2.2

Survey and construction

Fig. 1
2.3

Technical Characteritics

Maximum Load Height:
200 mm
Tyre pressure:
Large 3,5 kg/cm2(min. 2,7 / max. 3 bar
Small 2 kg/cm2
2.4

Technical data

The exact technical data (carrying capacity / working load limit (WLL), dead weight, etc.) are listed on the type plate.
51100011
Maximum Pallet Width:
1263 mm
Hydraulic oil volume:
Cylinder blue/black
Cylinder grey
1
2
3
Width: Lenght:
1615 mm 1400 mm
Types of oil:
0,5 l SAE 10 Hydra; SHELL Tellus Oil 37;
HOUGHTON HD 22,5
0,3 l
Handle
Lever for lifting cylinder
Fork legs (adjustable)
Height:
800 mm
GB
