Full Boar FBPBB-041 Instruction Manual

Full Boar FBPBB-041 Instruction Manual

41.5cc petrol backpack blower
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
KNOW YOUR PRODUCT
41.5cc PETROL
BACKPACK BLOWER
• 325KM/H VARIABLE AIR SPEED
• 900M
/H MAX AIR VOLUME
3
• 2 STROKE FUEL MIX 50:1
INSTRUCTION MANUAL
WARNING: Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
0322

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FBPBB-041 and is the answer not in the manual?

Questions and answers

Related Manuals for Full Boar FBPBB-041

Summary of Contents for Full Boar FBPBB-041

  • Page 1 KNOW YOUR PRODUCT 41.5cc PETROL BACKPACK BLOWER • 325KM/H VARIABLE AIR SPEED • 900M /H MAX AIR VOLUME • 2 STROKE FUEL MIX 50:1 INSTRUCTION MANUAL WARNING: Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference.

  • Page 2: Specifications

    SPECIFICATIONS - MODEL NO. FBPBB-041 Engine: 41.5cc, 2-stroke Spark plug: NGK BPMR7A Exhaust spark arrestor: Yes Power output: 1.5kw (2HP) Hand-arm system vibration total: Max. air speed: 325km/h Ah: 3.5 m/s Max. air volume: 900m3/h K: 1.5 m/s WOT speed: 7,000±500r/min Sound pressure level at the Max.
  • Page 3 KNOW YOUR PRODUCT (cont.)

  • Page 4: Table Of Contents

    TABLE OF CONTENTS SPECIFICATIONS............Page 02 KNOW YOUR PRODUCT.......... Page 02 INTRODUCTION............Page 05 SAFETY INSTRUCTIONS........Page 05 ASSEMBLY..............Page 09 SET-UP & PREPARATION........Page 11 OPERATION..............Page 15 MAINTENANCE............Page 18 TROUBLESHOOTING..........Page 21 DESCRIPTION OF SYMBOLS........ Page 22 CONTENTS..............

  • Page 5: Introduction

    INTRODUCTION Congratulations on purchasing a Full Boar Petrol Backpack Blower. Your Full Boar Petrol Backpack Blower FBPBB-041 features high speed air flow that is ideal for clearing fallen leaves, grass clippings, hedge cuttings and other heavy garden debris swiftly and effectively from large areas of the garden and outdoor areas.
  • Page 6 SAFETY INSTRUCTIONS (cont). RISK TO BREATHING What can happen: • Breathing exhaust fumes can cause serious injury or death. How to prevent it: • Operate tool or machine in a well ventilated area. Avoid enclosed areas. • Never operate unit in a location occupied by other people or animals. SAVE THESE INSTRUCTIONS 1) Work area a) Keep work area clean and well lit.
  • Page 7 SAFETY INSTRUCTIONS (cont). c) Turn tool or machine off completely before making any adjustments, changing accessories, or storing petrol tool and machines. Such preventive safety measures reduce the risk of starting the petrol tool or machine accidentally. Hair can be caught in moving parts.
  • Page 8 BACKPACK BLOWER SAFETY INSTRUCTIONS WARNING! This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

  • Page 9: Assembly

    ASSEMBLY Raised guide WARNING! Ensure the engine is off and is cool. Disconnect spark plug to prevent accidental starting. WARNING! Do not use any attachments or accessories not recommended by the manufacturer of this product, as it can result in serious personal injury.
  • Page 10 ASSEMBLY (cont). 5. Connect the intermediate pipe (19) onto the end of the control pipe (16) making sure the recess aligns with the two tabs, one either side of the pipe (fig. 4). Note: Make sure the screw in the pipe is moved out of the way so it does not obstruct during assembly.

  • Page 11: Set-Up & Preparation

    SET-UP & PREPARATION Engine fuel: mix at 50:1 only WARNING! Petrol is very flammable. Do not smoke or cause any sparks or flames near fuel. Make sure that you stop the engine and allow it to cool before refuelling the backpack blower. Select an open outdoor area for fuelling and move at least 3 metres away from the fuelling point before starting the engine.

