L6TDR622K
USER
MANUAL
EN
User Manual
Washing Machine

Advertisement

loading
Need help?

Need help?

Do you have a question about the L6TDR622K and is the answer not in the manual?

Questions and answers

Related Manuals for AEG L6TDR622K

Summary of Contents for AEG L6TDR622K

  • Page 1 L6TDR622K User Manual Washing Machine USER MANUAL...

  • Page 2: Table Of Contents

    17. ENVIRONMENTAL CONCERNS..............33 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.

  • Page 3: Safety Information

    ENGLISH SAFETY INFORMATION Before beginning the installation and use of this appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.

  • Page 4: Safety Instructions

    This appliance is designed for single household • domestic use in an indoor environment. This appliance may be used in, offices, hotel guest • rooms, bed & breakfast guest rooms, farm guest houses and other similar accommodation where such use does not exceed (average) domestic usage levels.

  • Page 5: Electrical Connection

    ENGLISH the drum to prevent an internal cable. Should the mains cable need to damage. be replaced, this must be carried out • Always take care when moving the by our Authorised Service Centre. appliance as it is heavy. Always use •...

  • Page 6: Product Description

    • Do not wash fabrics which are heavily such as detergent dispensers. Please soiled with oil, grease or other greasy note that some of these spare parts substances. It can damage rubber are only available to professional parts of the washing machine.

  • Page 7: Appliance Overview

    ENGLISH 3.2 Appliance overview 10 11 Control panel Drain hose Mains cable Lid handle Transit bolts Drain pump filter Hose support Lever to move the appliance Rating plate Feet for levelling the appliance Inlet hose Information for register product. The rating plate reports the model name The info label reports the model name (A), (A) , product number (B), electrical product number (B ) and serial number (C).

  • Page 8: Technical Data

    4. TECHNICAL DATA Dimension Width/ Height/ Total depth 39,7 cm /90,3 cm /59,9 cm Electrical connection Voltage 230 V Overall power 2200 W Fuse 10 A Frequency 50 Hz Level of protection against ingress of solid particles and IPX4 moisture ensured by the protective cover, except where the low voltage equipment has no protection against mois‐...

  • Page 9: The Inlet Hose

    ENGLISH We recommend that you keep the packaging and the transit bolts for any transport of the appliance. Adjust the appliance correctly to prevent vibration, noise and movement of the appliance when it operates. WARNING! Do not put cardboard, wood or equivalent materials below the appliance feet to adjust the level.

  • Page 10: Water Drainage

    5.3 Water drainage min.600 mm max.1000 mm The drain hose should stay at a height of no less than 600 mm and not more than 1000 mm. You can extend the drain hose to maximum 4000 mm. Contact the authorised service centre for the other drain hose and the extension.

  • Page 11: Control Panel

    ENGLISH through failure to comply with the above safety precaution. 6. CONTROL PANEL 6.1 Control panel description Marche/Arrêt touch button Option touch button • Taches option Programme dial • Prélavage option Display T/min. reduction touch button Départ Différé touch button Temp.

  • Page 12: Programme Chart

    The digital indicator can show: • Programme duration (e. g. • Delay time (e. g. • Cycle end ( ). • Warning code ( • Indication of total operating hours of the appliance. Refer to the 'Operating hours counter' section in the 'Settings' paragraph for more details.
  • Page 13 ENGLISH Pro‐ Default Refer‐ Programme description gramme temper‐ ence im‐ ature spin Tem‐ speed load pera‐ Spin ture speed range range Machine washable wool, hand washable 40 °C 1200 rpm wool and other fabrics with «hand washing» 40 °C - 1200-800 1 kg Laine/Soie...
  • Page 14 Pro‐ Default Refer‐ Programme description gramme temper‐ ence im‐ ature spin Tem‐ speed load pera‐ Spin ture speed range range Cotton and synthetic items lightly soiled or 30 °C 1200 rpm once worn. 40 °C - 1200-800 3 kg 20 min.
  • Page 15 ENGLISH OPTIONS ■ ■ ■ ■ ■ ■ ■ Gain de Temps ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ Rinçage Plus 1) This option is not available with temperature lower than 40 °C. 2) If you set the shortest duration, we recommend that you decrease the load size. It is possible to fully load the appliance, however the washing results can be less satisfactory.

  • Page 16: Options

    Universal Liquid Uni‐ Liquid for Delicates Programme Special versal coloureds woollens powder ▲ ▲ 20 min. - 3 kg 1) At temperature higher than 60 °C the use of powder detergent is recommended. ▲ = Recommended -- = Not recommended 7.1 Woolmark Wool Care - Blue...

  • Page 17: Gain De Temps

    ENGLISH be added in the appropriate phase of The indicator = cold water of the set the washing programme. temperature comes on (the appliance does not heat the water). This option can increase the programme duration. 8.4 T/min. This option is not available with a When you set a programme, the temperature lower than...

