OPERATING MANUAL

AIR CONDITIONER

Wall Mounted Type

□ ASTG30KMTC

□ ASTG34KMTC

MODEL:

* Please check the model name.

(Refer to the rating label.)

R32

REFRIGERANT

This Air Conditioner contains and

operates with refrigerant R32.

THIS PRODUCT MUST ONLY BE INSTALLED OR SERVICED

BY QUALIFIED PERSONNEL.

Refer to Commonwealth, State, Territory and local legislation,

regulations, codes, installation & operation manuals, before

the installation, maintenance or service of this product.

PART No. 9387081237-02

9387081237-02_OM_En_200710.indd

Before using this product, read these instructions

thoroughly. Also, keep this manual for future

reference, together with the installation manuals for

the indoor and outdoor units.

2020/07/10

16:02:51

Table of Contents

Need help?

Do you have a question about the ASTG34KMTC and is the answer not in the manual?

Questions and answers

Summary of Contents for Fujitsu ASTG34KMTC

Page 1 OPERATING MANUAL AIR CONDITIONER Wall Mounted Type □ ASTG30KMTC □ ASTG34KMTC MODEL: * Please check the model name. (Refer to the rating label.) REFRIGERANT Before using this product, read these instructions This Air Conditioner contains and operates with refrigerant R32.
Page 2: Table Of Contents
Contents CAUTION This symbol shows that the operating manual should 1. SAFETY PRECAUTIONS .......... 1 be read carefully. 2. PREPARATION ............2 CAUTION 3. NAME OF PARTS ............. 3 This symbol shows that a service personnel should be handling this equipment with reference to the 3.1.
Page 3: Preparation
2. PREPARATION WARNING • This product is not intended for use by persons (including children) with reduced physical, sensory or mental WARNING capabilities, or lack of experience and knowledge, • Take care to prevent infants and young children from unless they have been given supervision or instruction accidentally swallowing the batteries.
Page 4: Name Of Parts
3. NAME OF PARTS 3.2. Remote controller When you use the optional remote controller, the appearance CAUTION and the operation procedure may differ. For details, please refer to the operating manual of each remote For appropriate signal transmission between the remote controller.
Page 5 CAUTION • To prevent malfunction or damage of the remote controller: - Place remote controller at where will not be exposed to direct sunlight or excessive heat. - Remove batteries if the product is not going to be For Powerful operation ....Refer to page 8. used for an extended period.
Page 6: Basic Operations
■ Airflow direction range 4. BASIC OPERATIONS Vertical airflow direction ■ 3 steps to start operation 1 ⇄ 2 ⇄ 3 ⇄ 4 ⇄ 5 ⇄ 6 Change by 1. Press to start or stop the operation. Swing operation by 2.
Page 7: Weekly Timer
■ Examples of Weekly timer 6.1. Weekly timer Example 1 ■ Setting details 7:00 9:00 11:00 17:00 23:00 1. Select Weekly timer in step 2 of "Timer setting procedure". Monday Program Program Program Program 2. Press to select the program number and the day of the week.
Page 8: Energy Saving Operations
Detection range of Human sensor 7. ENERGY SAVING OPERATIONS Side view Top view 7.1. Economy operation It saves more electricity than other operation modes by changing the set 90° temperature to a moderate setting. 50° 50° Press to activate/deactivate the Economy operation.
Page 9: Other Operations
(2) Is the air conditioner under the Demand controlling? Contact your electricity supplier. 9. SETTINGS ON INSTALLATION No • Contact Fujitsu General (AUST.) PTY LIMITED. (Refer to your warranty card.) 9.1. Remote controller custom code setting • Visit our website (www.fujitsugeneral.com.au).
Page 10: Cleaning And Care
10. CLEANING AND CARE Cleaning intake grille ■ Removing intake grille CAUTION 1. Open the intake grille. • Before cleaning this product, be sure to turn it off and 2. While pressing the left and right mounting shafts outward disconnect all the power supply. gently, pull the intake grille.
Page 11 2. Remove the air filters. 9. Install the air cleaning filter holders to the air filters. Lift up the air filters' handle, disconnect the two lower tabs, and pull Engage the 2 hooks at the rear of the air cleaning filter holder with out.
Page 12: General Information
11. GENERAL INFORMATION 12. OPTIONAL PARTS ■ Heating performance 12.1. Wired remote controller This air conditioner operates on the heat-pump principle, absorbing heat from air outdoors and transferring that heat to the indoor unit. As a The optional wired remote controller can be used. result, the operating performance is reduced as outdoor air temperature drops.
Page 13: Troubleshooting
13. TROUBLESHOOTING Airflow is weak or stops. □ Is the fan speed set to Quiet? ⇒ To change the fan speed, refer to page 5. WARNING □ Has the Fan Control for Energy Saving set? In this case, the indoor unit fan may stop temporarily while the Cooling operation. In the following events, immediately stop operation of ⇒...
Page 14 ■ State of indicator lamps Lighting pattern: Off, Blinking, Any state State Causes and solutions page Automatic defrosting operation ⇒ Please wait until finishing the defrosting (maximum of 15 minutes). Filter indicator ⇒ Clean the air filter and reset the filter sign.
Page 15 9387081237-02_OM_En_200710.indd 2020/07/10 16:03:01...
Page 16 9387081237-02_OM_En_200710.indd 2020/07/10 16:03:01...

This manual is also suitable for:

Astg30kmtc Astg30kmtd