  • Page 12: Pre-Startup Checks

    SET-UP & PREPARATION (cont.) Pre-startup checks 1. Ensure that all the pipes and direction nozzle are fitted and the control handle is secured tightly in the correct position. 2. Ensure that there is sufficient fuel/oil mix in the tank before starting the engine.

  • Page 13: Warm Starting

    SET-UP & PREPARATION (cont.) 4. Hold the backpack blower securely on the ground and pull out the recoil starter (8) until you feel it start to resist. Then sharply pull recoil starter (8) several times (3 to 6 times) until the engine starts or attempts to start and stops (fig.

  • Page 14: Stopping The Engine

    SET-UP & PREPARATION (cont.) Stopping the engine 1. Allow the engine to slow by setting the cruise control lever (18) to the slow position (fig. 15). Fig. 15 2. Set the ignition switch (7) to STOP (fig. 16). STOP STOP START STOP Fig.

  • Page 15: Operation

    OPERATION Adjusting the speed The backpack blower has 2 speed adjustments, the throttle trigger (6) allows fast speed changes whereas the cruise control lever (18) will maintain a speed once set. – Throttle trigger (fig. 17) 1. To increase the speed (blowing power) of the backpack blower, squeeze the throttle trigger (6).

  • Page 16: Shoulder Harness

    OPERATION (cont.) Shoulder harness 1. Connect the clip at the end of each shoulder strap onto the connection points located on each side of the backpack blower (fig. 19). Note: Ensure each shoulder strap is not tangled or crossing over. 2.
  • Page 17 OPERATION (cont.) Blowing WARNING! Do not use the backpack blower with any type of accessory or attachment not recommended by the manufacture. Such usage might be hazardous. WARNING! Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.

  • Page 18: Maintenance

    MAINTENANCE WARNING! Before cleaning your backpack blower or carrying out any maintenance procedure, make sure that the engine is off and is cool. Disconnect the spark plug to prevent accidental starting. WARNING! Before each use, inspect the entire product for damaged, missing or loose parts, such as screws, nuts, bolts, caps, etc.

  • Page 19: Spark Plug

    MAINTENANCE (cont.) Spark plug When the backpack blower will not start and everything has been checked, it is likely the spark plug will need replacing. The spark plug is not covered under warranty. To replace the spark plug: 1. Pull off the spark plug lead (3). 2.
  • Page 20 MAINTENANCE (cont.) Storage If the backpack blower will be stored for 30 days or longer, the fuel tank has to be drained. This should be done outdoors and when the engine is cool. In order to avoid deposits forming on the interior of the carburettor, follow these instructions: 1.

  • Page 21: Troubleshooting

    TROUBLESHOOTING FAULT POSSIBLE CAUSES SOLUTION The machine The cruise control lever Adjust the cruise control lever will not slow (18) is set to maintain a to a lower setting. high speed. down Correct starting procedure Follow the instructions The machine does not not followed.

  • Page 22: Description Of Symbols

    DESCRIPTION OF SYMBOLS Milliliter Horsepower Wide-open throttle m³/h Cubic metres per hour km/h Kilometres per hour Kilowatt Cubic Centimeters (the standard measure of displacement in Europe and Asia) Revolutions or reciprocation per minute r/min Read the manual prior to use Decibel level Regulatory Compliance Mark (RCM) Wear safety eye protection...

  • Page 23: Contents

    CONTENTS x Petrol backpack blower 1 x Flexible pipe 1 x Control pipe 1 x Intermediate pipe 1 x Direction nozzle 1 x 2-Stroke fuel mixing bottle 1 x Multi-tool 1 x Instruction manual Note: The manufacturer’s liability shall be deemed void if the machine is modified in any way and the manufacturer shall therefore accept no liability for any damages arising as a result of modifications.

  • Page 24: Warranty

    WARRANTY YOUR WARRANTY FORM SHOULD BE RETAINED BY YOU AT ALL TIMES. IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU MUST RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS WAREHOUSE (see www.bunnings.com.au or www.bunnings.co.nz for store locations) WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO RETURNING YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE OUR CUSTOMER SERVICE HELPLINE: Australia 1800 951 371 New Zealand 0800 647 840...
