Summary of Contents for MettaX MC912
- Page 1 MettaX Digital (Shenzhen) Co., Ltd. Installation User Manual MC912 1 / 16...
-
Page 2: Table Of Contents
MettaX Digital (Shenzhen) Co., Ltd. Contents Introduction .............................3 1. Product Specifications ........................4 2. Definition of Accessories and Interfaces ..................7 2.1 Inspection of Products and Accessories ................7 2.2 Panel Introduction ........................8 2.3 Interface Definition ........................9 3. Installation Instructions ........................10 3.1 Hard Disk &... -
Page 3: Introduction
MettaX Digital (Shenzhen) Co., Ltd. Introduction The device is an intelligent terminal product that combines various advanced features such as GPS / BDS positioning monitoring, local SD card recording, 4G remote real-time video surveillance, IP-Camera, DMS / ADAS / BSD, and more. It seamlessly integrates real-time monitoring, production operation management, command dispatch, and other functionalities. -
Page 4: Product Specifications
MettaX Digital (Shenzhen) Co., Ltd. electronic products and the requirements of vehicles and other connected equipment. 3) The installation and construction shall comply with the specifications, which can refer to the relevant national or local standards. 4) Please check the connected power supply voltage, which should fall within the range of 9V - 36V. - Page 5 MettaX Digital (Shenzhen) Co., Ltd. & CPU DDR 2G Memory SATA HD(Max. 4T)*1, SD card(Max. 512G)*1 Video Input 12CH CVBS, 1.0Vp-p, 75 Ω 1CH VGA, 1CH CVBS, 1.0Vp-p, 75Ω, Support Full Screen and 4 / 9 Video Output Channels Segmentation...
- Page 6 MettaX Digital (Shenzhen) Co., Ltd. Alarm Output 2CH Output 2* USB Interface 3* RS232 Interface Communication Interface 1* RS485 Interface 1* 10M / 100M Adaptive Network Interface 1* Voice Intercom Interface Extension Interface Multi Function Control Panel can be Connected (Support 12V...
-
Page 7: Definition Of Accessories And Interfaces
MettaX Digital (Shenzhen) Co., Ltd. 360° 360-degree Panoramic View Adaptive Wide Power Input, with Overload, Under Voltage, Short Power Circuit, Reverse Connection and other Protection Functions, Support Management Timing on-off, Delay Shutdown Function Power Supply and Power Input Voltage DC: +9V ~ +36V... -
Page 8: Panel Introduction
MettaX Digital (Shenzhen) Co., Ltd. 30 Pin I/O Extension Cable 1pcs WIFI Antenna 1pcs 4G Antenna 1pcs BDS / GPS Antenna 1pcs 2pcs Remote Control 1pcs Mounting Screw 8pcs AV-IN (6-PIN) 6pcs AV-OUT (4-PIN) 1pcs 2.2 Panel Introduction 8 / 16... -
Page 9: Interface Definition
MettaX Digital (Shenzhen) Co., Ltd. Chart 1. Front Chart 2. Back 2.3 Interface Definition This paper mainly introduces the definition of power supply, I / O, audio and video interfaces, as follows: 1) Definition of Power Interface Chart 3. 2) I / O Interface Definitions... -
Page 10: Installation Instructions
MettaX Digital (Shenzhen) Co., Ltd. Chart 4. 3) Definition of Audio and Video Interface AV-IN 1~12 Camera Interface AV-OUT Display Interface 3. Installation Instructions 3.1 Hard Disk & SD Card & SIM Card To unlock and open the front panel cover, use the included key. The SIM card and SD card and hard disk interfaces are visible once they are opened, as illustrated in the diagram below. -
Page 11: Antenna Installation
MettaX Digital (Shenzhen) Co., Ltd. First, loosen the fixed screws located at both ends of the hard disk rack. Then, carefully pull out the hard dish box from the rack. After installing the hard disk into the box, securely fasten it with screws. -
Page 12: Adas / Dms Installation And Debugging
MettaX Digital (Shenzhen) Co., Ltd. smoking, playing with mobile phones, making phone calls and other non-standard driving, this function will alarm through voice and upload the alarm information. 3.5 ADAS / DMS Installation and Debugging 3.5.1 ADAS Installation 1) Installation Position: Take the center of the windshield as the axis, move up and down according to different vehicle types, and generally install at the lower point (Note: Do not affect the use of the wiper). -
Page 13: Power Connection
MettaX Digital (Shenzhen) Co., Ltd. the driver's face up and down in the middle of the entire video. B. Installation Position: Car Dashboard 1) Installation Angle: Ensure the camera is within 30 degrees to the right of the driver's direct line of sight. The smaller the angle, the better. -
Page 14: Product Firmware Upgrade
MettaX Digital (Shenzhen) Co., Ltd. The device can be embedded into the dashboard of the car through the sleeve, and it can also be fixed. Please pay attention to the following points during installation: 1) Waterproof: You should choose a location that is not suitable for water to ensure that... - Page 15 MettaX Digital (Shenzhen) Co., Ltd. Fast back key when playing back image file. Fast forward key when playing back video files. Play history video, Pause play and stop playing. PTZ, Delete button, delete characters when ZOOM- editing, color adjustment value drops.
- Page 16 MettaX Digital (Shenzhen) Co., Ltd. Switch panel (only work for full video recorder Model) Pause playing and frame playing button when playing back into video materials (Frame Playing: Playing a single picture, Pause / Step press this button once to play the next picture), press the play image key to return to the normal playing speed.
