Pioneer DV-S6D Service Manual

Hide thumbs

Quick Links

Download this manual

DVD PLAYER

DV-S6D

THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).

Model

Type

DV-S6D

CONTENTS

1. SAFETY INFORMATION ....................................... 2

2. EXPLODED VIEWS AND PARTS LIST ................. 3

3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM .. 10

4. PCB CONNECTION DIAGRAM ........................... 33

5. PCB PARTS LIST ................................................ 46

6. ADJUSTMENT ..................................................... 51

PIONEER CORPORATION

PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.

PIONEER ELECTRONIC (EUROPE) N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium

PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936

PIONEER CORPORATION 1999

ST ANDBY

ST ANDBY / ON

Power Requirement

AC110V

4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan

ÛN¿∫>Û

D V D P LA Y ER

ACOUSTIC DAMPER MECHANISM

5.1CH

MODE

DNR

FL OFF

Region No.

7. GENERAL INFORMATION .................................. 53

7.1 DIAGNOSIS ................................................... 53

7.1.1 TEST MODE SCREEN DISPLAY ............. 53

7.1.2 TROUBLE SHOOTING ............................ 55

7.1.3 ERROR CODE ......................................... 56

7.1.4 DISASSEMBLY ........................................ 60

7.2 PARTS ........................................................... 61

7.2.1 IC ............................................................. 61

7.2.2 DISPLAY .................................................. 78

8. PANEL FACILITIES AND SPECIFICATIONS ....... 79

ORDER NO.

RRV2228

Remarks

T - ZZE OCT. 1999 Printed in Japan

Need help?

Do you have a question about the DV-S6D and is the answer not in the manual?

