SERIES 7010
PORTABLE MORTUARY STORAGE
RACK SYSTEM w/ROLLERS
Available in
Two, Three, Four and Five Tiers
CAUTION
• Inspect unit and all components
for any loosening that may have
occurred during shipping •
ATTENTION
Review entire manual before
starting assembly
Mortech™ Manufacturing Inc.
411 North Aerojet Avenue, Azusa, CA 91702
(626) 334-1471 www.mortechmfg.com
™
Technical Users' Manual
Installation and Operating Instructions
CAUTION
• ALWAYS TAKE CARE WHEN
LOADING AND UNLOADING
THE RACK •
JULY 2007
ISO Doc. #OM7010 (REV C)
Advertisement
Table of Contents
Related Manuals for MORTECH 7010 Series
Summary of Contents for MORTECH 7010 Series
- Page 1 • Inspect unit and all components for any loosening that may have occurred during shipping • ATTENTION Review entire manual before starting assembly JULY 2007 Mortech™ Manufacturing Inc. 411 North Aerojet Avenue, Azusa, CA 91702 ISO Doc. #OM7010 (REV C) (626) 334-1471 www.mortechmfg.com...
-
Page 2: Bloodborne Disease Notice
• Do the moving parts operate smoothly? Modifying the equipment can cause injury and damage. • Is unit draining properly? Use the equipment only as designed by Mortech. • Are plumbing features operating properly? • Are all nuts, bolts, and pins secured in place? If unit has an issue contact customer relations. - Page 3 Series 7010 Portable Mortuary Storage Rack Systems Parts listing STAINLESS STEEL CONSTRUCTION NYLON ROLLER ASSEMBLY (TYP) MODEL T3626 BODY TRAY (TYP) TRAY STOP (TYP) TRAY BUMPER TRAY GUIDES Ø6" CASTER WHEEL w/BRAKE MECHANISM SERIES 7010 The Portable Mortuary Rack is ideal for a variety of cadaver storage applications. It is more compact than conventional cantilever storage units allowing for greater storage capacity without increasing space.
- Page 4 Parts listing Series 7010 Portable Mortuary Storage Rack Systems NYLON WHEEL ASSEMBLY (A) 1. ASSEMBLY, Roller, single 2. M-122 Roller, nylon 3. M-150 Bushing, bronze 4. M-123 Spacer, roller 5. End Uprights Shaft, STS-434 6. Washer, flat 3/8 7. Nut, 3/8-16 WELDED END UPRIGHT STS-434...
- Page 5 Series 7010 Portable Mortuary Storage Rack Systems Operation TRAY LATCH ASSEMBLY AFTER INSERTING THE TRAY, FLIP THE TRAY LATCH TO SECURE THE TRAY WHEN REMOVING THE TRAY SIMPLY LIFT THE TRAY LATCH TO REMOVE THE TRAY MAY 2010 MFGISO DOC. #OM7010 (REV C)
- Page 6 Parts listing Series 7010 Portable Mortuary Storage Rack Systems SERIES 7010 7010-5 5 TIER 7010-4 4 TIER 7010-3 3 TIER 7010-2 2 TIER MAY 2010 MFGISO DOC. #OM7010 (REV C)
-
Page 7: Operation
Series 7010 Portable Mortuary Storage Rack Systems Operation TOTAL ROLL CADAVER HANDLING SYSTEM Total Roll Cadaver Handling System All equipment in the system incorporates roller assemblies which allow for easy tray transfer from one component to the next. No manual lifting is required and in many instances only one person is required to complete the transfer. - Page 8 Parts listing Series 7010 Portable Mortuary Storage Rack Systems TRAY GUIDES 3/8” X 1” HEX HEAD BOLT 3/8” X 1” HEX HEAD BOLT 1. Take the tray guide and place over the tubing in the front entry opening of the rack 3/8”...
-
Page 9: Component Data
METRIC CAP M8 X 1.25 X 50L Brake Lock METRIC NYLOC NUT Brake Lock Release TIGHTEN AND SECURE Mortech™ Manufacturing Inc. 411 North Aerojet Avenue, Azusa, CA 91702 (626) 334-1471 www.mortechmfg.com... -
Page 10: Maintenance Instructions
Series 7010 Portable Mortuary Storage Rack Systems Maintenance MAINTENANCE INSTRUCTIONS Shop Oil and Grease - These soils may be corrosive and may not allow the surface to maintain passivity, and so MAINTENANCE SCHEDULE removal is a necessity. Soap or detergent and water may be The unit requires regular maintenance and follow the used or a combination of detergent and water plus a solvent. -
Page 11: Maintenance Record
Series 7010 Portable Mortuary Storage Rack Systems Maintenance record MAINTENANCE RECORD Date MAY 2010 MFGISO DOC. #OM7010 (REV C) -
Page 12: Training Record
Training record Series 7010 Portable Mortuary Storage Rack System TRAINING RECORD Date MAY 2010 MFGISO DOC. #OM7010 (REV C) -
Page 13: Warranty
Customer Relations. FAX (626) 334-1704 www.mortechmfg.com PROPRIETARY NOTICE info@mortechmfg.com The information in this manual is the property of Mortech © COPYRIGHT MORTECH MANUFACTURING INC., ALL Manufacturing. Mortech Manufacturing reserves all patent RIGHTS RESERVED. rights, proprietary design rights, manufacturing rights,...
