MP FASTPREP-24 Classic Quick Reference Manual

Quick Reference Guide
Dome
Display
STOP START
REGISTER YOUR INSTRUMENT
to activate your warranty
Scan the code or visit
www.mpbio.com/registermyfastprep
UNPACKING THE FASTPREP-24™ Classic
Revision Date: 2023-02
Inspect the exterior shipping crate upon arrival and notify
1
MP Biomedicals immediately of any damage.
2 Open top flaps of shipping container.
Remove the top foam
3
inside the box.
Firmly grip the instrument from the
bottom left and right sides through the
provided openings, and lift foam and
Adapter
instrument vertically from the box.
4
NOTE 4 Alternatively, lay the box on its
side and carefully slide the instrument
out.
Place the instrument on bench top, making sure the air vents
5
Buttons are clear with no obstructions in the back of the unit.
!
Keep and store all spare parts, packaging materials and box.
Emergency
Stop Button
Check all components.
Notify MP Biomedicals
6
immediately of any
missing parts.
SETUP
1
2
3
Packing List Qty
FastPrep-24™ Classic 1
4
Power cord (US and EU) 2
Tube Holder Adapter 2
Securing Knob (Ratchet) 2
Screw Driver 1
Spring Assembly Set 1
Fuse 10 Amp 2
Position the FastPrep-24 Classic
in its final installation position
and plug in the power cord.
Disengage the Emergency Stop
Buttom by twisting clockwise.
Press the Power Switch on
the back of the instrument.
The screen will display the
Home Screen.
To open the dome, unlock
Dome clip.
Unscrew the ratchet nut for
remove any removing foam
around the axis and below
the adapter.
Replace bowl and adapter
To close the dome, carefully
press & lock the dome clip.
Scan the code for detailed manual and videos.