Questions and answers

Summary of Contents for Pioneer DV-S6D

Page 1: Table Of Contents
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A. PIONEER ELECTRONIC (EUROPE) N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936 PIONEER CORPORATION 1999 T –...
Page 2: Safety Information
The use of a substitute replacement component which does Leakage 0.5mA current Device not have the same safety characteristics as the PIONEER tester under recommended replacement one, shown in the parts list in test this Service Manual, may create shock, fire, or other hazards.
Page 3: Exploded Views And Parts List
DV-S6D 2. EXPLODED VIEWS AND PARTS LIST • NOTES: Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. • mark found on some component parts indicates the importance of the safety factor of the part.
Page 4: Exterior Section
DV-S6D 2.2 EXTERIOR SECTION Refer to "2.3 FRONT PANEL SECTION". ¶ EXTERIOR SECTION PARTS LIST Mark No. Description Part No. Mark No. Description Part No. 1 Bonnet S VXX2617 Screw BCZ40P060FNI 2 Door Panel VNK4524 Clamper Plate VNE2068 3 DVD Plate...
Page 5: Front Panel Section
DV-S6D 2.3 FRONT PANEL SECTION 9(1/2) 5(2/3) 9(2/2) 5(3/3) 5(1/3) ¶ FRONT PANEL SECTION PARTS LIST Mark No. Description Part No. Mark No. Description Part No. LED Lens PNW2019 FLKY Assy VWG2093 PWSB Assy VWG2098 Illumi Holder VNK4098 DILB Assy...
Page 6: Bottom View Section
DV-S6D 2.4 BOTTOM VIEW SECTION Refer to "2.5 LOADING MECHANISM ASSY".
Page 7 DV-S6D ¶ BOTTOM VIEW SECTION PARTS LIST Mark No. Description Part No. DVDM Assy VWS1384 JCKB Assy VWV1682 • • • • • POWER SUPPLY Assy VWR1316 • • • • • VQEB Assy VWV1669 Loading Mechanism Assy VWT1164 • • • • •...
Page 8: Loading Mechanism Assy
DV-S6D 2.5 LOADING MECHANISM ASSY • Top View • Bottom View Refer to "2.6 TRAVERSE MECHANISM ASSY-S". ¶ LOADING MECHANISM ASSY PARTS LIST Mark No. Description Part No. Mark No. Description Part No. 1 Traverse Mechanism Assy-S VXX2653 Loading Motor Assy...
Page 9 DV-S6D 2.6 TRAVERSE MECHANISM ASSY-S • Top View ¶ TRAVERSE MECHANISM ASSY-S PARTS LIST Mark No. Description Part No. Mark No. Description Part No. SMEB Assy VWG2048 Hook VNL1770 FGSB Assy VWG2009 FFC Holder VNL1802 Motor VXM1079 Mechanism Base VNL1806...
Page 10: Block Diagram And Schematic Diagram
DV-S6D 3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM 3.1 BLOCK DIAGRAM 36/16M DVDM ASSY (24P) (24P) YCBR0-7 CN120 SPDL (Y0-Y7) 95-98, MOTOR OEIC MPEG2 100-103 RF IC SD0-SD7 DSPRF 149,150, DECODER 7,6, 7,6, B1-B4 57-60 IC101 152-155, DECODER DOUT0 MITUBISHI 63-66...
Page 11: Power Supply
DV-S6D (26P) (26P) CN110 CN201 M + 6V +12V POWER +12V SUPPLY ASSY CN101 LIVE AC IN +3.3V NEUTRAL EV+5V – 27V EDO DRAM IC803 M5M4V18165 DTP-6S JA801 JCKB ASSY COMPOSITE VIDEO OUT (15P) Q805, JA701 CN999 Q806 S VIDEO...
Page 12 DV-S6D 3.2 LOMB, LOSB, SMEB, FGSB ASSYS and OVERALL WIRING DIAGRAM Note : When ordering service parts, be sure to refer to "EXPLODED VIEWS and PARTS LIST" or "PCB PARTS LIST". 1/2, JCKB ASSY (VWV1682) J301 J101 DILB ASSY (VWG2100)
Page 13 DV-S6D 1/4- POWER SUPPLY ASSY (VWR1316) DVDM ASSY (VWS1384) AC110V 60Hz AC POWER CORD ADG7006 PICKUP : RF SIGNAL ROUTE ASSY : FOCUS SERVO LOOP LINE (VWY1055) : TRACKING SERVO LOOP LINE : SLIDER SERVO LOOP LINE FGSB ASSY (VWG2009)
