Clicker KLIK1C Manual

CLICKER
®
Universal Garage Door Opener Remote Control
Thank you for your purchase of a Clicker
PLEASE DO NOT RETURN TO THE RETAIL STORE. If for any reason you
STOP
have questions or need help with troubleshooting please call: 1-800-442-1255.
Read instructions thoroughly BEFORE beginning.
Start with garage door closed. Identify garage door opener type - Smart/Learn
button or DIP Switch. Smart/Learn button or DIP Switches are located on motor
unit or external receiver. Refer to owner's manual if necessary.
Clicker products are intended to be used only with garage door openers
manufactured after 1993 that utilize photo-eyes safety sensors. These are
always located on or near the bottom of the door track. If your garage door
does not have the sensors attached and working, the opener is not
compliant with current federal safety regulations and should be replaced.
Proceed with instructions according to your type of garage door opener.
SMART/LEARN BUTTON
1
See Chart A to
determine # of times to
press button and write
in blank on step 5.
2
3
Press program button
until LED lights.
4
1 2 3
KG KG
Motor Unit
Press and release the
smart/learn button.
5
Select a button to program.
Press button times
ensuring LED stops flashing
after each press. Code is
accepted when one of the
following occurs:
Click
OR
OR
6
Press program button.
7
Programming complete.
Press selected button
to test. If unit does not
work, return to Step 3.
PRODUCT REGISTRATION AND
TROUBLESHOOTING
www.clickerproducts.com
1-800-442-1255
Chamberlain, LiftMaster and Moore-O-Matic are Trademarks of Chamberlain Group. Genie
and Intellicode are Trademarks of GMI Holdings, Inc. Overhead Door is a Trademark of
Overhead Door Corporation. Linear is a Trademark of Linear Corporation. Master Mechanic
is a Trademark of TruServ. Sears is a Trademark of Sears & Roebuck. Stanley is a
Trademark of The Stanley Works. Wayne Dalton is a trademark of Wayne Dalton
Corporation. Do It is a trademark of Do It Best Corporation.
114A3486D
MODEL KLIK1C
® universal remote control.
CHART A
# of times Brand Type/Color of
to press Smart/Learn
button
1 Linear ® Mega-Code
2 Chamberlain ® * Orange
3 Chamberlain ® * Purple
®
4 Chamberlain * Green
5 Genie ®
®
Overhead Door Intellicode
6 Genie ® **
®
Overhead Door Intellicode
7 Stanley ® Secure Code
8 Chamberlain ® * Yellow
9 Wayne Dalton ® Rolling Code
11 Chamberlain ® * 9 Position
*NOTE: LiftMaster, Do-It, Master Mechanic, Raynor, True Value and Sears Craftsman are compatible
with Chamberlain technology.
**NOTE: Visit www.clickerproducts.com for Genie Intellicode II instructions.
SMART/LEARN BUTTON
1
NOTE: Your opener may
appear different and you
may have to remove the
light lens to access the
learn button.
LED Indicator
Button 1
Program Button
REMOTE CONTROL BATTERY
To prevent possible SERIOUS INJURY or DEATH:
• NEVER allow small children near batteries.
• If battery is swallowed, immediately notify doctor.
To reduce risk of fire, explosion or chemical burn:
• Replace ONLY with 3V2032 coin batteries.
• DO NOT recharge, disassemble, heat above 212° F (100° C) or
incinerate.
Dispose of batteries properly. Replace ONLY with 3V2032 coin
batteries.
NOTICE: To comply with FCC and or Industry Canada (IC) rules, adjustment or modifications of this
receiver and/or transmitter are prohibited, except for changing the code setting or replacing the battery.
THERE ARE NO OTHER USER SERVICEABLE PARTS.
Tested to Comply with FCC Standards FOR HOME OR OFFICE USE. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
To prevent possible SERIOUS INJURY or DEATH from a moving gate or
garage door:
• ALWAYS keep remote controls out of reach of children. NEVER permit
children to operate, or play with remote control transmitters.
• Activate gate or door ONLY when it can be seen clearly, is properly
adjusted and there are no obstructions to door travel.
• ALWAYS keep gate or garage door in sight until completely closed.
NEVER permit anyone to cross path of moving gate or door.
Year
# of times Brand
to press
button
'97-Current
11 Chamberlain
'97-'05
12 Chamberlain
'05-Current
®
'93-'96 13 Genie
14 Linear Multicode
'95-Current
15 Chamberlain
16 Stanley/Multicode
'93-Current
17 Genie ®
'98
18 Linear ®
'11-Current
Moore-O-Matic
'99
19 Chamberlain
'90-'92
OR
DIP SWITCH
ON
2 3
KG KG
Button 2
DIP Switches
Battery
Battery Cover
© 2011, Clicker Corporation
All Rights Reserved
CHART B
Description Year
® * 9 Position '90-'92
®
* 9 Position
Canada '83-'89
12 Position '85
® 10 Position '76
® 8 Position '83-'89
® 10 Position '76
9 Position '85
® 8 Position '76
® * 7 Position '83-'89
Existing Remote
Select a button to program.
Press button
NOTE:
2 Position DIP Switch:
If programming fails reverse
DIP switches (OFF to ON and
ON to OFF).
**3 Position DIP Switch:
For Chamberlain remotes DO NOT
use the "0" position, use "+" or "-".
If you already have a 3-button
remote, DIP switch #1 must be set to "-" if the large
button is to open the door. It may be necessary to
reprogram original remote controls.
DIP SWITCH
1
See Chart B to
determine # of times to
press button and write
in blank on step 5.
2
3
Motor Unit
Clicker Remote
Match DIP switches. Turn
extra switches OFF.**
4
Press program button
until LED lights.
5
times
ensuring LED stops
flashing after each
press. Code is accepted
when door activates.
6
Press program button.
7
Programming complete.
Press selected button
to test. If unit does not
work, return to Step 3.
ON
