- Page 1 Installation User Manual MC401...
-
Page 2: Table Of Contents
Content Introduction..........................3 1.System Overview.......................5 1.1 Product Overview...................5 1.2 Schematic diagram powered by standard power cable....5 2.Installation Preparation....................6 2.1 Installation Technical Requirements............6 2.2 Understanding the Installation Environment........6 2.3 Vehicle Condition and Related Electrical Information......6 2.4 Vehicle Power Connection..............6 3.Preparation for Installation Materials and Tools.............8 3.1 Package Inventory Check..............8 3.2 Installation Materials and Tools..............8 3.3 Preparing standard SIM Card and Micro SD Memory Card.....10... -
Page 3: Introduction
Introduction To guide engineers in the correct and efficient installation of MC401 and its accessories, and to improve installation efficiency, this MC401 Solution Installation Guide has been prepared. This document primarily includes: Preamble, System Overview, Installation Preparation, Installation Introduction, Acceptance, and Cleaning. This document is intended for installation engineers. - Page 4 8. During installation, the Mxtool application is required for debugging and configuring the MC401. 9. Scan the QR code below or search for and download the Mxtool application from the application store. Once downloaded, you can connect the application to the MC401 to configure the device's operational parameters. Android...
-
Page 5: System Overview
System Overview 1.1 Product Overview MC401 is an smart dash cam with built-in dual recording cameras. It helps drivers reduce traffic accidents and assists fleet management in improving efficiency. Based on artificial intelligence technology, it can proactively detect dangerous driving events and unsafe driving behaviors. -
Page 6: Installation Preparation
Installation Preparation 2.1 Installation Technical Requirements Relevant personnel should be familiar with the product's features, applications, and overall composition. Relevant personnel should have knowledge of vehicle circuits, structures, and commonly used installation methods for in-vehicle devices. 2.2 Understanding the Installation Environment Before equipment installation, relevant personnel should have a clear understanding of the vehicle model, installation position of the device, cable types and lengths required for different vehicle models, and the list of commonly used auxiliary materials. - Page 7 method of connecting the vehicle's power supply according to the product's power cable requirements. (1) Tools required: multi-meter. (2) Selection of Power Connection Location When the vehicle is parked and ignition is OFF, use a multi-meter to check if the circuit is powered.
-
Page 8: Preparation For Installation Materials And Tools
Preparation for Installation Materials and Tools 3.1 Package Inventory Check After unpacking the product, please ensure the device is intact and all accessories are included. 3.2 Installation Materials and Tools Before installation, the following installation accessories and tools shall be made available... - Page 9 Installation Materials and Tools List Image Name Uasage Quantity Tighten screws, optional 1pcs Common Screwdriver Kit Crowbar Pry up the vehicle panel 1pcs Ties Bundle cables As per needs 1pcs Cleaning Cloth Clean the dashboard Install the Mxtool App for video 1pcs Android Phone preview and parameter configuration...
-
Page 10: Preparing Standard Sim Card And Micro Sd Memory Card
Image Name Uasage Quantity Scissors Cut insulated rubber tape or wire clip 1pcs TF Card Reader For future use 1pcs Locate vehicle power supply Measure the conduction of harness 1pcs Multi-meter Measure pulse signal 1pcs 3M adhesive tape Fix DMS Camera 1pcs Three legged ladder Help to install the BSD camera... -
Page 11: Installation
Installation 4.1 Installing standard SIM Card and Memory Card Installing the standard SIM card and Micro SD card as shown in the following diagram (pay attention to the insertion direction of these cards). During installation, make sure it feels smooth and flexible. When pushing the card, you should hear a clear "click" sound, indicating that the card is correctly inserted. -
Page 12: Choice Of Installation Area For The Main Unit
Once the standard SIM card and Micro SD card are installed, remove the lens protective film from the front and rear lenses of the device, as shown in the diagram below. 4.2 Choice of Installation Area for the Main Unit The installation area requirements for MC401 are as follows:... - Page 13 (1) The device must be installed in the middle of the windshield. Typically, it is installed in the area above the center line of the windshield, in the vicinity of the rear-view mirror. If it is not possible to install the device in the middle as required, a deviation of less than 5 cm to the left or right is allowed (the deviation of the device relative to the center line of the windshield is calculated using the center line of the front lens).
-
Page 14: Installation Of The Main Unit
4.3 Installation of the main unit. 1. Park the vehicle on a level surface. 2. Clean the inside and outside of the target installation area on the windshield using an alcohol swab. Ensure that there is no dirt or debris on the glass that could obstruct the view of the road condition monitoring lens. - Page 15 The properly adjusted cabin monitoring camera rendering is shown below: d) MC401 supports two additional external remote cameras, please select the matching camera to install in the appropriate position according to the actual requirements. *Note: Only when the device is securely connected to the vehicle, can the device be powered on.
-
Page 16: Power Connection, Signal Cable, And Cable Connection
4.5 Power Connection, Signal Cable, and Cable Connection Connect the power/ACC/GND to the vehicle's power supply line. *Note: The power line should preferably be connected using "dedicated non-stripping connectors" (no need for stripping, to avoid the risk of electric leakage) and wrapped with insulating tape to prevent electric leakage/short circuit. -
Page 17: Device Configuration
Device configuration After the device is powered on, adjust it using the mobile app MXtool. Please refer to MXtool user manual for instruction. -
Page 18: Acceptance And Cleaning
Acceptance and Cleaning 6.1 Cleaning Clean up the installation site, collect and remove tools and waste materials. Return any original items to their original positions in the vehicle. The installation work is now complete. 6.2 Installation Acceptance Conduct acceptance based on the acceptance checklist provided by the customer, focusing on the installation details and parameter settings.