Page 14 DV-S6D 3.3 DVDM ASSY (1/4) DVDM ASSY (VWS1384) (DVD) (DVD) CN201 VKN1324 CN110 VKN1479 (CD) (CD) CN120 VKN1484 CN1030 IC352 : VKN1471 SPDL & FTS DRIVER...
Page 15 DV-S6D : The power supply is shown with the marked box. : RF SIGNAL ROUTE : ROM DATA SIGNAL ROUTE : FOCUS SERVO LOOP LINE : TRACKING SERVO LOOP LINE : SLIDER SERVO LOOP LINE (DVD) (DVD) − − FOR CHECKER...
Page 16 DV-S6D 3.4 DVDM ASSY (2/4) 3 TO 5 DVDM ASSY (VWS1384) CONVERTER MC74VHCT541ADT 5 TO 3 CONVERTER MC74VHCT541DT (V_SEL) X601 20MHz DSS1110...
Page 17 DV-S6D : The power supply is shown with the marked box. : AUDIO SIGNAL ROUTE : ROM DATA SIGNAL ROUTE MN414800CSJ-07 DVD ENCODER...
Page 18 DV-S6D 3.5 DVDM ASSY (3/4) DVDM ASSY (VWS1384) 100/10 MPEG2 DECODER MITSUBISHI AV1 3 - 5 CONVERTER TC74VHCT541ADT...
Page 19 DV-S6D : AUDIO SIGNAL ROUTE : ROM DATA SIGNAL ROUTE : VIDEO SIGNAL ROUTE : Y SIGNAL ROUTE : C SIGNAL ROUTE : R SIGNAL ROUTE : G SIGNAL ROUTE : B SIGNAL ROUTE CLOCK GENERATOR CN101...
Page 20 DV-S6D 3.6 DVDM ASSY (4/4) DVDM ASSY (VWS1384) : AUDIO SIGNAL ROUTE : VIDEO SIGNAL ROUTE : Y SIGNAL ROUTE : C SIGNAL ROUTE : R SIGNAL ROUTE : G SIGNAL ROUTE : B SIGNAL ROUTE VKN1585 3 TO 5 CONVERTER...
Page 21 DV-S6D...
Page 22 DV-S6D 3.7 VQEB ASSY VQEB ASSY (VWV1669) (6 ch, DNR) VIDEO ENCODER...
Page 23 DV-S6D : The power supply is shown with the marked box. CN802 14 17 12 15 13 16 : ROM DATA SIGNAL ROUTE : R SIGNAL ROUTE : VIDEO SIGNAL ROUTE : G SIGNAL ROUTE : Y SIGNAL ROUTE : B SIGNAL ROUTE...
Page 24: Dts Decoder
DV-S6D 3.8 JCKB ASSY (1/2) JCKB ASSY (VWV1682) IC401 : 96k, 24 bit 6 ch DAC DTS DECODER...
Page 25 DV-S6D : AUDIO SIGNAL ROUTE TC4W53F : The power supply is shown with the marked box.
Page 26 DV-S6D 3.9 JCKB ASSY (2/2) JCKB ASSY (VWV1682)
Page 27: Video Amp
DV-S6D : The power supply is shown with the marked box. : AUDIO SIGNAL ROUTE : VIDEO SIGNAL ROUTE : Y SIGNAL ROUTE : C SIGNAL ROUTE VIDEO AMP (CB) (CB) (CR) (CR)
Page 28 DV-S6D 3.10 FLKB, PWSB and DILB ASSYS FLKY ASSY (VWG2093) R141 R143...
Page 29 DV-S6D PWSB ASSY (VWG2098) : The power supply is shown with the marked box. DILB ASSY (VWG2100) FLKY ASSY PWSB ASSY S101 : ¡¢ (FORWARD) S201 : STANDBY/ON(POWER) S102 : 41 (REVERSE) S103 : 7 (STOP) S105 : 0 (OPEN/CLOSE)
Page 30 DV-S6D 3.11 POWER SUPPLY ASSY NOTE OF SPARE PARTS IN POWER SUPPLY (SYPS) ASSY • In case of repairing, use the described parts only to prevent an accident. • Please write the red mark on the board when the primary section of POWER SUPPLY (SYPS) Assy is repaired.
Page 31 DV-S6D P211 L211 D211 VEK1041 39µH/1.3A VZF1065 1.0A/60V C212 C211 D213 330/35 100/35 MTZJ15B CN201 L711 D711 R711 52806-2610 39µH/1.3A VZF1065 0.51 1/2W M+6V M+6V VZC1061 C711 330/35 GND (M+6V, M+12V) GND (M+6V, M+12V) IC311 M+12V D311 VZF1078 GND (D+12V)
Page 32 DV-S6D WAVEFORMS Note : The encircled numbers denote measuring point in the schematic diagram. Measurement condition : No. 1 to 4 and 6 to 11 : Disc MA1, Title 1-chp 1 No. 5 : CD, ABEX-784 Track 1 No. 12 to 14 : MJK1, Title 1-chp 4 or T2-1 No.
Page 33: Pcb Connection Diagram
