- Page 1 Operating Instructions Translation of original operating instructions Pallet Fork PW-III PW-III 51100011...
- Page 2 Please note that the product may not be used / put into operation without these operating instructions in the national language. If you did not receive operating instructions in your national language with the delivery of the product, please contact us. In countries of the EU / EFTA we will send them to you free of charge.
-
Page 3: Table Of Contents
Safety procedures ............................11 Hints to the type plate ........................... 12 Hints to the renting/leasing of PROBST devices ..................12 Disposal / recycling of devices and machines ..................... 12 We hereby reserve the right to make changes to the information and illustrations in the operating instructions. -
Page 4: Ec-Declaration Of Conformity / Ukca-Declaration Of Conformity
Address: Probst GmbH; Gottlieb-Daimler-Straße 6; 71729 Erdmannhausen, Germany Authorized person for UK-documentation: Name: Nigel Hughes Address: Probst Ltd ; Unit 2 Fletcher House; Stafford Park 17; Telford Shropshire TF3 3DG, United Kingdom Signature, information to the subscriber: Erdmannhausen, 01.02.2023................(Eric Wilhelm, Managing director) -
Page 5: General
The device pallet cart (PW-III) exclusively suitable for transporting of stone slabs (on pallets) on a building site (on even ground). Underride the pallets sidewise. The device (PW-III) may only be used on sloping locations with not more than 15° (slope) and if the conditions on the area allows a safety handling with this device. -
Page 6: Survey And Construction
Survey and construction Handle Lever for lifting cylinder Fork legs (adjustable) Fig. 1 Technical Characteritics Maximum Load Height: Maximum Pallet Width: Width: Lenght: Height: 200 mm 1263 mm 1615 mm 1400 mm 800 mm Tyre pressure: Hydraulic oil volume: Types of oil: Large 3,5 kg/cm2(min. -
Page 7: Safety
Safety Safety symbols Danger to life! Identifies imminent hazard. If you do not avoid the hazard, death or severe injury will result. Hazardous situation! Identifies a potentially hazardous situation. If you do not avoid the situation, injury or damage to property can result. -
Page 8: Personal Safety Requirements
Personal safety requirements Each operator must have read and understood the operating instructions (and all safety instructions). Only qualified, authorized personal is allowed to operate the device and all devices which are connected (lifting device/carrier). The manual guiding is only allowed for devices with handles. Otherwise there is a risk of injury to the hands! Protective equipment •... -
Page 9: Adjustments And Operating
REGULATORY SIGN Adjustments and operating Adjustments • Before using the device (PW-III) adjust the forks (3) according to the corresponding distance. • The forks (3) are displaceable and can so be adjusted stepless. Forks Abb. 1 51100011... -
Page 10: Operating
Fig. 2 • Lower the device (PW-III) Regard, when it is not in operation - to raise the lifetime of the hydraulic. 4.2.1 Filling Hydraulic Oil If the oil cylinder needs to be topped up, the following steps should be followed: •... -
Page 11: Maintenance And Care
Maintenance and care Maintenance and care Maintenance To ensure the correct function, safety and service life of the device the following points must be executed in the maintenance interval. Used only original spare parts, otherwise the warranty expires. All operations may only be made in unpressurised, electro less and closed state of the device! 5.1.1 Mechanics MAINTENANCE PERIOD... -
Page 12: Trouble Shooting
Maintenance and care Trouble shooting ERROR CAUSE REPAIR The pallet cart cannot be Valve is opened Close valve (lever II) raised The pallet cart cannot be Valve defective Check valve (lever II) and exchange it if lowered necessary. The pallet cart is difficult Steering bearing is defective. -
Page 13: Safety Procedures
• The corresponding legal regulations and the regulations of the declaration of conformity must be observed! • The expert inspection can also be done by the manufacturer Probst GmbH. Contact us at: service@probst-handling.de • We recommend affixing the inspection sticker "„Sachkundigenprüfung / Expert inspection" in a clearly visible place (order no.: 2904.0056+Tüv sticker with year number) after the inspection has been done. -
Page 14: Hints To The Type Plate
Example: Hints to the renting/leasing of PROBST devices With every renting/leasing of PROBST devices the original operating instructions must be included unconditionally (in deviation of the user´s country's language, the respective translations of the original operating instructions must be delivered additionally)! Disposal / recycling of devices and machines The product may only be taken out of service and prepared for disposal / recycling by qualified personnel. -
Page 15: Proof Of Maintenance
After each completed performance of a maintenance interval the included form must be fill out, stamped, signed and send back to us immediately 1) via e-mail to service@probst-handling.de / via fax or post Operator: _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _... - Page 18 PIECES DE HYDRAULIQUE DE TRANSPALETTE CHARACTERISTIQUES TECHNIQUES Nº CODE DESIGNATION 030800 Piston 030100 Corps hydraulique 032100 031400 Bille 6 mm. 030400 Clé Descente 031300 Bille 8 mm. 031200 Ressort 031900 Rondelle 032000 031100 Ressort 030900 Protectour 031000 Collier 031700 Joint O.R. 030300 Pistón de pompage 030200...
- Page 19 PIECES DE TRANSPALETTE H-2 Nº CODE DESIGNATION 360000 Anneau Ø18 090000 Goujon Ø18 300000 Galet 020000 Ensemble fourche 030000 Hydraulique 110000 Goupille 5x50 100000 Goupille 3x30 320000 Support timon 060000 Timon 032300 GoujonØ10 160000 Ecrou M-12 180000 Vis 12x30 010000 Chassis H-2 280000 Roue 155-13”...
