- Page 1 AIJGO-22LCD PERSONAL GROUNDING TESTER WITH LCD DISPLAY AND DUAL FOOT ELECTRODE INSTRUCTION MANUAL www.dlb.hu sales@destsa.hu +36 27 502 555...
-
Page 2: Table Of Contents
TABLE OF CONTENTS About the product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Technical informations . -
Page 3: About The Product
The tester is supplied with manufacturer’s calibration certificate, dual foot electrode, mounting plate and universal holder. CE declaration We declare that the AIJGO-22LCD product complies with the requirements of IEC 61340-5-1, ANSI/ESD S20.20 and Directive 2001/95/EC (General product safety). -
Page 4: Technical Informations
TECHNICAL INFORMATIONS Resistance values indicated as acceptable by the tester Default setting when measuring footwear system 100 KΩ – 35 MΩ An upper value of 100 MΩ can be set using the red switch at the bottom of the tester. However, after setting a different limit from the one used previously, the device must be restarted for the change to take effect. - Page 5 Mounting plate sizes Order codes Personal grounding tester with LCD display, dual foot electrode, mounting AIJGO-22LCD plate and universal holder AIJGO-STA Stand for AIJGO tester...
-
Page 6: Parts Of The Tester
PARTS OF THE TESTER Steel touch button with 9 RGB LEDs Combined 4 mm banana plug and 10 mm snap socket for connecting wrist strap/groundable ESD smock Switch for test type selection: if the upper position is selected, the footwear system and wrist strap/groundable ESD smock system are tested, if the lower position is selected, only the footwear system is tested... -
Page 7: Items Supplied With The Tester
ITEMS SUPPLIED WITH THE TESTER Dual foot electrode with wire and relay connector In case of a tester version which is to be In case of a tester version which is to be mounted on wall/table/entrance gate mounted on stand Universal holder In case of a tester version which is to be mounted In case of a tester version which is to be mounted on... -
Page 8: Assembly Instructions
ASSEMBLY INSTRUCTIONS Stand version Retool the red switch on the bottom of the tester to the desired position, if necessary, to set the measurement resistance limit of the footwear system. However, after setting a different limit from the one used previously, the device must be restarted for the change to take effect. - Page 9 Fix the tester with the universal holder on the stand Ask a qualified electrician to connect the gate to the EPH network of the building. For information on connecting the fire alarm wiring, see below. Connect the device to mains voltage The tester is ready to use...
- Page 10 Wall version Retool the red switch on the bottom of the tester to the desired position, if necessary, to set the measurement resistance limit of the footwear system. However, after setting a different limit from the one used previously, the device must be restarted for the change to take effect.
- Page 11 Connect the device to mains voltage The tester is ready to use...
- Page 12 Entrance gate or table top version Retool the red switch on the bottom of the tester to the desired position, if necessary, to set the measurement resistance limit of the footwear system. However, after setting a different limit from the one used previously, the device must be restarted for the change to take effect.
-
Page 13: Operation Instructions
OPERATION INSTRUCTIONS Step with both feet on the middle of the foot electrode plates When testing a wrist strap/groundable ESD smock system, connect the wrist strap/ groundable ESD smock to the tester socket Touch both halves of the steel touch button at the same time and keep your hand on it while testing is in progress You can read the result on the LCD display, the... -
Page 14: Calibration Instructions
CALIBRATION GUIDE Foot electrode calibration Place a measuring electrode on the foot electrode you want to measure and connect it to a resistance decade Connect the calibration test point of the tester to the resistance decade To calibrate, adjust the knobs on the resistance decade and start testing by touching both parts of the touch button simultaneously Wrist strap/groundable ESD smock connection calibration... - Page 15 To calibrate, adjust the knobs on the resistance decade and start testing by touching both parts of the touch button simultaneously Table to evaluate the results Accepted maximum Accepted maximum Calibration Lower limit Upper limit deviation downwards Expected value deviation upwards parameters value value...