DV-S6D 4. PCB CONNECTION DIAGRAM NOTE FOR PCB DIAGRAMS : 1. Part numbers in PCB diagrams match those in the schematic 3. The parts mounted on this PCB include all necessary parts for diagrams. several destinations. 2. A comparison between the main parts of PCB and schematic For further information for respective destinations, be sure to diagrams is shown below.
Page 34 DV-S6D 4.2 DVDM ASSY • This PCB is a four-layered board. CN666 CN999 DVDM ASSY IC23 IC26 IC31 Q810 Q808 Q812 IC25 IC54 Q809 Q807 Q811 IC21 IC801 VR851 IC807 VC21 IC22 IC806 IC903 IC261 IC303 PICKUP ASSY IC302 IC702...
Page 35 DV-S6D • This PCB is a four-layered board. DVDM ASSY IC905 IC803 IC27 IC805 IC802 IC73 CN101 IC201 IC701 IC231 Q542 Q179 IC608 Q106 Q105 Q237 IC299 Q113 Q543 Q106 IC904 Q114 IC609 IC611 IC612 Q101 IC751 Q103 IC792 Q251...
Page 36 DV-S6D 4.3 VQEB ASSY VQEB ASSY SIDE A (VNP1696-B) VR102 VR101 Q551 Q541 IC106 Q531 IC103 IC105 Q521 Q511 Q501 VQEB ASSY SIDE B (VNP1696-B) CN802 Q502 Q512 IC102 Q522 IC104 Q532 Q542 Q552...
Page 37: Power Supply Assy
DV-S6D 4.4 POWER SUPPLY ASSY AC IN POWER SUPPLY ASSY Q104 IC151 Q101 Q102 Q103 Q801 IC801 IC201 IC411 IC311 SIDE A CN110...
Page 38 DV-S6D 4.5 JCKB ASSY JCKB ASSY Q194 Q193 Q384 Q385 Q395 Q396 Q345 IC405 IC540 IC50 IC301 IC351 IC400 Q294 Q293 IC404 IC101 IC201 IC222 Q371 IC401 IC262 SIDE A...
Page 39 DV-S6D (VNP1707-A) CN905 CN901 Q715 Q705 Q706 IC901 IC501 Q805 Q716 Q806 IC902 Q666 IC666 IC601 IC555 IC505 IC999 Q996...
Page 40 DV-S6D JCKB ASSY SIDE B...
Page 41 DV-S6D (VNP1707-A) Q393 Q391 Q382 Q381 Q292 Q291 Q192 Q191 Q394 Q392 Q365 Q261...
Page 42 DV-S6D 4.6 FLKY, PWSB and DILB ASSYS FLKY ASSY PWSB ASSY (VNP1710-A) SIDE A...
Page 43 DV-S6D DILB ASSY (VNP1710-A) CN602 (VNP1710-A) IC102 Q101...
Page 44 DV-S6D DILB ASSY (VNP1710-A) FLKY ASSY SIDE B...
Page 45 DV-S6D (VNP1710-A) IC101 Q102 PWSB ASSY (VNP1710-A)
Page 46: Pcb Parts List
DV-S6D 5. PCB PARTS LIST NOTES : Parts marked by “ NSP ” are generally unavailable because they are not in our Master Spare Parts List. mark found on some component parts indicates the importance of the safety factor of the part.
Page 47 DV-S6D Mark No. Description Part No. Mark No. Description Part No. Q106, Q109 2SA1576A C722, C904 CKSRYB103K50 Q105, Q114, Q251 2SC4081 C101, C102, C114, C118, C119 CKSRYB104K16 Q602 DTA114EUA C121, C130, C138, C204 CKSRYB104K16 Q107, Q111, Q601 DTC114EUA C212, C213, C227, C228, C231...
Page 48 DV-S6D Mark No. Description Part No. Mark No. Description Part No. CN1030 12P CONNECTOR VKN1471 Q193, Q293, Q383, Q395 2PB709A CN602, CN901 15P CONNECTOR VKN1474 Q715, Q716, Q996 2PD601A CN110 26P CONNECTOR VKN1479 Q999 2SB1260 CN802 CONNECTOR VKN1529 Q345, Q705, Q706, Q805, Q806...
Page 49 DV-S6D Mark No. Description Part No. Mark No. Description Part No. C555, C571, C573, C581, C583 CKSQYF104Z25 RESISTORS C591, C593, C610, C706, C806 CKSQYF104Z25 All Resistors RS1/10S&&&J C808, C809, C820, C901, C902 CKSQYF104Z25 C904, C905, C908, C910, C912 CKSQYF104Z25 OTHERS...
Page 50 DV-S6D Mark No. Description Part No. D105, D107, D110, D514 1SS270A D108 VZF1045 D211, D711 VZF1065 D213 MTZJ15B D311 VZF1076 D411 VZF1075 D511 10ELS2 D513 MTZJ8.2B D811 VZF1054 D812 MTZJ6.8B RESISTORS R511 (33Ω) VZC1057 R611 VZC1060 R711 (0.51Ω, 1/2W) VZC1061...
Page 51: Adjustment
