RAB Design NS2H Installation Instructions

NS2H – SENSOR ACTIVATED FLOOD LIGHT
INSTALLATION INSTRUCTIONS
READ, UNDERSTAND
ELECTRICAL SHOCK HAZARD
.
installing the equipment
WARNING
Disconnect the Electrical supply power at the service panel (fuse or circuit breaker box) prior to installa�on. Failure to do so could result in serious injury or
death. Only qualified electricians should install this fixture and the installa�on MUST conform to the Canadian Electrical Code Part I and all local codes and
ordinances. Ensure that only proper tools, materials, and equipment are used to complete the installa�on.
SAFETY
•
Proper grounding is required to ensure personal safety.
•
Fixture should be mounted in loca�ons where unauthorized personnel will not readily subject it to tampering.
•
Do not use this equipment for anything other than its intended purpose.
•
Servicing this equipment should be performed by qualified service personnel.
•
Save these instruc�ons.
•
MIN 75 °C SUPPLY CONDUCTOR
INCLUDED IN THE BOX TOOLS REQUIRED
• Light fixture with twin light heads
• Wall gasket
• Metal Moun�ng bracket
•
Screws and Wire nuts
INSTALLATION
1. Remove exis�ng light fixture as well as any exis�ng metal moun�ng bracket
(if any). [Fig. 1]
**NS2H is designed to be installed on a standard round junc�on box. If there is no exis�ng
junc�on box, please hire a licensed electrician to install one.
Rubber Plug
Center Moun�ng Screw
2. Remove the center rubber plug and unscrew the Center moun�ng screw to
remove the moun�ng bracket. [Fig. 1]
3. Secure the moun�ng bracket to the junc�on box with provided screws (2).
[Fig. 2]
4. A�ach the Wall Gasket to the back of the fixture. Use the provided Aircra�
support cable to hang the fixture from the moun�ng bracket. [Fig. 3]
RAB Design Ligh�ng inc. August – 2023
NS2H – SENSOR ACTIVATED FLOOD LIGHT
INSTALLATION INSTRUCTIONS
5. Wiring Connec�on: Use provided wire nut to connect the fixture wires to
FOLLOW the supply wires following local building code and the wiring diagram
, and these instruc�ons before
[Fig. 4] [Fig. 5]
Refer to your local electrical code for approved grounding method if exis�ng
house supply wire does not include ground wire.
•
Check that the line voltage is correct.
•
Connect fixture GROUND (green) wire to power supply GROUND (green) wire.
• Connect fixture WHITE wire to power supply NEUTRAL wire.
• Connect fixture BLACK wire to power supply LINE wire.
• #2 Philips Screwdriver 6. Align the light fixture and wall gasket over the junc�on box and �ghten the center
moun�ng screw.
7. Please inspect to ensure all the gap between fixture and junc�on box is sealed
Moun�ng bracket
by the wall gasket. Apply silicone caulking (not included) to seal any gap between
the light fixture and the moun�ng surface.
8.
Aim twin-head lights to desired loca�on and adjust sensor se�ngs.
CONTROLS
Refer to [Fig. 6]
• BRIGHTNESS: Changes the brightness of the twin head lights
o
[ 1]
Fig.
o
Standard Junc�on Box
o
(not provided)
• PHOTOCELL: Changes photocell sensi�vity
o
o
Moun�ng bracket
• TIME: Controls how long twin head lights remain on since last mo�on detec�on
[ 2]
Fig.
o
o
o
• MOTION: Changes PIR sensor sensi�vity
o
o
o
• COLOUR: Changes the colour of the twin head lights
o
o
o
Aircra� Cable
Support
Wall gasket
[ 3]
Fig.
Page 1 of 6 RAB Design Ligh�ng inc.
Green:
White:ACN
Black:ACL
[ 4]
Fig.
Daylight sensor
(Photocell)
Le�: Accent light will turn OFF. If mo�on is detected, twin head will
turn ON at Highest light level.
Middle: Accent light turns ON based on daylight sensor. Twin Head will
turn ON at Low light level if mo�on is detected.
Right: Accent light turns ON based on daylight sensor. Twin Head will
turn ON at High light level if mo�on is detected.
Le�: Lowest sensi�vity – this se�ng is applicable to turn on light at
day�me
Right: Highest sensi�vity to turn on light at very dark condi�on
Le�, TEST: Light turns off in 5 seconds if no mo�on is detected.
Middle, 1M: Light turns off in 1 minute if no mo�on is detected.
Right, 5m: Light turns off in 5 minutes if no mo�on is detected.
Le�-most: Turns OFF mo�on sensor (Manual Override). Twin head will
be controlled by photocell only.
Refer to Fig.6 for
Le�: Mo�on sensor is ON with low sensi�vity
Right: Mo�on sensor is ON with high sensi�vity
recommended settings.
Le�: Warm (3000K)
Middle: Cool (4000K)
Right: Daylight (5000K)
August – 2023
NS2H – SENSOR ACTIVATED FLOOD LIGHT
INSTALLATION INSTRUCTIONS
TROUBLESHOOTING
LIGHT WILL NOT TURN ON
•
Fixture not receiving power. If the fixture is wired to a switch, ensure it is turned on.
•
Incorrect wiring. Verify that the wires are connected properly using the diagram [Fig. 4].
•
Breaker/fuse. Ensure the fixture has not caused a blown fuse or triggered the breaker. Change the fuse or reset breaker if necessary.
•
Photocell ac�vated. If there is low ambient light but the fixture is not on, reduce the photocell sensi�vity using the PHOTOCELL dial.
•
Mo�on not detected. If the fixture does not turn on while moving in front of it, increase the sensi�vity using the MOTION dial.
LIGHT TURNS ON RANDOMLY AND/OR WILL NOT TURN OFF
•
Photocell ac�vated. If the fixture is s�ll ON in the bright ambient light, increase the photocell sensi�vity using the PHOTOCELL dial.
•
Mo�on detected. If the fixture will not turn off even if nothing is moving in front of it, it may be detec�ng minor mo�on, try
decreasing the sensi�vity using the MOTION dial.
LIGHT IS FLASHING
• Photocell ac�vated. Lights from fixture may be reflec�ng off a surface or other sources which is triggering the photocell. Try
reposi�oning the twin heads and/or decrease the photocell sensi�vity using the PHOTOCELL dial.
[ 5]
•
Fig. Sensor ac�vated. Heat from the twin head-lights or other sources may be triggering the PIR sensor. Decrease the sensi�vity using the
MOTION dial.
[ 6]
Fig.
Page 2 of 6 RAB Design Ligh�ng inc. August – 2023 Page 3 of 6
