- Page 2 Copyright Notice The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
- Page 3 Thank you for choosing MACTRON Tablet This instruction serves to enable users to get to know our product as soon as possible. Here we have made a brief introduction to the key layout and definitions in figures and words. And a brief explains for the basic operating...
- Page 4 Packing List MAS1227 x1 Strap x 1 Handle Strap x 1 Plastic Pry tool x 1 Power Adapter 12V/4A x 1...
-
Page 5: Table Of Contents
CONTENT 1. Product Information .............1 1.1 S ................... 1 PECIFICATIONS 1.2 P ................2 RODUCT VERVIEW 1.3 I ............... 3 NTERFACE ESCRIPTION 2. Device Initialized Setting............7 2.1 L ................7 ANGUAGE ETTING 2.2 K ..........8 EYBOARD AYOUT AND ANGUAGE ETTING 2.3 U .............. - Page 6 4.3 Q ..................20 UICK START 4.4 S ................22 YSTEM SETTING...
-
Page 7: Product Information
1. Product Information 1.1 Specifications Display Display Type 12.2" IPS TFT LCD Resolution 1920 x 1200 Brightness 280nit Touch screen type 10 points capacitive, G+G, 7H anti scratch, 1.1, COF System Intel Skylake Core m3 6Y30, 4M Cache, 2.20 GHz Intel HD Graphics 515 4 GB LPDDR3 128 GB... -
Page 8: Product Overview
Adapter AC100V ~ 240V, 50Hz/60Hz, output DC 12V/4A Battery 6300mAh/7.4V (Removable), 1000mAh/7.4V (Built in) Using time 6hrs (Default 50% volume, default 200nit, play 1080 HD video) Rugged Feature IP65, 1.0m drops Operating Temperature 10°C ~ 50°C Storage Temperature 30°C ~ 70°C Humidity 95% non condensing Dimensions... -
Page 9: Interface Description
1.3 Interface Description 1. Power key: Press it to turn your tablet PC on or off. Pressing with 5 seconds to turn on. Pressing with 10 seconds to turn off. Pressing with short time, for sleep mode or awaken. 2. Volume +/ : Reduce / increase the volume. 3. - Page 10 Front Camera: 2.0MP front Camera, to take photos and record video. Light sensor: The light sensation can adjust the brightness automatically. 10. TP: 10 points capacitive panel, G+G, Rigidness: above 7H Anti scratch, TP thickness: 1.1mm, COF, support to handwritten, optional for SLR AR film. 11.
- Page 11 17. HDMI: Connect to the monitor/ high definition TV and other display device, to transfer or play the audio/video, to transfer and play the pictures. 18. USB3.0: High speed data transmission interface. 19. USB2.0: Standard data transmission interface. 20. Ethernet port: RJ45 net export, user can link internet to using in this slot. 21.
- Page 12 28. Battery Lock: Using sliding bar for unlock; Let the battery lock in the locking state when be used, which can prevent the battery from falling off. 29. VESA holes: VESA holes can be fixed directly to the vehicle or other facilities by screws.
-
Page 13: Device Initialized Setting
2. Device Initialized Setting 2.1 Language Setting Click ”Yes” to go to the next step depending on the language you want. Select the area of use according to language. -
Page 14: Keyboard Layout And Language Setting
2.2 Keyboard Layout and Language Setting Choose the xkeyboard layout and language you like, click "Yes" to enter the next step. -
Page 15: User License Agreement
B. If one keyboard cannot be satisfied, add a second keyboard or skip here. 2.3 User License Agreement This is the Microsoft software license agreement, click “Accept” to enter the next step. -
Page 16: Network Setting
2.4 Network Setting Choose the network you want to connect and enter your password. (it is recommended to skip the network connection, otherwise it may take too long for the system to check for updates.) -
Page 17: Username And Password Settings
2.5 Username and password settings Setting the user name, go to the next step. Setting password Enter the password, click “Next” the device will restart, do not do anything else during the device restart. (no need to set password and click the “Next”). -
Page 18: Personalized Setting
2.6 Personalized setting Make Cortana your personal assistant. Choose privacy settings for your device. -
Page 19: Complete Setting
2.7 Complete setting Wait for the system to enter the desktop, do not shut down the computer. -
Page 20: Desktop Layout
3. Desktop Layout 3.1 Windows 10 Startup Desktop 1. Start icon Quick launch of installed applications. 2. Search for Enter the key character search page or open the application. 3. Task view Open multiple tasks to quickly switch applications with this icon. 4. -
Page 21: Charm Menu Bar
3.2 Charm menu bar Press the Start button to open the charm menu bar. Including: Start, Device, Settings, Search program. 1. Battery level View the system of battery voltage. 2. Network View the status of device management network connections. 3. Sound Control audio and adjust volume. 4. - Page 22 Including: Browse files, settings, power keys, apps Sleep, shut down, restart Search for files and applications Device system More apps...
-
Page 23: App Interface Introduction
3.3 APP Interface Introduction Tablet Start Pinned tiles All apps User Setting Start Add "Magnet" file: All app select the application icon, mouse with right key pin to start return to the fixed magnet to view the application. Delete magnet file: Fixed magnet, mouse with right key select cancel screen. -
Page 24: System Setting
4. System Setting 4.1 Display Application icon Click on the right mouse key and select “Personalize”, as below picture. Personalize window, click “Themes” with the mouse left key. - Page 25 Click “Desktop icon settings” with the mouse left key. Tick in front of the computer icon and click “OK”.
-
Page 26: System Information
4.2 System Information Click the right mouse key or long touch the computer icon to open the extension option. Click on “Properties” to view system information, Windows system version, hardware configuration information, computer name, Windows activation, etc. 4.3 Quick start... - Page 27 Click the right mouse button or click the long touch to start the icon, open the advanced boot interface, and open the corresponding function: 1. Apps and features Manage installed applications and drivers, update drivers and applications. 2. Mobility center Adjust the screen brightness, volume size, detect battery power, set the direction of the screen.
- Page 28 4.4 System setting 1. System Display settings, notifications & actions, power & sleep, battery, storage, tablet mode, multitasking, projecting to this PC, shared experiences, about remote desktop (Windows10 HOME version is not supported). 2. Device Bluetooth & other devices, printer & scanner, mouse, typing, pen &Windows ink, auto play, USB.
- Page 29 8. Time and Language The time and date can be set at the interface (when the device is connected to the Internet when it opens automatically, it can synchronize with the network), Region &language (Region setting, adding other language packages), speech settings. 9.
- Page 30 This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: ( 1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 15.21 Information to the user.