DV-S6D 6. ADJUSTMENT 6.1 ADJUSTMENT ITEMS AND LOCATION Note : When the Traverse mechanism adjustment is not properly adjusted, jitter, error rate and playability are defective. The noise may come out by the case. Adjustment Points (PCB Part) Adjustment Items...
Page 52: Electrical Adjustment
DV-S6D 6.4 ELECTRICAL ADJUSTMENT Master Clock Adjustment • When not properly adjusted : Uneven color DVDM ASSY • Normal mode • Power ON 33.868800MHz ± 160Hz VC21 Player START DVDM ASSY IC21 Frequency counter Pin 5...
Page 53: General Information
DV-S6D 7. GENERAL INFORMATION 7.1 DIAGNOSIS 7.1.1 TEST MODE SCREEN DISPLAY Consecutive double-OSD display is supported during test mode. The screen is composed 10 lines with a maximum of 32 characters per line. It can't be used with the debugging display mode together.
Page 54 DV-S6D (10) Output video system [V – ∗ ∗ ∗ ∗] (19) The part number of the flash ROM and system controller [∗ ∗ ∗ ∗ ∗ ∗ / ∗ ∗ ∗ ∗ ∗ ∗ ∗ ] NTSC system [NTSC]...
Page 55: Trouble Shooting
DV-S6D 7.1.2 TROUBLE SHOOTING • No Power ON • FL is not turned ON • FL indication is unusual START • Blow out fuse of the primary side Power ON • Blow out micro-fuse on the POWER SUPPLY Assy. (Check the each voltage.) (P611, P211, R711) •...
Page 56: Error Code
DV-S6D 7.1.3 ERROR CODE l l o c i f ) . l ) . l l l o n i l u l i l l a t ' d t I ( l l a ) . l ) .
Page 57 DV-S6D ± r i f r i f t s i t ' n t i s v i f r i f t ' n v i f 7 " " 3 t i s 7 " " 3...
Page 58 DV-S6D u l i l i a u l i u l i l l o l l o l l o f i c µ . ) µ f i c c i f c i f f i c...
Page 59 DV-S6D...
Page 60: Disassembly
DV-S6D 7.1.4 DISASSEMBLY DVDM ASSY TRAVERSE MECHANISM ASSY-S Remove a Bonnet (Seven screws). Remove a Bonnet (Seven screws). POWER OPEN/CLOSE ×3 Disc Tray DVDM ASSY Loading POWER SUPPLY ASSY Mechanism Assy JCKB ASSY POWER SUPPLY DVDM ASSY Short Open ASSY side...
Page 61: Parts
DV-S6D 7.2 PARTS 7.2.1 IC • The information shown in the list is basic information and may not correspond exactly to that shown in the schematic diagrams. • List of IC CY2081SL-655, PD3410A, VYW1669, M65773FP, LC89051V, YSS912C, PM0023AF CY2081SL-655 (DVDM ASSY : IC21) •...
Page 62 DV-S6D PD3410A (DVDM ASSY : IC601) • System Control IC • Pin Function − − − − − t f i t s i c t i − l l i t f i t s i , c i - t l −...
Page 63 DV-S6D c t i − − − − − − c t i c t i − c t i c t i c t i c t i − c t i i n i − − l l o −...
Page 64 DV-S6D − t i s d i l t i s − − − l l o l a i e l l l a i e l l − e l l − − −...
Page 65 DV-S6D − − − − − − −...
Page 66 DV-S6D VYW1669 (DVDM ASSY : IC603) • 16M bit Flash Memory IC • Block Diagram - DQ 29-36,38-45 RY/BY RY/BY Buffer Erase Voltage Input/Output Generator Buffers State Control BYTE RESET Command Program Voltage Register Generator Chip Enable Output Enable Data Latch...
Page 67 DV-S6D M65773FP (DVDM ASSY : IC801) • MPEG2 Decoder IC • Block Diagram 16M bit SDRAM SDRAM Bit Streem Descrambler Controller Bit Streem Input Interface Video Decoder Sub-picture Decoder Internal Display Processor Special Playback 16M DRAM Processor Host Video Output...
Page 68 DV-S6D − y l l n i l − n i l − n i l n i l...
Page 69 DV-S6D n i l n i l n i l n i l n i l n i l n i l n i l n i l n i l n i l n i l n i l...
