- Page 1 AEG-1 User’s Guide...
- Page 2 Thank you! Thank you for choosing the Baggs AEG-1 Acoustic Electric Guitar! The AEG-1 is the culmination of a lifetime dedicated to high- performance acoustic amplification, all rooted in the craftsmanship of a luthier. Our founder and master luthier, Lloyd Baggs, began his journey as a guitar maker, creating instruments for artists like Ry Cooder, Jackson Browne, Graham Nash, and Janis Ian.
-
Page 3: Volume Control
LED is yellow, you have about 8 hours of normal playing time left. You will need to replace the battery when the LED is red. To maximize battery life, make sure to unplug your instru- ment cable when not using the AEG-1. -
Page 4: Phase Inversion
C. MIC CONTROL Use this control to mix between HiFi pickups and the Silo microphone. When the mic control is fully counterclockwise, you will hear full-range HiFi pickups only. Turn this control clockwise to mix in the Silo microphone. When turned all the way clockwise, the Silo mic is carrying the majority of the guitar’s voice with the HiFi pickups supporting the lower frequencies. -
Page 5: Battery System
Battery Compartment To properly set this control, make sure the MIC CONTROL knob (C) is turned fully clockwise (full mic position). Then carefully adjust the MIC SENSITIVITY (F) so that you get even tonal balance between the bass, mids, and treble frequencies. -
Page 6: Accessory Tray
ACCESSORY TRAY I. Mic adjustment tool. Refer to “F” for mic adjust- ment instructions. J. Allen key for truss rod adjustments. K. Soundhole feedback ring for additional feedback control in loud playing environments. To use, slide the ring beneath the strings and gently push into the gap between the top and soundhole plug. - Page 7 GUITAR SPECIFICATIONS Guitar Description: High-performance Acoustic Electric Guitar Back Woods: Indian Rosewood Side Woods: Composite Poplar frame Top Wood (A): Engelmann Spruce (Natural) Top Wood (B): Torrefied Sitka Spruce (Torrefied) Top Wood (C): Sitka Spruce (Sun Burst) Top Finish: Gloss Color: Natural, Torrefied, Sun Burst Body Bracing:...
-
Page 8: Electronics Specifications
ELECTRONICS SPECIFICATIONS Pickup System: Custom HiFi Duet with HiFi Pickups and Silo Microphone Battery: Single 9V Current Consumption: 4.1mA Battery Life: 120Hrs Input impedance: - Pickup (High) 4.7MEG - Pickup (Low) 4.7MEG Mic: 6.8K Output Impedance: 3.6K... - Page 9 LEARN MORE ABOUT WARRANTY AND REGISTER YOUR BAGGS GUITAR https://www.lrbaggs.com/support/aeg-1-product-registration...
- Page 10 483 N. FRONTAGE RD. NIPOMO, CA 93444 LRBAGGS.COM...
