SAYURI GIANNA INSTALLATION MANUAL | MANUEL D’INSTALLATION | MANUAL DE INSTALACIÓN Questions, problems, need help? Call our customer service department at 1-866-839-2888, 8 a.m. - 5 p.m., EST, Monday - Friday Questions, problèmes ou besoin d’aide? Contactez notre service à la clientèle au 1-866-839-2888, du lundi au vendredi de 8h00 à...
Page 3
FLOOR TRACING TEMPLATE GUIDE DE TRAÇAGE GUÍA DE SEGUIMIENTO Rough-in zone for water supply pipes Floor cut-out for P-trap Rough-in zone for waste pipe Zone indiquée pour tuyaux d’entrée d’eau Ouverture dans le plancher pour p-trap Zone indiquée pour tuyau d’évacuation Zona para tuberías de entrada de agua Abertura en el piso de p-trampa Zona para la tubería de desagüe...
Page 4
PART LIST LISTE DES PIÈCES LISTA DE PIEZAS PART # DESCRIPTION QUANTITY CODE # DE PIÈCE DESCRIPTION QUANTITÉ CODE PARTE # DESCRIPCIÓN CANTIDAD CÓDIO 1-1/2 NPSM to SCH40 Pipe Adapter Raccord 1-1/2 NPSM à Tuyau SCH40 Adaptador 1-1/2 NPSM à SCH40 Tubo TOOLS REQUIRED OUTILS REQUIS HERRAMIENTAS NECESARIAS...
Page 5
CAUTION ATTENTION ATENCIÓN You will need at least two people to install this product properly. In order to reduce the risks of personal injuries, do not support or lift the bathtub by the rim. Provide adequate support under the feet. The distributor is not responsible for any damage to the unit or personal property caused by improper installation.
Page 6
FLOOR TRACING TRAÇAGE SEGUIMIENTO 1.1. Use the floor tracing template supplied in this manual to trace the proper position of your supply pipes, your drain and your P-Trap rough-in. 1.2. Place the bathtub in the desired position on the floor, manually locate the proper position for your plumbing and trace the outline on the floor. 1.3.
Page 7
INSTALLATION: USING REGULAR PVC PIPING INSTALLATION: UTILISATION DE TUYAU PVC RÉGULIER INSTALACIÓN: USO DE TUBERÍAS DE PVC REGULARES 2.1. Apply Teflon Tape and/or thread sealant to the pre-installed bathtub drain. 2.2. Screw the provided 1-1/2 NPSM to SCH40 Pipe Adapter to the drain. Cut a 1-1/2 PVC Extension Tube to the desired length. Then connect it to the Adapter using PVC pipe sealant to join the parts together.
Page 8
SEALING SCELLAGE SELLADO BEFORE FIXING YOUR TUB TO THE FLOOR, ENSURE THAT YOU HAVE INSTALLED YOUR FAUCET (if applicable) AND THAT YOU HAVE CHECKED FOR LEAKS. 3.1. Test for leak by filling up the tub and let it drain. Then check all plumbing connections for leaks. 3.2.
CONSUMER RESPONSIBILITIES The DISTRIBUTOR’s products will remain beautiful for many years if properly cared for. The DISTRIBUTOR does not recommend the use of harsh abrasive cleansers on any of its products. Harsh cleansers will damage the finish of your product. MAINTENANCE ▶...
