Page 4
Seagate Technology LLC. Other product names are registered trademarks or trademarks of their owners. Seagate reserves the right to change, without notice, product offerings or specifications. No part of this publication may be reproduced in any form without written permission of Seagate Technology LLC.
Revision status summary sheet Revision Date Sheets Affected Rev. A 04/21/03 All. Rev. B 05/07/03 Pages 8, 34-36, 38, and 41-45 Rev. C 07/17/03 Pages 1, 4, 7, 12, and 13. Also new design and page size. Rev. D 09/02/03 Page 20.
Introduction ® This manual describes the functional, mechanical and interface specifications for the following Seagate ® Barracuda 7200.7 model drives: Barracuda 7200.7 Plus • ST3160023A • ST3120026A • ST380013A Barracuda 7200.7 • ST3160021A • ST3120022A • ST380011A • ST360014A • ST340014A These drives provide the following key features: •...
Drive specifications Unless otherwise noted, all specifications are measured under ambient conditions, at 25°C, and nominal power. For convenience, the phrases the drive and this drive are used throughout this manual to indicate ST3160021A, ST3160023A, ST3120022A, ST3120026A, ST380011A, ST380013A, ST360014A, and ST340014A model drives.
Page 14
ST3160021A ST3120022A ST380011A Drive specification ST3160023A ST3120026A ST380013A ST360014A ST340014A Average latency (msec) 4.16 Power-on to ready (sec typical) 10 sec Standby to ready (sec typical) 10 sec Startup current (typical) 12V (peak) 2.8 amps Track-to-track seek time (msec typical) <1.0 (read), <1.2 (write) Average seek time (msec typical) Average seek, read (msec typical)
Formatted capacity Formatted Guaranteed Model capacity sectors Bytes per sector ST3160021A 160 Gbytes 312,581,808 ST3160023A ST3120022A 120 Gbytes 234,441,648 ST3120026A ST380011A 80 Gbytes 156,301,488 ST380013A ST360014A 60 Gbytes 117,231,408 ST340014A 40 Gbytes 78,165,360 2.2.1 LBA mode When addressing these drives in LBA mode, all blocks (sectors) are consecutively numbered from 0 to n–1, where n is the number of guaranteed sectors as defined above.
Seek time Seek measurements are taken with nominal power at 25°C ambient temperature. All times are measured using drive diagnostics. The specifications in the table below are defined as follows: • Track-to-track seek time is an average of all possible single-track seeks in both directions. •...
2.9.1 Power consumption Power requirements for the drives are listed in the table on page 8. Typical power measurements are based on an average of drives tested, under nominal conditions, using 5.0V and 12.0V input voltage at 25°C ambient temperature. •...
Page 19
2.9.1.1 Typical current profile Amps +5 Volt Current during spindle start — Typical Amperes Seconds Figure 1. Typical 5V startup and operation current profile +12 Volt Current during spindle start — Typical Amperes Amps Seconds Figure 1. Typical 12V startup and operation current profile Barracuda 7200.7 Product Manual, Rev.
2.9.2 Conducted noise Input noise ripple is measured at the host system power supply across an equivalent 80-ohm resistive load on the +12 volt line or an equivalent 15-ohm resistive load on the +5 volt line. • Using 12-volt power, the drive is expected to operate with a maximum of 120 mV peak-to-peak square-wave injected noise at up to 10 MHz.
activity is required, the drive makes a transition to Standby mode. In both Idle and Standby mode, the drive accepts all commands and returns to Active mode when disc access is necessary. 2.10 Environmental specifications 2.10.1 Ambient temperature Ambient temperature is defined as the temperature of the environment immediately surrounding the drive. Actual drive case temperature should not exceed 69°C (156°F) within the operating ambient conditions.
2.10.5 Shock All shock specifications assume that the drive is mounted securely with the input shock applied at the drive mounting screws. Shock may be applied in the X, Y or Z axis. 2.10.5.1 Operating shock These drives comply with the performance levels specified in this document when subjected to a maximum operating shock of 63 Gs based on half-sine shock pulses of 2 msec.
Information Technology Equipment (ITE). Emission levels are defined by EN 55022, Class B and the immunity levels are defined by EN 55024. Seagate uses an independent laboratory to confirm compliance with the EC directives specified in the previous paragraph. Drives are tested in representative end-user systems. Although CE-marked Seagate drives comply with the directives when used in the test systems, we cannot guarantee that all systems will comply with the directives.
As a subassembly, no Federal Communications Commission verification or certification of the device is required. Seagate Technology LLC has tested this device in enclosures as described above to ensure that the total assembly (enclosure, disc drive, motherboard, power supply, etc.) does comply with the limits for a Class B computing device, pursuant to Subpart J, Part 15 of the FCC rules.
Configuring and mounting the drive This section contains the specifications and instructions for configuring and mounting the drive. Handling and static discharge precautions After unpacking, and before installation, the drive may be exposed to potential handling and electrostatic dis- charge (ESD) hazards. Observe the following standard handling and static-discharge precautions: Caution: •...
Breather filter hole precautions This section contains information regarding the precautions which should be taken regarding the breather filter hole in Seagate hard disc drives. Proper precautions should be taken to ensure full functionality and prevent possible damage to the drive.