Page 70 DV-S6D LC89051V (DVDM ASSY : IC903) • Digital Audio IC • Block Diagram Input Block C bit Detection Data Demodulation Microcontroller Timing Block Interface C bit Detection TEST1 Mute Output Mute Output TEST TEST2 XMODE 21 22 20 • Pin Function...
Page 71 DV-S6D YSS912C (JCKB ASSY : IC501) • DTS Decoder • Block Diagram OVFB /CSB 3,4,25-29, 42-44,58-59 RAMA0 - 16 ,61,64,70, 86,87 RAMOEN RAMWEN RAMCEN SDIB3 72 - 79 SDIB3 SDIB2 SDIB1 SDIB0 SDOA2 SDOA1 SDOA0 OPORT0 - 7 32 - 39...
Page 72 DV-S6D • Pin Function − l l i − − − − f - r t l i f . t i − − − − − − −...
Page 73 DV-S6D − − − − − − − − − t t i l l u...
Page 74 DV-S6D PM0023AF (VQEB ASSY : IC101) • VQE4 IC • Block Diagram MPU Interface with Macrovision Configuration Register Closed Caption VBID MPEG2 Sync and Timing Signal Generator Video Generator Decoder MPEG2 Video Processing Engine 6 ch Input 6 ch Video 75 Ω...
Page 75 DV-S6D e l l − . ) r v i t y t i c i t . ) r v i t y t i − − l l u − − l l u − l l u l l u −...
Page 76 DV-S6D − − v i t y t i c i t v i t y t i − − − − − t s i − t s i − − Ω t s i Ω t s i µ...
Page 77 DV-S6D Ω t s i > µ t i c Ω t s i Ω t s i Ω t s i µ t i c Ω t s i > µ t i c Ω t s i t s i...
Page 78: Display
DV-S6D 7.2.2 DISPLAY VAW1050 (FLKY ASSY : V101) • FL DISPLAY G2 to G11 192kHz V-PART GUIDE REPEAT COND.MEMORY DOLBY ANGLE VOCAL PARTNER LAST MEMORY DIGITAL 96kHz DOWN MIX TITLE TOTAL REMAIN SACD HDCD • ANODE AND GRID ASSIGNMENT 192kHz...
Page 79: Panel Facilities And Specifications
DV-S6D 8. PANEL FACILITIES AND SPECIFICATIONS 8.1 PANEL FACILITIES Front Panel ÛN¿∫>Û DVD PLA YER ACOUSTIC DAMPER MECHANISM ST ANDBY ST ANDBY / ON ¡ ¢ 5.1CH FL OFF MODE ˜ Î Disc tray Remote sensor When loading a disc, place in the disc tray with the Point the remote control toward the remote sensor label side facing up.
Page 80 DV-S6D Display Window REPEAT COND. MEMORY DOLBY 96 kHz ANGLE LAST MEMORY DIGITAL DOWN MIX TOTAL REMAIN TITLE 96 kHz indicator DOLBY DIGITAL indicator Indicates that the currently loaded disc contains an Indicates Dolby Digital audio playback. audio signal with a sampling frequency of 96 kHz.
Page 81 Use to connect this player to another component Use to set which output is used to output the video bearing the Pioneer Î mark. This lets you control signals. Select either video/S-video or component this unit as though it were a component in a system.
Page 82 DV-S6D...
Page 83 DV-S6D Remote Control (Buttons indicated with * are used for menu operation.) MENU button* Use to display or close the DVD menu screen. (standby/on) button Press to switch the player on or to put in standby. AUDIO button OPEN/ CLOSE...
Page 84 DV-S6D RETURN button* JOG MODE indicator Use to go one menu back (current settings are Lights red when the player is in the Jog Mode. maintained). Use RETURN when you do not want to change the option setting in a menu.
Page 85: Specifications
DV-S6D 8.2 SPECIFICATIONS General Other terminals System .. DVD system and Compact Disc digital audio system CONTROL IN .......... Minijack (3.5 ø) Power requirements ......AC 110 V, 60 Hz CONTROL OUT ........Minijack (3.5 ø) Power consumption ..........18 W Power consumption in standby mode ..
