- Page 1 AIJGO-34 PERSONAL GROUNDING TESTER WITH DUAL FOOT ELECTRODE, RFID READER, LCD DISPLAY AND OPERATING SOFTWARE INSTRUCTION MANUAL www.dlb.hu sales@destsa.hu +36 27 502 555...
-
Page 2: Table Of Contents
TABLE OF CONTENTS About the product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Technical informations . -
Page 3: About The Product
ӹ For indoor use only The AIJGO-34 is a tester for checking personal grounding before entering an ESD protected area (EPA). It may be a good choice if you want to identify persons entering the site. Tester with LIGHT BAR system – such AIJGO products have a steel touch button, the measured results are indicated by LED lights. -
Page 4: Technical Informations
CE declaration We declare that the AIJGO-34 product complies with the requirements of IEC 61340- 5-1, ANSI/ESD S20.20 and Directive 2001/95/EC (General product safety). Warning The device can deliver an effective output power of up to 20 µA or less at a maximum voltage of 100 V for 2-4 seconds at 0,5 second cycles. -
Page 5: Order Codes
AIJGO-34 software, mounting plate and universal holder AIJGO-STA Stand for AIJGO tester PieManager management software for AIJGO-34 and AIJGO-34/COMP (if AIJGO-34/MSW buying more than one tester, it is sufficient and recommended to buy one if they will be networked together) -
Page 6: Shut Down Button
PARTS OF THE TESTER Steel touch button with 9 RGB LEDs Combined 4 mm banana plug and 10 mm snap socket for connecting wrist strap/ groundable ESD smock RFID reader LCD display Green 4 mm banana plug socket: calibration / verification test point USB 2.0 socket LAN socket Shut down button... -
Page 7: Rfid Reader
RFID reader The FF (Full Frequency) reader reads cards operating at both low (125/134 kHz) and high (13 .56 MHz) frequencies . It is compatible with the following types of cards, transmitters, and communication standards: Emarine (pl. EM4100,4102,4200), Casi Rusco, FDX Animal, HiTag1, HiTag2, Indala Type1, Indala Type2, Indala KSF (Kantech Secure Format), IoProx XSF (Kantech Extended Secure Format), ProxCard II, ProxCard II C1000, ProxCard II... -
Page 8: Items Supplied With The Tester
ITEMS SUPPLIED WITH THE TESTER Dual foot electrode with wire and relay connector In case of a tester version which is to be In case of a tester version which is to be mounted on wall/table/entrance gate mounted on stand Universal holder In case of a tester version which In case of a tester version which is to... -
Page 9: Packaging Dimensions And Weights Of The Product
PACKAGING DIMENSIONS AND WEIGHTS OF THE PRODUCT SIze of the package Weight of the package AIJGO-34 with stand - 1 . package 94 x 18 x 50 cm 15,3 kg AIJGO-34 without stand - 2 . package 21 x 51 x 43 cm 12,2 kg 1. -
Page 10: Assembly Instructions
ASSEMBLY INSTRUCTIONS Stand version Fix the tester with screws on the universal holder Connect the wires from the stand to the wires of the platform Place the stand on the platform and fix it with screws Connect the wires of the dual foot electrode and the relays, also the adapter to the tester –... - Page 11 Ask a qualified electrician to connect the gate to the EPH network of the building. For information on connecting the fire alarm wiring, see below. Remove the protecion foil from the foot electrode plates Connect the device to mains voltage The tester is ready to use...
-
Page 12: Wall Version
Wall version Screw the mounting plate to the wall Fix the tester to the universal holder with screws in the direction shown in the picture Connect the wires of the dual foot electrode and the relays using the 8-pin connector and also the adapter Connect the device to mains voltage Slide the tester with the holder onto the... - Page 13 The tester is ready to use Entrance gate or table top version Fix the tester to the universal holder with screws in the direction shown in the picture Connect the wires of the dual foot electrode and the relays using the 8-pin connector and also the adapter Remove the protecion foil from the foot electrode plates...
-
Page 14: Operation Instructions
OPERATION INSTRUCTIONS Step with both feet on the middle of the foot electrode plates When testing a wrist strap/groundable ESD smock system, connect the wrist strap/ groundable ESD smock to the tester socket Place the RFID card you wish to use onto the RFID reader, aligning it precisely with the section marked with the “RFID”... -
Page 15: Calibration / Verification Guide
CALIBRATION / VERIFICATION GUIDE Foot electrode calibration / verification Place a measuring electrode on the foot electrode you want to measure and connect it to a resistance decade Connect the calibration / verification test point of the tester to the resistance decade To calibrate / verificate, adjust the knobs on the resistance decade Read your RFID card at the RFID reader of the... - Page 16 Wrist strap / groundable ESD smock connection calibration / verification Connect the wrist strap/groundable ESD smock connection to a resistance decade Connect the calibration / verification test point of the tester to the resistance decade To calibrate / verificate, adjust the knobs on the resistance decade Read your RFID card at the RFID reader of the tester...
- Page 17 Table to evaluate the results Accepted maximum Accepted maximum Calibration / verification Lower limit Expected Upper limit deviation downwards deviation upwards parameters value value value from expected value from expected value Footwear system test - 20% 80 KΩ 100 KΩ 120 KΩ...
- Page 18 D és Tsa. Bt. 2600 Vác, Dr. Csányi László Krt. 83. Hungary Tel. / Fax: +36 27 502 555 +36 27 200 835 E-mail: sales@destsa.hu Web: www.destsa.hu www.dlb.hu...
