- Page 1 WINE CELLAR MODEL NUMBER SERIES FWCDR6642-40S INSTRUCTION MANUAL & INSTALLATION GUIDE Read these instructions carefully before using your appliance, and keep it carefully. If you follow the instructions, your appliance will provide you with many years of good service.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Customer Care Warning Important Safety Product Dimension Cutout Names of Parts and Accessories Installations: • Anti-tip Bracket ..............• Handle ................Operating Instruction • Adjusting the Temperature Setting ........• Adjusting the Zones Settings..........Care and Maintenance •... - Page 4 WINE CELLAR MODEL NUMBER SERIES FWCDR6642-40S...
-
Page 5: Customer Care
A customer service representative will contact you as soon as possible. All warranty work needs to be authorized by FORNO customer service. All our authorized service providers are carefully selected and rigorously trained by us. -
Page 6: Warning
WARNING FOR YOUR SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. -
Page 7: Important Safety
Important Safety Instructions • The appliance is intended to be used exclusively for storage of wine. • Make sure the voltage/current marked on the rating label corresponds with your supply voltage. Plug into a grounded 3-pin outlet, do not remove grounding pin, do not use an adapter, and do not use an extension cord. •... - Page 8 Important Safety Instructions MOVING THE APPLIANCE Turn off the wine cooler and unplug from the outlet. Securely tape down all loose items inside. Close the door. Do not lift, pull the door or door handle during transportation. 5. When moving, the appliance can not be tilted over 45 degrees as possible damage to the sealed system could occur.
- Page 9 Important Safety Instructions The power cord should be secured behind the appliance and not left exposed or dangling to prevent accidental injury. Never unplug the appliance by pulling the power cord. Always grip the plug firmly and pull straight out from the receptacle.
-
Page 10: Product Dimension
Product Dimension Overall Width Overall Height Height Depth Depth Height (Hing to foot - on (Top to bottom) Back to door) Back to front Top to handle) maximum) frame) 39 3/8” 74 51/64” 73 15/64” 23 7/16” 21 13/16” 16 55/64” 100cm 190cm 186cm... -
Page 11: Cutout
Product Dimension (continued) Total of 166 bottles Cutout 75 13/64” 24 1/64” 39 48/64” 191 cm 61cm 101 cm... -
Page 12: Names Of Parts And Accessories
Names of Parts and Accessories Numbers Parts Control panel Handle Glass door Flat shelf Display shelf Leveling legs Bottom Grill Supplied Parts 2x Anti-tip bracket with hardware 2x Expansion bolt 1x Hexagon wrench 2x Handle Logo 2x Screws for the handle... -
Page 13: Installations
Installations Before installing your cellar, you must do the following: • Unpack both the exterior and interior layers of packaging. Verify the presence of all components listed in the parts inventory, including shelves and instructional materials. Should any elements, such as shelf fragments or support structures, become dislodged during transit, refer to the instruction manual for precise guidance on proper installation. -
Page 14: Handle
Installations (continued) 3. (A) Next insert the expansion bolt into the drilled hole. Make sure it is flush to the floor. (B) Unscrew the nut, washer and lock ring from the screw. 4. Next, align the bracket hole with the screw and reattach the washer and lock ring. Finally, tighten the nut with a wrench or socket to the maximum. -
Page 15: Operating Instruction
Operating Instruction The cellar should be placed in an area where the ambient temperature range is between 18-26 °C (64.4° F - 78.8° F). If the ambient temperature is above or below this range, the performance of the unit may be affected. For example, placing your unit in extreme cold or hot conditions may cause interior temperatures to fluctuate. -
Page 16: Care And Maintenance
Operating Instruction (continued) IMPORTANT: During a power interruption, all previous temperature settings are automatically saved, and each compartment returns to its previous temperature setting. If the unit is unplugged, loses power, or is turned off, wait 3 to 5 minutes before restarting. -
Page 17: Troubleshooting
Troubleshooting There are many common issues you may experience with your wine cellar that can be solved very easily, without the need of a service call. Try the tips below to troubleshoot your unit should you experience any problems: PROBLEM POSSIBLE CAUSES Not plugged in or the appliance is turned off Cellar does not operate... -
Page 18: Wire Diagram
Wire Diagram... -
Page 19: Warranty
Retain proof of original purchase to establish warranty of components such as seals, knobs, pan supports, period. Forno’s liability on any claim of any kind, with respect shelving, cutlery baskets, buttons, touch displays, to the goods and/or services provided, shall in no event scratched or broken ceramic-glass tops. - Page 20 TO PURCHASER AND PURCHASER’S PROPERTY AND TO OTHERS AND THEIR PROPERTY ARISING FROM THE USE, MISUSE, OR INABILITY TO USE THIS PRODUCT SOLD BY FORNO THAT IS NOT A DIRECT RESULT OF NEGLIGENCE ON THE PART OF FORNO THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL PURCHASER OF THIS PRODUCT, IS NON-TRANSFERABLE, AND STATES YOUR EXCLUSIVE REMEDY.
