- Page 1 WINE & BEVERAGE CELLAR MODEL NUMBER SERIES FWCDR6635-32S INSTRUCTION MANUAL & INSTALLATION GUIDE Read these instructions carefully before using your appliance, and keep it carefully. If you follow the instructions, your appliance will provide you with many years of good service.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Customer Care Warning Important Safety Product Dimension Cutout Names of Parts and Accessories Installations: • Anti-tip Bracket ..............• Handle ................Operating Instruction • Adjusting the Zones Settings ........... • Adjusting the Temperature Setting........Care and Maintenance •... - Page 4 WINE & BEVERAGE CELLAR FELT RIGHT LOWER MODEL NUMBER SERIES FWCDR6635-32S...
-
Page 5: Customer Care
A customer service representative will contact you as soon as possible. All warranty work needs to be authorized by FORNO customer service. All our authorized service providers are carefully selected and rigorously trained by us. -
Page 6: Warning
WARNING FOR YOUR SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. -
Page 7: Important Safety
Important Safety Instructions • The appliance is intended to be used exclusively for storage of wine and beverage. • Make sure the voltage/current marked on the rating label corresponds with your supply voltage. Plug into a grounded 3-pin outlet, do not remove grounding pin, do not use an adapter, and do not use an extension cord. •... -
Page 8: Moving The Appliance
Important Safety Instructions MOVING THE APPLIANCE Turn off the wine cooler and unplug from the outlet. Securely tape down all loose items inside. Close the door. Do not lift, pull the door or door handle during transportation. 5. When moving, the appliance can not be tilted over 45 degrees as possible damage to the sealed system could occur. - Page 9 Important Safety Instructions The power cord should be secured behind the appliance and not left exposed or dangling to prevent accidental injury. Never unplug the appliance by pulling the power cord. Always grip the plug firmly and pull straight out from the receptacle.
-
Page 10: Product Dimension
Product Dimension FELT RIGHT LOWER Overall Width Overall Height Height Overall Depth Depth Hing to foot Hing to foot Handle to Handle to back (on maximum) (on minimum ) complete back 31 23/64” 5/8” 29 49/64” 21/32” 3/16” 5/64” 79.65cm 1.6cm 197.25cm 193.5cm... - Page 11 Product Dimension Total of 120 Bottles ° ° ° ° Total of 148 cans 1 layer 71 cans 2 layer 77 cans Total of 80 cans 1 layer 45 cans 2 layer 35 cans To ensure proper storage, kindly follow the example provided below for placing your bottle.
-
Page 12: Cutout
Cutout 78 5/64” 27 3/4” 11/16” 198.3cm 80.5cm 70.5cm... -
Page 13: Names Of Parts And Accessories
Names of Parts and Accessories Numbers Parts FELT RIGHT LOWER Control Panel Storage shelf Door hing Glass Doors Handles Drawer Adjustable feet Bottom Grill Supplied Parts 2x Anti-tip bracket with hardware 2x Expansion bolt 1x Hexagon wrench 4x Handle Logo 2x Screws for the handle... -
Page 14: Installations
Installations Before installing your cellar, you must do the following: • Unpack both the exterior and interior layers of packaging. Verify the presence of all components listed in the parts inventory, including shelves and instructional materials. Should any elements, such as shelf fragments or support structures, become dislodged during transit, refer to the instruction manual for precise guidance on proper installation. -
Page 15: Handle
Installations (continued) 3. (A) Next insert the expansion bolt into the drilled hole. Make sure it is flush to the floor. (B) Unscrew the nut, washer and lock ring from the screw. 4. Next, align the bracket hole with the screw and reattach the washer and lock ring. Finally, tighten the nut with a wrench or socket to the maximum. -
Page 16: Operating Instruction
Operating Instruction The cellar should be placed in an area where the ambient temperature range is between 18-26 °C (64.4° F - 78.8° F). If the ambient temperature is above or below this range, the performance of the unit may be affected. For example, placing your unit in extreme cold or hot conditions may cause interior temperatures to fluctuate. -
Page 17: Care And Maintenance
Operating Instruction (continued) IMPORTANT: • During a power interruption, all previous temperature settings are automatically saved, and each compartment returns to its previous temperature setting. • If the unit is unplugged, loses power, or is turned off, wait 3 to 5 minutes before restarting. Restarting before this time may hinder the wine cellar from starting. -
Page 18: Troubleshooting
Troubleshooting There are many common issues you may experience with your wine cellar that can be solved very easily, without the need of a service call. Try the tips below to troubleshoot your unit should you experience any problems: PROBLEM POSSIBLE CAUSES Not plugged in or the appliance is turned off Cellar does not operate... -
Page 19: Wire Diagram
Wire Diagram... -
Page 20: Warranty
Retain proof of original purchase to establish warranty of components such as seals, knobs, pan supports, period. Forno’s liability on any claim of any kind, with respect shelving, cutlery baskets, buttons, touch displays, to the goods and/or services provided, shall in no event scratched or broken ceramic-glass tops. - Page 21 TO PURCHASER AND PURCHASER’S PROPERTY AND TO OTHERS AND THEIR PROPERTY ARISING FROM THE USE, MISUSE, OR INABILITY TO USE THIS PRODUCT SOLD BY FORNO THAT IS NOT A DIRECT RESULT OF NEGLIGENCE ON THE PART OF FORNO THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL PURCHASER OF THIS PRODUCT, IS NON-TRANSFERABLE, AND STATES YOUR EXCLUSIVE REMEDY.
- Page 22 Customer Support: Call 1-866-231-8893 or email: info@forno.ca...