Jumper settings 3.3.1 Master/slave configuration The options jumper block shown in Figure 1 is used to configure the drive for operation. It is the 8-pin dual header between the interface connector and the power connector. Use the following settings to configure the drive as a master or a slave.
Windows XP, Windows Me, Windows 98 or newer versions are needed to support drives with capacities greater than 32 Gbytes. 3.3.4 Ultra ATA/100 cable An 80-conductor 40-pin cable is required to run Ultra DMA mode 3, mode 4 and mode 5. This cable uses even- numbered conductors connected to the ground pins to improve signal integrity.
Page 31
Notes: 1. Dimensions are shown in inches (mm). 2 Dimensions per SFF-8301 specification. 0.228 0.178 2.23 (5.79) (4.27) (56.56) 1.028 max 2.83 (26.11) (71.80) 3 x 0.25 0.015 3.71 (6.35 0.037) (94.35) both sides 1.122 0.02 1.625 0.02 (28.5 0.51) (41.28 0.51) 1.638...
ATA interface These drives use the industry-standard ATA task file interface that supports 16-bit data transfers. It supports ATA programmed input/output (PIO) modes 0–4; multiword DMA modes 0–2, and Ultra DMA modes 0–5. The drive also supports the use of the IORDY signal to provide reliable high-speed data transfers. You can use a daisy-chain cable to connect two drives to a single AT host bus.
Page 34
Drive pin # Host pin # and signal description Signal name Reset – Hardware Reset Ground Ground Host Data Bus Bit 7 Host Data Bus Bit 8 Host Data Bus Bit 6 Host Data Bus Bit 9 Host Data Bus Bit 5 DD10 Host Data Bus Bit 10 Host Data Bus Bit 4...
4.1.1 Supported ATA commands The following table lists ATA-standard commands that the drive supports. For a detailed description of the ATA commands, refer to the Draft ATA-6 Standard. See “S.M.A.R.T. commands” on page 31 for details and sub- commands used in the S.M.A.R.T. implementation. Command name Command code (in hex) ATA-standard commands...
Page 36
Command name Command code (in hex) Write Sectors Extended ATA-standard power-management commands Check Power Mode or E5 Idle or E3 Idle Immediate or E1 Sleep or E6 Standby or E2 Standby Immediate or E0 ATA-standard security commands Security Set Password Security Unlock Security Erase Prepare Security Erase Unit...
4.1.2 Identify Device command The Identify Device command (command code EC ) transfers information about the drive to the host following power up. The data is organized as a single 512-byte block of data, whose contents are shown in the table on page 27.
Page 38
Word Description Value Number of current logical sectors per logical track xxxx 57–58 Current capacity in sectors xxxx Number of sectors transferred during a Read Multiple or Write Multiple xxxx command 60–61 Total number of user-addressable LBA sectors available ST3160021A =0FFFFFFFh* ST3160023A =0FFFFFFFh* (see Section 2.2 for related information) ST3120022A = 234,441,648...
Page 39
ST380011A = 156,301,488 ST380013A = 156,301,488 ST360014A = 117,231,408 ST340014A = 78,165,360 104–127 ATA-reserved 0000 Security status 0001 129–159 Seagate-reserved xxxx 160–254 ATA-reserved 0000 Integrity word xxA5 Note. Advanced Power Management (APM) and Automatic Acoustic Management (AAM) features are not supported Note.
Word 93 1 = 80-conductor cable detected, CBLID above V 0 = 40-conductor cable detected, CBLID below V 4.1.3 Set Features command This command controls the implementation of various features that the drive supports. When the drive receives this command, it sets BSY, checks the contents of the Features register, clears BSY and generates an inter- rupt.
) that elimi- nates unnecessary drive returns. The diagnostic software ships with all new drives and is also available at: http://seatools.seagate.com. This drive is shipped with S.M.A.R.T. features disabled. You must have a recent BIOS or software package that supports S.M.A.R.T. to enable this feature. The table below shows the S.M.A.R.T. command codes that the drive uses.
(1-800-SEAGATE) is the Seagate toll-free number (1-800-732-4283) to access our automated self-help and directory assistance for Seagate support services. Using a touch-tone phone, you can find ser- vice and support phone numbers, answers to commonly asked questions, troubleshooting tips and specifica- tions for disc drives 24 hours daily.
Seagate service center representative for warranty-related issues. Resellers or end users of drive products should contact their place of purchase or one of the Seagate warranty service cen- ters for assistance. Have your drive’s “ST” model number and serial number available.
European Support Services For presales and technical support in Europe, dial the toll-free number for your specific country. If your country is not listed here, dial our presales and technical support call center at +1-405-324-4714 from 8:00 . to 11:45 .
Page 46
Asia/Pacific Support Services For Asia/Pacific presales and technical support, dial the toll-free number for your specific country. The Asia/ Pacific toll-free numbers are available from 6:00 . to 10:45 . and 12:00 . to 6:00 . (Australian East- ern time) Monday through Friday, except as noted. If your country is not listed here, direct dial one of our tech- nical support locations.
Page 47
Index Data Defense 1 data-transfer rates 1 Numerics DC power 7 3D Defense System 1 density 6 Diagnostic Defense 1 diagnostic software 1 discs 5 acoustics 12 DiscWizard 19 Active mode 10 Disk Manager 19 adio frequency (RF) 13 dissipation 8 agency certification (regulatory) 14 Download Microcode 25 alternate capacity jumper 19...
