DENVER VANITY 72 IN
INSTALLATION MANUAL
483-8064, 483-8135
ITEM #:
DIMENSIONS
72''
8''
8''
4''
4''
4''
4''
6X ø 1 3/8''
2X ø 1 3/4''
41''
Questions, problems, need help?
Before returning to your retailer, call our customer service department at :
1-866-839-2888
8 a.m. - 5 p.m., EST, Monday - Friday
Page 1
2024-07-18
www.ovedecors.com | customerservice@ovedecors.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for OVE DENVER 483-8064
Summary of Contents for OVE DENVER 483-8064
- Page 1 DENVER VANITY 72 IN INSTALLATION MANUAL 483-8064, 483-8135 ITEM #: DIMENSIONS 72’’ 8’’ 8’’ 4’’ 4’’ 4’’ 4’’ 6X ø 1 3/8’’ 2X ø 1 3/4’’ 41’’ Questions, problems, need help? Before returning to your retailer, call our customer service department at : 1-866-839-2888 8 a.m.
-
Page 2: Parts List
PARTS LIST ITEM # DESCRIPTION QUANTITY REPLACEMENT PART CODE Countertop 99VCT2258-FY Backsplash 99VBS-7106TX96 Basin 99VBA2100-FY Pebble Gray: 99VDO9791-EI Tilt-down drawer (left) White: 99VDO8389-EI Pebble Gray: 99VDO9794-EI Tilt-down drawer (right) White: 99VDO8403-EI Pebble Gray: 99VDO9789-EI Door (left) White: 99VDO8387-EI Pebble Gray: 99VDO9788-EI Door (right) White: 99VDO8386-EI Pebble Gray: 99VDO9790-EI... - Page 3 PARTS LIST (Continued) ITEM # DESCRIPTION QUANTITY REPLACEMENT PART CODE Satin Nickel: 99VHA2718-FY Handle (long) Matte Gold: 99VHA2714-FY Satin Nickel: 99VHA2660-FY Handle (short) Matte Gold: 99VHA2659-FY Hinge (full overlay) 99VHI3146-FY Hinge (tilt-down drawer) 99VHI-L2C76A99-FY Hinge (half overlay) 99VHI-W1X3V798 Butterfly hinge (right) 99VHI3151-FY Butterfly hinge (left) 99VHI3148-FY...
-
Page 4: Installation
INSTALLATION Unpacking the countertop Attaching the countertop 1.1. Lift up the countertop (A) from the vanity base 2.1. Apply silicone (sold separately) onto the vanity base and place it on a protective floor covering such where the countertop (A) will be placed. as cardboard to prevent damage. - Page 5 INSTALLATION Drying Completing the assembly 5.1. Wipe away any seeping silicone from underneath 6.1. Installation Complete - Allow any silicone applied to the the countertop (A) and backsplash (B) with a caulk vanity to dry for 24 hours before use. finishing tool.
- Page 6 HOW TO ADJUST THE DRAWER How To Remove The Drawer *If necessary, each drawer is designed to be removed or replaced: 1.1. Pull out the drawer until the lock pins located at the sides of the drawer are easy to reach. Pull up the lock pin on the left side of the drawer, and push it down on the right side to release the drawer.
- Page 7 HOW TO ADJUST THE SHELF How To Remove The Shelf Each shelf can be removed or repositioned to create more space: 1.1. Uninstall the screws and remove the shelf (H). 1.2. Pull out the shelf holders (R). How To Install The Shelf There are multiple positions to install the shelf to help you have the desired space.
- Page 8 HOW TO ADJUST THE DOOR’S POSITION Door’s in and out adjustment Each door will come pre-installed on the cabinet. Should your doors arrive and not be properly aligned, follow these steps to adjust them. 1.1. To adjust the door’s depth, loosen screw (A), adjust the door, and then tighten screw (A). Door’s left and right adjustment 2.1.
-
Page 9: Maintenance And Care
▶ Vanities installed with obvious visual defects. ▶ Defects or damages to vanities caused by installation that do not comply strictly with the instructions set forth in OVE DECORS’s installation manual. ▶ Defects or damage to vanities caused by severe accidents (e.g., fire, impacts).
