SERIES 7005
CANTILEVER STORAGE
SYSTEM w/CASTERS
CAUTION
• Inspect unit and all components
for any loosening that may have
occurred during shipping •
ATTENTION
Review entire manual before
starting assembly
Mortech™ Manufacturing Inc.
411 North Aerojet Avenue, Azusa, CA 91702
(626) 334-1471 www.mortechmfg.com
™
Technical Users' Manual
Installation and Operating Instructions
JULY 2010
ISO Doc. #OM7005 (REV B)
Advertisement
Table of Contents
Related Manuals for MORTECH 7005 Series
Summary of Contents for MORTECH 7005 Series
- Page 1 • Inspect unit and all components for any loosening that may have occurred during shipping • ATTENTION Review entire manual before starting assembly JULY 2010 Mortech™ Manufacturing Inc. 411 North Aerojet Avenue, Azusa, CA 91702 ISO Doc. #OM7005 (REV B) (626) 334-1471 www.mortechmfg.com...
-
Page 2: Safety Information
• Do the moving parts operate smoothly? Modifying the equipment can cause injury and damage. • Is unit draining properly? Use the equipment only as designed by Mortech. • Are plumbing features operating properly? • Are all nuts, bolts, and pins secured in place? If unit has an issue contact customer relations. -
Page 3: Parts Listing
7005 Cantilever Storage System w/Casters Parts listing 16-1/2 16-1/2 77-1/2 16-1/2 16-1/2 All measurements in inches SERIES 7005 The Adjustable Cantilever Storage Rack can be free standing or floor mounted. Adjustable rack arms allow the end user to MODELS AVAILABLE set the desired tier spacing. - Page 4 1. DO NOT FORCE BOLTS. IF THE ARE NOT SCREWING EASILY, REMOVE THEM AND MAKE SURE YOU ARE PROPERLY LINED UP. FORCING THE BOLT WILL STRIP THE INTERNAL THREADS. Mortech Manufacturing Inc. 411 North Aerojet Avenue, Azusa, CA 91702 (626) 334-1471 www.mortechmfg.com...
-
Page 5: Tray Options
7005 Cantilever Storage System w/Casters Tray options MODEL T3603 The hi-tech plastic operating platform is shaped to fit the subframe of the carrier chassis. A real time and energy saver, the detachable hi-tech plastic top will ensure a secure fit with no mechanical fastening devices required. - Page 6 Tray Options 7005 Cantilever Storage System w/Casters MODEL T3614 A real time and energy saver, the detachable stainless steel top will ensure a secure fit with no mechanical fastening devices required. It is fabricated from 14 gauge 304 stainless steel with No. 4 finish. Interior long sides are angled to allow for easier body transfer.
-
Page 7: Operation
7005 Cantilever Storage System w/Casters Operation Cadaver Handling System 1. Transfer from Storage System to Cadaver Lift. (Any lift can work with the system) 2. Maneuver Lift to Body Carrier 3. Transfer from Cadaver Lift to Body Carrier. 4. Transport Carrier to Processing Area. 5. -
Page 8: Maintenance Instructions
7005 Cantilever Storage System w/Casters Maintenance MAINTENANCE INSTRUCTIONS Shop Oil and Grease - These soils may be corrosive and may not allow the surface to maintain passivity, and so MAINTENANCE SCHEDULE removal is a necessity. Soap or detergent and water may be The unit requires regular maintenance and follow the used or a combination of detergent and water plus a solvent. -
Page 9: Maintenance Record
7005 Cantilever Storage System w/Casters Maintenance record MAINTENANCE RECORD Date JULY 2010 MFGISO DOC. #OM7005 (REV. B) -
Page 10: Training Record
Training record 7005 Cantilever Storage System w/Casters TRAINING RECORD Date JULY 2010 MFGISO DOC. #OM7005 (REV. B) -
Page 11: Warranty
Customer Relations. FAX (626) 334-1704 www.mortechmfg.com PROPRIETARY NOTICE info@mortechmfg.com The information in this manual is the property of Mortech © COPYRIGHT MORTECH MANUFACTURING INC., ALL Manufacturing. Mortech Manufacturing reserves all patent RIGHTS RESERVED. rights, proprietary design rights, manufacturing rights,...