  • Page 18: Settings

    9. SETTINGS 9.1 Acoustic signals 1. Switch the appliance on by pressing Marche/Arrêt button. To deactivate the acoustic signals when 2. Turn the programme knob to the Eco the programme is completed touch the 40-60 programme (1st position Départ Différé and the Gain de Temps clockwise).

  • Page 19: Before First Use

    ENGLISH 10. BEFORE FIRST USE 2. Open the water tap. During installation or before 3. Put 2 litre of water in the detergent first use you may observe compartment for washing phase. some water in the appliance. This activates the drain system. This is residual water left in 4.

  • Page 20: Activating The Appliance

    Detergent compartment for prewash phase. When you set a programme with a stain, add detergent (powder or liquid). Detergent compartment for washing phase. Compartment for liquid additives (fabric conditioner, starch). The mark is the maximum level for the quantity liquid additives.

  • Page 21: Interrupting A Programme And Changing A Option

    ENGLISH 3. Touch the Départ/Pause button again If the ProSense phase is to start the new countdown. already carried out and the water filling is already 11.6 Starting a programme started, the new programme starts without repeating the Touch the Départ/Pause button to start ProSense phase.

  • Page 22: Draining Water Out After End Of Cycle

    11.14 Draining water out after To open the lid proceed as follows: end of cycle 1. Press the button Marche/Arrêt for some seconds to deactivate the The washing programme is appliance. completed, but there is water in the 2. Wait for some minutes and then open drum: carefully the lid.

  • Page 23: Hints And Tips

    ENGLISH 12. HINTS AND TIPS WARNING! Refer to Safety chapters. 12.1 The laundry load • Divide the laundry into: white, coloured, synthetics, delicates and wool. • Follow the washing instructions on the • Empty pockets and unfold the items. laundry care labels. •...

  • Page 24: Ecological Hints

    • The choice and quantity of detergent save detergent, water and time (the will depend on: type of fabric environment is protected too!). (delicates, woollens, cottons, etc), the • Loading the appliance to the colour of clothes, size of the load,...

  • Page 25: Removing Foreign Objects

    ENGLISH 13.4 Descaling Clean drum Every two months If the water hardness in your Clean detergent dis‐ Every two months area is high or moderate, we recommend that you use a penser water descaling product for Clean drain pump Twice a year washing machines.

  • Page 26: Cleaning The Detergent Dispenser

    Always obey the instructions seal surface. that you find on the packaging of the product. 13.8 Cleaning the detergent dispenser 13.9 Cleaning the drain filter WARNING! • Disconnect the mains Regularly check the drain pump filter and plug from the mains make sure that it is clean.

  • Page 27: Emergency Drain

    ENGLISH 13.10 Cleaning the inlet hose and the valve filter 13.11 Emergency drain 1. Disconnect the mains plug from the mains socket. If the appliance cannot drain the water, 2. Close the water tap. carry out the same procedure, described 3.
  • Page 28 14.1 Alarm Codes and Possible failures The appliance does not start or it stops during operation. First try to find a solution to the problem (refer to the tables). WARNING! Deactivate the appliance before carrying out any check. With some problems, the display shows an alarm code and the Départ/Pause button may flash continuously:...
  • Page 29 ENGLISH Problem Possible solution • Make sure that the mains plug is connected to the mains socket. • Make sure that the appliance lid and drum door are closed. • Make sure that there is no damaged fuse in the fuse box. The programme does •...

  • Page 30: Consumption Values

    Problem Possible solution Too much foam in the • Reduce the quantity of detergent. drum during the wash‐ ing cycle. After the check, activate the appliance. The programme continues from the point of interruption. If the problem occurs again, contact the Authorised Service Centre.
  • Page 31 ENGLISH 15.3 According to Commission Regulation Eu 2019/2023 Eco 40-60 pro‐ Litres h:mm °C gramme Full load 0.940 3:17 1151 Half load 0.518 2:35 1151 Quarter load 0.260 2:35 1151 1) Maximum spin speed. Power consumption in different modes Off (W) Stand-by (W) Delay start (W) 0.48...

  • Page 32: Quick Guide

    16. QUICK GUIDE 16.1 Daily use Connect the mains plug to the mains 2. Set the desired options (1) by means socket. of the corresponding touch buttons. To start the programme, touch the Open the water tap. Départ/Pause (2) button.

  • Page 33: Environmental Concerns

    ENGLISH Programmes Load Product description 3 kg Synthetic items or mixed fabric items. Synthétiques 3 kg Synthetic items requiring a gentle wash. Repassage Facile Delicate fabrics such as acrylics, viscose, poly‐ 2 kg Délicats ester items. Machine washable wool, hand washable wool 1 kg Laine/Soie and delicates.
